MYGTC012R5BZN Short Form
1
DC-DC Converter Short Form
MYGTC012R5BZN (Small Size & High Efficiency)
■ FEATURES
・ High efficiency & Small Size SIL
・ Wide input rage (16V to 40V)
・ 2 output(5V , 12V)
・ Plastic case type
・ ON/OFF control function(Control independent by 2 outputs)
・ Short circuit protection
■ GENERAL SPECIFICATIONS (Ta=25ºC)
Item
Symbol
Condition
MIN.
16.0
TYP.
24.0
MAX.
40.0
UNIT
V
Input Voltage
Vin
Vout1
Vout2
Iout1
Iout2
Vrpl1
Vrpl2
EFF
4.85
5.00
5.15
12.36
0.5
Vin=16.0~40.0V,
Output Voltage
Output Current
V
A
Iout1=0~0.5A, Iout2=0~0.5A
11.64
12.00
0
0
-
-
Vin=16.0~40.0V
-
50
100
89
-
0.5
-
Vin=24V,
Iout1=0~0.5A,Iout2=0~0.5A,
BW=20MHz
Ripple Voltage
Efficiency
mVpp
%
Vin=24V, Iout1=0.5A, Iout2=0.5A
-
2.5
-
-
-
OFF
On/Off1
Vin=16.0~40.0V
ON
-
0.5
-
Remote Voltage
V
OFF
2.5
-
On/Off2
SCP
Vin=16.0~40.0V,
ON
-
-
0.5
If output is shorted to GND, DC-DC Converter shall be operated in a
hiccup mode. After the short circuit event has cleared, the output is
automatically brought back into regulation.
Short Circuit
Protection
Note:
1. This datasheet is downloaded from the website of Murata Manufacturing co., ltd. Therefore, it’ s specifications are subject to change or our
products in it may be discontinued without advance notice. Please check with our sales representatives or product engineers before ordering.
2. This datasheet has only typical specifications because there is no space for detailed specifications. Therefore, please approve our product
specifications or transact the approval sheet for product specifications before ordering.
2009.10.8
