NZL5V6AUA3

型号:

NZL5V6AUA3

品牌:

ROCHESTER[ Rochester Electronics ]

页数:

5 页

PDF大小:

718 K

NZL5V6AUA3
Product Preview
MicroLeadlesst Dual
Common Anode Zener for
ESD Protection
http://onsemi.com
Plastic Surface Mount Leadless Package
This dual monolithic silicon voltage suppressor is designed for
applications requiring ESD protection capability. It is intended for use
in voltage and ESD sensitive equipment such as computers, printers,
business machines, communication systems, medical equipment, and
other applications. Its dual junction common anode design protects
four separate lines using only one package. These devices are ideal for
situations where board space is at a premium.
CATHODE
1
3
2
ANODE
CATHODE
3
1
Specification Features
Low Leakage < 1 mA @ 3 Volts
2
Breakdown Voltage: 5.3 – 5.9 Volts @ 1 mA
Low Capacitance (40 pF typical between terminals)
ESD Protection Meeting IEC61000–4–2 Level 4
1006 3 PAD
CASE TBD
STYLE 4
MARKING DIAGRAM
Mechanical Characteristics
Void Free, Transfer–Molded, Thermosetting Plastic Case
Corrosion Resistant Finish, Easily Solderable
Small Package Size for High Density Applications
56
56 = Device Marking
ORDERING INFORMATION
Device
NZL5V6AUA3
Package
Shipping
TBD
1006 3 Pad
MicroLeadless
This document contains information on a product under development. ON Semiconductor
reserves the right to change or discontinue this product without notice.
Semiconductor Components Industries, LLC, 2002
1
Publication Order Number:
February, 2002 – Rev. 0
NZL5V6AUA3/D
NZL5V6AUA3
ELECTRICAL CHARACTERISTICS
I
(T = 25°C unless otherwise noted)
UNIDIRECTIONAL (Circuit tied to Pins 1 and 3 or 2 and 3)
A
I
F
Symbol
Parameter
I
PP
Maximum Reverse Peak Pulse Current
V
C
Clamping Voltage @ I
PP
V
C
V
V
BR RWM
V
I
V
F
V
RWM
Working Peak Reverse Voltage
R
T
I
I
R
Maximum Reverse Leakage Current @ V
RWM
V
Breakdown Voltage @ I
Test Current
BR
T
I
T
I
PP
QV
Maximum Temperature Coefficient of V
Forward Current
BR
BR
I
F
Uni–Directional TVS
V
F
Forward Voltage @ I
F
Z
Maximum Zener Impedance @ I
Reverse Current
ZT
ZT
I
ZK
Z
ZK
Maximum Zener Impedance @ I
ZK
MAXIMUM RATINGS (T = 25°C unless otherwise noted)
A
Characteristic
Steady State Power – 1 Diode
Symbol
Value
>150
Unit
mW
°C
P
D
Maximum Junction Temperature
T
Jmax
150
Operating Junction and Storage Temperature Range
T T
–55 to +150
°C
J
stg
ESD Discharge
IEC61000–4–2, Air Discharge
IEC61000–4–2, Contact Discharge
V
$15
kV
PP
$8
Lead Solder Temperature (10 seconds duration)
T
260
°C
L
ELECTRICAL CHARACTERISTICS
Typical
Capacitance
Breakdown Voltage
Leakage Current
Max
@ 0 V Bias
@ 1.0 MHz
V
BR
@ 1 mA (Volts)
I
@ V
= 3.0 V
V @ I = 10 mA
RM
RM
F
F
Device
Min
Nom
Max
(mA)
(pF)
(V)
1.25
NZL5V6
5.3
5.6
5.9
1.0
40
300
250
200
100
PEAK VALUE I
@ 8 ms
t
r
RSM
90
80
70
60
50
40
30
20
PULSE WIDTH (t ) IS DEFINED
AS THAT POINT WHERE THE
PEAK CURRENT DECAY = 8 ms
p
HALF VALUE I
/2 @ 20 ms
RSM
150
100
50
t
p
10
0
0
0
25
50
75
100
125
150
175
0
20
40
t, TIME (ms)
60
80
TEMPERATURE (°C)
Figure 1. Steady State Power Derating Curve
Figure 2. 8 X 20 ms Pulse Waveform
http://onsemi.com
2
NZL5V6AUA3
100
45
40
35
30
25
20
15
10
10
5
NOTE: Non–Repetitive Surge
100
1
0
10
1000
0
0.5
1
1.5
2
