XTC7003
• Temperature Compensated Crystal Oscillator
• Hermetically Sealed Miniature SMT Package
• Good Frequency Stability
• Low Phase Noise
• Complies with Directive 2002/95/EC (RoHS)
12.80000 MHz
TCXO
P
b
SM5032-8 Case
Electrical Characteristics
Sym
Notes
Minimum
Typical
Maximum
Units
MHz
Characteristic
F
Nominal Frequency
12.80000
O
Storage Temperature Range in Tape and Reel
Operating Temperature Range
Power Supply Voltage
-40
-30
+85
+50
°C
°C
V
V
3
DD
V
V
P-P
Output Voltage with Load 10 pF || 10 KΩ
Power Supply Current
0.8
OUT
l
2.0
mA
DD
Frequency Tolerance
±1.0 ppm max @ 25 °C ±3 °C
Frequency Stability versus:
Temperature, -30 to 50 °C
±1
ppm
ppm
ppm
Load Variation, 10 pF ||10 KΩ ±10%
Supply Voltage, 3 V ±5%
±0.2
±0.2
±1.0 ppm/year @ 25 °C
1000
Aging
units
Stanard Shipping Quantity on 180 mm (7”) Reel
Lid Symbolization (in addition to Lot and/or Date Codes)
Line1: 7003 Line2: YWWS
CAUTION: Electrostatic Sensitive Device. Observe precautions for handling.
Notes:
1.
The design, manufacturing process, and specifications of this device are subject to change without notice.
