PRELIMINARY
5R8/3DCT
thru
15R8/3DCT
SOLID STATE DEVICES, INC.
14005 Stage Road * Santa Fe Springs, Ca 90670
Phone: (562) 404-4474 * Fax: (562) 404-1773
100 AMP
50-200 VOLTS
70nsec
Designer's Data Sheet
FEATURES:
EPION
Optimized for 12V and 15V auxiliary output power supplies. The
EPION series has been designed to provide low forward voltage
drops and small delta shifts in reverse recovery time at high
temperature minimizing switching loses.
CENTERTAP RECTIFIER
CERAMIC SEAL TO-3
• Radiation Tolerant
• Ultra Fast Recovery Time
• Low Forward Voltage
• Low Reverse Leakage
• Hermetically Sealed Package
• High Reverse Blocking Voltage
• 175oC Operating TJ
SYMBOL
VALUE
UNITS
Volts
Maximum Ratings
50
70
100
125
150
5R
Peak Repetitive Reverse and
7R
V
RM(rep)
DC Blocking Voltage
10R
12R
15R
V
R
Half Wave Rectified Forward Current. Averaged Over
Full Cycle per leg .
Io
100
Amps
(Resistive load, 60Hz, Sine Wave, T = 55oC)
C
Peak Repetitive Forward Current per leg
(T = 55oC, 8.3 ms Pulse, Allow Junction to Reach Equilib-
I
110
Amps
Amps
C
FM(rep)
rium Between Pulses)
Peak Surge Current per leg
(T = 55oC, Superimposed on Rated Current at Rated
I
1000
FM(surge)
C
Voltage, 8.3 ms Pulse)
TJ & Tstg
-65 TO +175
0.5
oC
Operating and Storage Temperature
Maximum Thermal Resistance
Junction to Case
R
2JC
oC/W
NOTE: All specifications are subject to change without notification.
SCD's for these devices should be reviewed by SSDI prior to release.
DATA SHEET #: RC0004A