2.5
3
3.5
4
4.5
5
t , PULSE WIDTH (ms)
p
BIAS VOLTAGE (V)
Figure 3. Pulse Rating Curve
Figure 4. Capacitance
100
10
1
1
0.1
0.01
1.0 ms SQUARE WAVE
0.001
0.6 0.7
0.8
0.9
1
1.1
1.2
1.3
1.4
4
4.2 4.4 4.6 4.8
5
5.2 5.4 5.6 5.8
6
V , FORWARD VOLTAGE (V)
F
V , CLAMPING VOLTAGE (V)
C
Figure 5. Forward Current versus
Forward Voltage
Figure 6. Clamping Voltage versus Peak Pulse
Current (Reverse Direction)
http://onsemi.com
3
NZL5V6AUA3
PACKAGE DIMENSIONS
1006 MicroLeadless
CASE TBD
ISSUE TBD
0.5 mm
STYLE 4:
PIN 1. CATHODE
2. CATHODE
3. ANODE
1.0 mm
BSC
0.15 mm
0.50 mm
1
0.60 mm
BSC
3
2
0.25 mm
0.40 mm
0.25 mm
0.05 mm typ
MicroLeadless is a trademark of Semiconductor Components Industries, LLC (SCILLC).
ON Semiconductor and
are trademarks of Semiconductor Components Industries, LLC (SCILLC). SCILLC reserves the right to make changes
without further notice to any products herein. SCILLC makes no warranty, representation or guarantee regarding the suitability of its products for any particular
purpose, nor does SCILLC assume any liability arising out of the application or use of any product or circuit, and specifically disclaims any and all liability,
including without limitation special, consequential or incidental damages. “Typical” parameters which may be provided in SCILLC data sheets and/or
specifications can and do vary in different applications and actual performance may vary over time. All operating parameters, including “Typicals” must be
validated for each customer application by customer’s technical experts. SCILLC does not convey any license under its patent rights nor the rights of others.
SCILLC products are not designed, intended, or authorized for use as components in systems intended for surgical implant into the body, or other applications
intended to support or sustain life, or for any other application in which the failure of the SCILLC product could create a situation where personal injury or
death may occur. Should Buyer purchase or use SCILLC products for any such unintended or unauthorized application, Buyer shall indemnify and hold
SCILLC and its officers, employees, subsidiaries, affiliates, and distributors harmless against all claims, costs, damages, and expenses, and reasonable
attorney fees arising out of, directly or indirectly, any claim of personal injury or death associated with such unintended or unauthorized use, even if such claim
alleges that SCILLC was negligent regarding the design or manufacture of the part. SCILLC is an Equal Opportunity/Affirmative Action Employer.
PUBLICATION ORDERING INFORMATION
Literature Fulfillment:
JAPAN: ON Semiconductor, Japan Customer Focus Center
4–32–1 Nishi–Gotanda, Shinagawa–ku, Tokyo, Japan 141–0031
Phone: 81–3–5740–2700
Literature Distribution Center for ON Semiconductor
P.O. Box 5163, Denver, Colorado 80217 USA
Phone: 303–675–2175 or 800–344–3860 Toll Free USA/Canada
Fax: 303–675–2176 or 800–344–3867 Toll Free USA/Canada
Email: ONlit@hibbertco.com
Email: r14525@onsemi.com
ON Semiconductor Website: http://onsemi.com
For additional information, please contact your local
Sales Representative.
N. American Technical Support: 800–282–9855 Toll Free USA/Canada
NZL5V6AUA3/D
