IXGY 2N120
TO-252 AA Outline (IXGY)
Symbol
Test Conditions
Characteristic Values
Min. Typ. Max.
(TJ = 25°C unless otherwise specified)
gfs
IC = IC90, VCE = 15 V,
1.5
2.5
S
Pulse test, t < 300 µs, duty cycle < 2 %
Cies
Coes
Cres
VCE = 25 V, VGE = 0 V, f = 1 MHz
110
12
2
pF
pF
pF
1Anode
2 NC
3Anode
4 Cathode
Qg
Qge
Qgc
IC = Ic90, VGE = 15 V, VCE = 0.5 VCES
9.0
1.6
3.2
nC
nC
nC
Dim. Millimeter
Inches
Min. Max. Min. Max.
td(on)
tri
td(off)
tfi
Inductive load, TJ = 25°C
IC = IC90, VGE = 15 V
RG = 150 Ω
VCLAMP = 0.8 VCES
Note 1
15
25
300
360
0.6
ns
ns
ns
ns
mJ
A
2.19 2.38 0.086 0.094
A1 0.89 1.14 0.035 0.045
A2
b
0
0.13
0
0.005
0.64 0.89 0.025 0.035
b1 0.76 1.14 0.030 0.045
b2 5.21 5.46 0.205 0.215
Eoff
c
c1
0.46 0.58 0.018 0.023
0.46 0.58 0.018 0.023
td(on)
Inductive load, TJ = 125°C
IC = IC90, VGE = 15 V
RG = R(off) = 150 Ω
VCLAMP = 0.8 VCES
Note 1
15
30
500
500
1.2
ns
ns
µs
ns
D
D1
5.97 6.22 0.235 0.245
4.32 5.21 0.170 0.205
t
tri
E
6.35 6.73 0.250 0.265
E1 4.32 5.21 0.170 0.205
d(off)i
tfi
e
e1
2.28 BSC
4.57 BSC
0.090BSC
0.180BSC
Eoff
mJ
H
L
9.40 10.42 0.370 0.410
0.51 1.02 0.020 0.040
L1
L2
L3
0.64 1.02 0.025 0.040
0.89 1.27 0.035 0.050
2.54 2.92 0.100 0.115
RthJC
4.2 K/W
Notes: 1. Switching times may increase for VCE (Clamp) > 0.8 VCES
higher TJ or increased RG.
,
IXYS reserves the right to change limits, test conditions, and dimensions.
