THE CONNOR-WINFIELD CORP.
2111 COMPREHENSIVE DRIVE.
AURORA, IL 60505.
FAX
PHONE (630) 851-4722.
WWW.CONWIN.COM
(630) 851-5040.
P R O D U C T D A T A S H E E T
CRYSTAL CONTROLLED OSCILLATORS
PIN CONNECTIONS
Notes:
1) Initial calibration @ 25°C, Vc = 1.5 Vdc.
2) Frequency stability, absolute over the temperature range of 0 to 70°C.
3) Frequency stability per 5% change in supply voltage.
TABLE 7.0
Pin
1
Function
4) At the time of shipment after 48 hours of operation.
Voltage Control
Ground (Case)
Output
5) Inclusive of calibration, operating temperature range, supply voltage change, shock and
vibration and aging (20 years).
7
8
6) Measured @ 25°C, within 5 minutes, the unit will be within +/-0.1ppm of its reference
frequency, measured after 30 minutes of continuous operation at a stable 25°C.
7) Referenced to Fo @ 25°C, Positive Transfer Characteristic.
14
Vcc
ENVIRONMENTAL CHARACTERISTICS
Temperature Cycle: Per MIL-STD-883, Method 1010, Condition B. -55°C to 125°C, 300 cycles,
10 minute dwell, 1minute transition.
MECHANICAL CHARACTERISTICS
Vibration: Per MIL-STD-202, Method 204, Condition A. 10G’s peak, 10Hz to 500Hz, 15 minute
cycles 12 times each perpendicular axis.
Shock: Per MIL-STD-202, Method 213, Condition F. 1500G’s, 0.5ms, half sine, 3 shocks per
direction.
Moisture Resistance: Per MIL-STD-202, Method 106. 95% RH @ 65°C, 10 cycles 10°C to 65°C.
PACKAGE LAYOUT
SUGGESTED PAD LAYOUT
KEEP OUT AREA
..333300 mmaaxx
((88..338822mmmm))
.830
(21.08mm)
Dimensional Tolerance:
±.005 (.127mm)
.565
(14.35mm)
SOLDER PROFILE
TEST CIRCUIT
Temperature
260°C
260°C
220°C
180°C
150°C
120°C
POWER
SUPPLY
14
8
5.0Vdc
1
7
0
CONTROL
VOLTAGE
50 Ohm
Time
120 S
Max.
Oscilloscope
Termination
10 S
60 S
Max.
360 Sec. Max.
Specifications subject to change without notice.
Copyright 2001 Connor-Winfield all rights reserved.
a
12/29/06
Cx118
00
2
2
DATASHEET #:
PAGE
OF
REV:
DATE:
