Note: This datasheet maybe out of date.
Please download the latest datasheet of DXW21BN2511N#from the official website of Murata Manufacturing
Co., Ltd.
http://www.murata.com/en-global/products/productdetail?partno=DXW21BN2511N%23
Product Search Data Sheet
“#” indicates a package specification code.
DXW21BN2511N#
< List of part numbers with package codes >
DXW21BN2511NB DXW21BN2511NK DXW21BN2511NL
Appearance & Shape
Features
1. Ultra Miniature Wire Wound Transformer
(2.0×1.2×1.2mm)
2. Low lnsertion Loss
3. Wideband Frequency Range
4. Surface Mount
Applications
TV tuners, Cable TV tuners and Communication application
that require unbalance mode to balance mode conversion.
Applications
Other Usage
For general
Packaging Information
Minimum
Order Quantity
Packaging
Specifications
B
K
L
Bulk(Bag)
500
330mm Embossed Tape
180mm Embossed Tape
10000
2000
1 of 3
Attention
1.This datasheet is downloaded from the website of Murata Manufacturing Co., Ltd. Therefore, it’s specifications are subject to change or our products in it maybe discontinued
without advance notice. Please checkwith our sales representatives or product engineers before ordering.
2.This datasheet has onlytypical specifications because there is no space for detailed specifications.
Therefore, please reviewour product specifications or consult the approval sheet for product specifications before ordering.
