ZXTP25100CFHQTA

型号:

ZXTP25100CFHQTA

品牌:

DIODES[ DIODES INCORPORATED ]

页数:

7 页

PDF大小:

503 K

ZXTP25100CFHQ
100V PNP MEDIUM POWER TRANSISTOR IN SOT23
Description
Mechanical Data
Case: SOT23
This Bipolar Junction Transistor (BJT) is designed to meet the
stringent requirement of Automotive Applications.
Case Material: Molded Plastic. “Green” Molding Compound.
UL Flammability Rating 94V-0
Moisture Sensitivity: Level 1 per J-STD-020
Terminals: Finish - Matte Tin Plated Leads, Solderable per
Features
MIL-STD-202, Method 208
Weight: 0.008 grams (Approximate)
BVCEO > -100V
Maximum Continuous Collector Current IC = -1A
VCE(SAT) < -220mV @ -1A
RCE(SAT) = 150m
7V Reverse Blocking Voltage
Applications
MOSFET and IGBT Gate Driving
DC DC Converters
Motor Drive
High Peak Current
Complementary Part Number ZXTN25100CFH
Totally Lead-Free & Fully RoHS Compliant (Notes 1 & 2)
Halogen and Antimony Free. “Green” Device (Note 3)
Qualified to AEC-Q101 Standards for High Reliability
PPAP Capable (Note 4)
High Side Driver
SOT23
C
E
B
Top View
Pin-Out
Top View
Device Symbol
Ordering Information (Note 5)
Part Number
ZXTP25100CFHQTA
Compliance
Automotive
Marking
1G5
Reel Size (inches)
Tape Width (mm)
Quantity per Reel
7
8
3,000
Notes:
1. No purposely added lead. Fully EU Directive 2002/95/EC (RoHS), 2011/65/EU (RoHS 2) & 2015/863/EU (RoHS 3) compliant.
2. See https://www.diodes.com/quality/lead-free/ for more information about Diodes Incorporated’s definitions of Halogen- and Antimony-free, "Green" and
Lead-free.
3. Halogen- and Antimony-free "Green” products are defined as those which contain <900ppm bromine, <900ppm chlorine (<1500ppm total Br + Cl) and
<1000ppm antimony compounds.
4. Automotive products are AEC-Q101 qualified and are PPAP capable. Refer to https://www.diodes.com/quality/.
5. For packaging details, go to our website at https://www.diodes.com/design/support/packaging/diodes-packaging/.
Marking Information
SOT23
1G5 = Product Type Marking Code
YM = Date Code Marking
Y = Year ex: F = 2018
M = Month ex: 9 = September
1G5
Date Code Key
Year
2018
2019
2020
2021
2022
2023
2024
2025
2026
2027
2028
2029
Code
F
G
H
I
J
K
L
M
N
O
P
Q
Aug
Sep
Oct
Nov
Dec
Month
Code
Jan
Feb
Mar
Apr
May
Jun
Jul
8
9
O
N
D
1
2
3
4
5
6
7
1 of 7
www.diodes.com
October 2018
© Diodes Incorporated
ZXTP25100CFHQ
Document number: DS41475 Rev. 2 - 2
ZXTP25100CFHQ
Absolute Maximum Ratings (@TA = +25°C, unless otherwise specified.)
Characteristic
Symbol
VCBO
VCEO
VECO
VEBO
IC
Value
-115
-100
-7
Unit
V
Collector-Base Voltage
Collector-Emitter Voltage
V
Emitter-Collector voltage (Reverse Blocking)
Emitter-Base Voltage
V
-7
V
Continuous Collector Current
Base Current
-1
A
-500
-3
mA
A
IB
Peak Pulse Current
ICM
Thermal Characteristics (@TA = +25°C, unless otherwise specified.)
Characteristic
Symbol
Value
0.73
1.05
1.25
1.81
171
119
100
69
75.25
Unit
(Note 6)
(Note 7)
(Note 8)
(Note 9)
(Note 6)
(Note 7)
(Note 8)
(Note 9)
(Note 10)
Collector Power Dissipation
W
PD
Thermal Resistance, Junction to Ambient
C/W
RθJA
Thermal Resistance, Junction to Leads
RθJL
C/W
C
Operating and Storage Temperature Range
-55 to +150
TJ, TSTG
Notes:
6. For the device mounted on 15mm X 15mm X 1.6mm FR-4 PCB with high coverage of single sided 1oz copper in still air condition.
7. Mounted on 25mm X 25mm X 1.6mm FR-4 PCB with high coverage of single sided 2oz copper in still air condition.
8. Mounted on 25mm X 25mm X 1.6mm FR-4 PCB with high coverage of single sided 2oz copper in still air condition.
9. As Note 7 above, measured at t < 5 secs.
10. Thermal resistance from junction to solder-point (at the end of the collector lead).
2 of 7
www.diodes.com
October 2018
© Diodes Incorporated
ZXTP25100CFHQ
Document number: DS41475 Rev. 2 - 2
ZXTP25100CFHQ
Thermal Characteristics (@TA = +25°C, unless otherwise specified.)
1.4
10
1
50mmX50mm FR-4 PCB
2oz Cu
50mX50mm FR-4 PCB
2oz Cu
