VUI 9-06N7
VRRM = 1200 V
IFAV25 = 15 A
Rectifier Module for
Power Factor Correction
VCES = 600 V
IC25 = 37 A
Fast Single Phase Rectifier
Ultra Fast Boost Chopper
Preliminary data sheet
J
A
B
N
E
Typical Rectified Mains Power
D 11
D 13
D 14
D 1
Pn = 900 W at Vn = 110 V
H
Pn = 2100 W at Vn = 240 V
D 12
7
T
at VDC = 400 V, fT = 75 kHz, TC = 80°C
G
G
Pin configuration see outlines
Application
Input Rectifier Bridge D11 - D14
• single phase rectification with power
factor correction (PFC)
• low harmonic content of mains current
• mains current and voltage in phase
• wide input voltage range, controlled
output voltage
Symbol
VRRM
Conditions
Maximum Ratings
1200
V
IFAV25
IFAV80
TC = 25°C; sine 180°
TC = 80°C; sine 180°
15
10
A
A
IFSM
TVJ = 25°C; t = 10 ms sine 50 Hz
75
A
Features
• high level of integration -
only one power semiconductor
module required for the whole PFC
rectifier
• standard PFC control ICs useable
• fast rectifier diodes for enhanced
Symbol
Conditions
Characteristic Values
(TVJ = 25°C, unless otherwise specified)
min. typ. max.
VF
IR
IF = 10 A
VR = VRRM
TVJ = 25°C
TVJ = 125°C
1.4
1.6
1.8
V
V
EMC
behaviour
• NPT IGBT with low saturation voltage,
ultra fast switching capability,
high RBSOA and short circuit
ruggedness
• internally series connected
HiPerFREDTM free wheeling diode
for fast and soft reverse recovery at
high switching frequency
TVJ = 25°C
TVJ = 125°C
0.05 mA
mA
0.5
1
trr
VR = 100 V; IF = 10 A; -di/dt = 5 A/µs
µs
RthJC
RthJH
(per diode)
with heat transfer paste
2.5 K/W
K/W
3.8
• package with insulated DCB base and
soldering pins for PCB mounting
© 2007 IXYS All rights reserved
1 - 3