VCE(SAT)
Limited
1.2
1.0
0.8
0.6
0.4
0.2
0.0
25mX25mm FR-4 PCB
2oz Cu
DC
1s
100m
100ms
15mX15mm FR-4 PCB
1oz Cu
10ms
Single Pulse
TA=25OC
1ms
100s
10
10m
100m
0
20
40
60
80 100 120 140 160
1
100
Temperature (OC)
VCE Collector-Emitter Voltage (V)
Safe Operating Area
Derating Curve
100
80
60
40
20
0
TA=25OC
100
10
1
Single Pulse
TA=25OC
50mX50mm FR-4 PCB
2oz Cu
50mX50mm FR-4 PCB
2oz Cu
D=0.5
D=0.2
Single Pulse
D=0.05
D=0.1
1m 10m 100m
100
1
10
100
1k
1m 10m 100m
100
1
10
100
1k
Pulse Width (s)
Transient Thermal Impedance
Pulse Width (s)
Pulse Power Dissipation
3 of 7
www.diodes.com
October 2018
© Diodes Incorporated
ZXTP25100CFHQ
Document number: DS41475 Rev. 2 - 2
ZXTP25100CFHQ
Electrical Characteristics (@TA = +25°C, unless otherwise specified.)
Characteristic
Symbol
BVCBO
BVCEO
BVEBO
Min
-115
-100
-7
Typ
-180
-140
-8.4
Max
Unit
V
Test Condition
IC = -100µA
Collector-Base Breakdown Voltage
Collector-Emitter Breakdown Voltage (Note 11)
Emitter-Base Breakdown Voltage
-
-
-
V
IC = -10mA
V
IE = -100µA
IE = -100µA, RBC < 1kor
-0.25 < VBC < 0.25V
IE = -100µA
Emitter-Base Breakdown Voltage
Emitter-Base Breakdown Voltage
Collector-Base Cutoff Current
-7
-8.3
-
V
BVECX
BVECO
ICBO
-7
-
-8.8
< -1
-
-
V
-50
-0.5
nA
µA
VCB = -115V
-
VCB = -115V, TA = +100°C
VCE = -90V, RBE < 1kor
-0.25V < VBE < 1V
VEB = -5.6V
Collector-Emitter Cutoff Current
Emitter-Base Cutoff Current
-
-
-100
nA
nA
ICEX
IEBO
-
< -1
350
320
190
35
-50
500
-
200
IC = -10mA, VCE = -2V
IC = -100mA, VCE = -2V
IC = -500mA, VCE = -2V
IC = -1A, VCE = -2V
IC = - 100mA, IB = -1mA
IC = - 500mA, IB = -50mA
IC = - 500mA, IB = -20mA
IC = - 1A, IB = -100mA
IC = -1A, IB = -100mA
IC = -1A, VCE = -2V
VCB = -10V, f = 1MHz
180
Static Forward Current Transfer Ratio (Note 11)
Collector-Emitter Saturation Voltage (Note 11)
-
hFE
110
-
20
-
-
-140
-80
-210
-110
-310
-220
-950
-900
20
-
mV
VCE(SAT)
-
-180
-150
-849
-790
14.1
-
Base-Emitter Saturation Voltage (Note 11)
Base-Emitter Saturation Voltage (Note 11)
Output Capacitance
-
mV
mV
pF
VBE(SAT)
VBE(ON)
Cobo
-
-
VCE = -15V, IC = -20mA,
f = 100MHz
Transition Frequency
-
180
-
MHz
fT
Delay Time
Rise Time
Storage Time
Fall Time
-
-
-
-
15.8
41
-
-
-
-
ns
ns
ns
ns
tD
tR
tS
tF
VCC = -10V, IC = -500mA,
IB1 = -IB2 = -50mA
411
89
Note:
11. Measured under pulsed conditions. Pulse width ≤ 300 µs. Duty cycle ≤ 2%.
4 of 7
www.diodes.com
October 2018
© Diodes Incorporated
ZXTP25100CFHQ
Document number: DS41475 Rev. 2 - 2
ZXTP25100CFHQ
Typical Electrical Characteristics (@TA = +25°C, unless otherwise specified.)
1
100m
10m
0.4
0.3
0.2
0.1
0.0
TA=25OC
IC/IB=10
IC/IB=100
IC/IB=50
150OC
100OC
IC/IB=25
25OC
1
IC/IB=10
-55OC
1m
10m
100m
1
10m
100m
- IC Collector Current (A)
- IC Collector Current (A)
VCE(SAT) v IC
VCE(SAT) v IC
1.0
0.8
0.6
0.4
0.2
-55OC
600
500
400
300
200
100
0
VCE=2V
IC/IB=10
1.6
1.4
1.2
1.0
0.8
0.6
0.4
0.2
0.0
25OC
150OC
100OC
25OC
150OC
100OC
-55OC
1m
10m
100m
1
1m
10m
100m
1
- IC Collector Current (A)
- IC Collector Current (A)
hFE v IC
VBE(SAT) v IC
200
180
160
140
120
100
80
1.0
0.8
0.6
0.4
0.2
-55OC
VCE=2V
f = 1MHz
25OC
Cibo
150OC
60
40
100OC
Cobo
20
0
10m
100m
1
10
100
1m
10m
100m
1
- Voltage(V)
- IC Collector Current (A)
Capacitance v Voltage
VBE(ON) v IC
5 of 7
www.diodes.com
October 2018
© Diodes Incorporated
ZXTP25100CFHQ
Document number: DS41475 Rev. 2 - 2
ZXTP25100CFHQ
Package Outline Dimensions
Please see http://www.diodes.com/package-outlines.html for the latest version.
SOT23
All 7°
H
SOT23
GAUGE PLANE
0.25
Dim
A
B
C
D
F
G
H
Min
0.37
1.20
2.30
0.89
0.45
1.78
2.80
Max
0.51
1.40
2.50
1.03 0.915
0.60 0.535
Typ
0.40
1.30
2.40
J
K
K1
a
M
A
2.05
3.00
1.83
2.90
0.05
L
L1
J
0.013 0.10
K
K1
L
L1
M
a
0.890 1.00 0.975
0.903 1.10 1.025
C
B
0.45
0.25
0.61
0.55
0.55
0.40
0.085 0.150 0.110
0° 8° --
D
All Dimensions in mm
G
F
Suggested Pad Layout
Please see http://www.diodes.com/package-outlines.html for the latest version.
SOT23
Y
Dimensions Value (in mm)
C
X
X1
Y
2.0
0.8
1.35
0.9
Y1
C
Y1
2.9
X
X1
6 of 7
www.diodes.com
October 2018
© Diodes Incorporated
ZXTP25100CFHQ
Document number: DS41475 Rev. 2 - 2
ZXTP25100CFHQ
IMPORTANT NOTICE
DIODES INCORPORATED MAKES NO WARRANTY OF ANY KIND, EXPRESS OR IMPLIED, WITH REGARDS TO THIS DOCUMENT,
INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE
(AND THEIR EQUIVALENTS UNDER THE LAWS OF ANY JURISDICTION).
Diodes Incorporated and its subsidiaries reserve the right to make modifications, enhancements, improvements, corrections or other changes
without further notice to this document and any product described herein. Diodes Incorporated does not assume any liability arising out of the
application or use of this document or any product described herein; neither does Diodes Incorporated convey any license under its patent or
trademark rights, nor the rights of others. Any Customer or user of this document or products described herein in such applications shall assume
all risks of such use and will agree to hold Diodes Incorporated and all the companies whose products are represented on Diodes Incorporated
website, harmless against all damages.
Diodes Incorporated does not warrant or accept any liability whatsoever in respect of any products purchased through unauthorized sales channel.
Should Customers purchase or use Diodes Incorporated products for any unintended or unauthorized application, Customers shall indemnify and
hold Diodes Incorporated and its representatives harmless against all claims, damages, expenses, and attorney fees arising out of, directly or
indirectly, any claim of personal injury or death associated with such unintended or unauthorized application.
Products described herein may be covered by one or more United States, international or foreign patents pending. Product names and markings
noted herein may also be covered by one or more United States, international or foreign trademarks.
This document is written in English but may be translated into multiple languages for reference. Only the English version of this document is the
final and determinative format released by Diodes Incorporated.
LIFE SUPPORT
Diodes Incorporated products are specifically not authorized for use as critical components in life support devices or systems without the express
written approval of the Chief Executive Officer of Diodes Incorporated. As used herein:
A. Life support devices or systems are devices or systems which:
1. are intended to implant into the body, or
2. support or sustain life and whose failure to perform when properly used in accordance with instructions for use provided in the
labeling can be reasonably expected to result in significant injury to the user.
B. A critical component is any component in a life support device or system whose failure to perform can be reasonably expected to cause the
failure of the life support device or to affect its safety or effectiveness.
Customers represent that they have all necessary expertise in the safety and regulatory ramifications of their life support devices or systems, and
acknowledge and agree that they are solely responsible for all legal, regulatory and safety-related requirements concerning their products and any
use of Diodes Incorporated products in such safety-critical, life support devices or systems, notwithstanding any devices- or systems-related
information or support that may be provided by Diodes Incorporated. Further, Customers must fully indemnify Diodes Incorporated and its
representatives against any damages arising out of the use of Diodes Incorporated products in such safety-critical, life support devices or systems.
Copyright © 2018, Diodes Incorporated
www.diodes.com
7 of 7
www.diodes.com
October 2018
© Diodes Incorporated
ZXTP25100CFHQ
Document number: DS41475 Rev. 2 - 2
厂商 型号 描述 页数 下载

ZETEX

ZXT1053AK 75V NPN低饱和中功率晶体管D- PAK[ 75V NPN LOW SATURATION MEDIUM POWER TRANSISTOR IN D-PAK ] 6 页

DIODES

ZXT1053AK 75V NPN低饱和中功率晶体管D- PAK[ 75V NPN LOW SATURATION MEDIUM POWER TRANSISTOR IN D-PAK ] 6 页

DIODES

ZXT1053AKQTC [ 暂无描述 ] 6 页

ZETEX

ZXT1053AKTC 75V NPN低饱和中功率晶体管D- PAK[ 75V NPN LOW SATURATION MEDIUM POWER TRANSISTOR IN D-PAK ] 6 页

DIODES

ZXT1053AKTC 75V NPN低饱和中功率晶体管D- PAK[ 75V NPN LOW SATURATION MEDIUM POWER TRANSISTOR IN D-PAK ] 6 页

ZETEX

ZXT10N15DE6 15V NPN硅低饱和开关晶体管[ 15V NPN SILICON LOW SATURATION SWITCHING TRANSISTOR ] 6 页

DIODES

ZXT10N15DE6 15V NPN硅低饱和开关晶体管[ 15V NPN SILICON LOW SATURATION SWITCHING TRANSISTOR ] 6 页

ZETEX

ZXT10N15DE6TA 15V NPN硅低饱和开关晶体管[ 15V NPN SILICON LOW SATURATION SWITCHING TRANSISTOR ] 6 页

DIODES

ZXT10N15DE6TA 15V NPN硅低饱和开关晶体管[ 15V NPN SILICON LOW SATURATION SWITCHING TRANSISTOR ] 6 页

ZETEX

ZXT10N15DE6TC 15V NPN硅低饱和开关晶体管[ 15V NPN SILICON LOW SATURATION SWITCHING TRANSISTOR ] 6 页

PDF索引:

A

B

C

D

E

F

G

H

I

J

K

L

M

N

O

P

Q

R

S

T

U

V

W

X

Y

Z

0

1

2

3

4

5

6

7

8

9

IC型号索引:

A

B

C

D

E

F

G

H

I

J

K

L

M

N

O

P

Q

R

S

T

U

V

W

X

Y

Z

0

1

2

3

4

5

6

7

8

9

Copyright 2024 gkzhan.com Al Rights Reserved 京ICP备06008810号-21 京

0.243749s
