TPS3809J25-Q1, TPS3809L30-Q1, TPS3809K33-Q1, TPS3809I50-Q1
SGLS142B –JUNE 2008–REVISED MARCH 2016
TPS3809xxx-Q1 3-Pin Supply Voltage Supervisors
1 Features
3 Description
The TPS3809 family of supervisory circuits provides
circuit initialization and timing supervision, primarily
for DSPs and processor-based systems.
1
•
•
Qualified for Automotive Applications
AEC-Q100 Qualified With the Following Results:
–
Device Temperature Grade 1: –40°C to
+125°C Ambient Operating Temperature
Range
During power-on, RESET is asserted when the
supply voltage VDD becomes higher than 1.1 V.
Thereafter, the supervisory circuit monitors VDD and
keeps RESET active as long as VDD remains below
the threshold voltage VIT. An internal timer delays the
return of the output to the inactive state (high) to
–
–
Device HBM ESD Classification Level 2
Device CDM ESD Classification Level C5
•
•
•
3-Pin SOT-23 Package
ensure proper system reset. The delay time, td(typ)
=
Supply Current of 9 μA (Typical)
200 ms, starts after VDD has risen above the
threshold voltage VIT. When the supply voltage drops
below the threshold voltage VIT, the output becomes
active (low) again. No external components are
required. All the devices of this family have a fixed
sense-threshold voltage VIT set by an internal voltage
divider.
Precision-Supply Voltage Monitor 2.5 V, 3 V, 3.3
V, 5 V
•
•
Power-On Reset Generator With Fixed Delay
Time of 200 ms
Pin-For-Pin Compatible With MAX 809
The product spectrum is designed for supply voltages
of 2.5 V, 3 V, 3.3 V, and 5 V. The circuits are
available in a 3-pin SOT-23. The TPS3809xxx-Q1
2 Applications
•
Automotive Applications With DSPs,
Microcontrollers, or Microprocessors
devices are characterized for operation over
a
temperature range of −40°C to 125°C, and are
qualified in accordance with AEC-Q100 stress test
qualification for integrated circuits. For more
information about TI's voltage supervisor portfolio,
please visit the Supervisor and Reset IC Overview
web page.
•
•
•
Automotive Camera Systems
Automotive Radar
USB Hubs and Charging
Device Information(1)
PART NUMBER
PACKAGE
BODY SIZE (NOM)
TPS3809xxx-Q1
SOT-23 (3)
2.90 mm × 1.60 mm
(1) For all available packages, see the orderable addendum at
the end of the datasheet.
Typical Application
TPS76333
IN OUT
3.3 V
5 V
GND
V
DD
TMS320LC54x
V
DD
TPS3809K33-Q1
RESET
RESET
GND
GND
1
An IMPORTANT NOTICE at the end of this data sheet addresses availability, warranty, changes, use in safety-critical applications,
intellectual property matters and other important disclaimers. PRODUCTION DATA.





TPS3809J25-Q1, TPS3809L30-Q1, TPS3809K33-Q1, TPS3809I50-Q1
SGLS142B –JUNE 2008–REVISED MARCH 2016
www.ti.com
Table of Contents
8.2 Functional Block Diagram ......................................... 8
8.3 Feature Description................................................... 8
8.4 Device Functional Modes.......................................... 8
Application and Implementation .......................... 9
9.1 Application Information.............................................. 9
9.2 Typical Application ................................................... 9
1
2
3
4
5
6
7
Features.................................................................. 1
Applications ........................................................... 1
Description ............................................................. 1
Revision History..................................................... 2
Voltage Options ..................................................... 3
Pin Configuration and Functions......................... 3
Specifications......................................................... 4
7.1 Absolute Maximum Ratings ...................................... 4
7.2 ESD Ratings.............................................................. 4
7.3 Recommended Operating Conditions....................... 4
7.4 Thermal Information.................................................. 4
7.5 Electrical Characteristics........................................... 5
7.6 Timing Requirements................................................ 5
7.7 Switching Characteristics.......................................... 5
7.8 Typical Characteristics.............................................. 7
Detailed Description .............................................. 8
8.1 Overview ................................................................... 8
9
10 Power Supply Recommendations ..................... 11
11 Layout................................................................... 11
11.1 Layout Guidelines ................................................. 11
11.2 Layout Example .................................................... 11
12 Device and Documentation Support ................. 12
12.1 Related Links ........................................................ 12
12.2 Community Resources.......................................... 12
12.3 Trademarks........................................................... 12
12.4 Electrostatic Discharge Caution............................ 12
12.5 Glossary................................................................ 12
8
13 Mechanical, Packaging, and Orderable
Information ........................................................... 12
4 Revision History
Changes from Revision A (December 2002) to Revision B
Page
•
•
•
Added AEC-Q100 Qualified information in bullets ................................................................................................................ 1
Changed Applications list items ............................................................................................................................................. 1
Added ESD Ratings table, Feature Description section, Device Functional Modes, Application and Implementation
section, Power Supply Recommendations section, Layout section, Device and Documentation Support section, and
Mechanical, Packaging, and Orderable Information section ................................................................................................. 1
•
Changed device part numbers by adding -Q1 to them throughout document ...................................................................... 5
2
Submit Documentation Feedback
Copyright © 2008–2016, Texas Instruments Incorporated
Product Folder Links: TPS3809J25-Q1 TPS3809L30-Q1 TPS3809K33-Q1 TPS3809I50-Q1

TPS3809J25-Q1, TPS3809L30-Q1, TPS3809K33-Q1, TPS3809I50-Q1
www.ti.com
SGLS142B –JUNE 2008–REVISED MARCH 2016
5 Voltage Options
TA
DEVICE NAME
THRESHOLD VOLTAGE
MARKING
PCZQ
TPS3809J25QDBVRQ1
TPS3809L30QDBVRQ1
TPS3809K33QDBVRQ1
TPS3809I50QDBVRQ1
2.25 V
2.64 V
2.93 V
4.55 V
PDAQ
−40°C to 125°C
PDBQ
PDCQ
6 Pin Configuration and Functions
DBV Package
3-Pin SOT-23
Top View
GND
1
2
3
V
DD
RESET_
Pin Functions
PIN
I/O
DESCRIPTION
NAME
GND
NO.
1
—
O
I
Ground
RESET
VDD
2
Reset output
3
Supply voltage and supervising input
Copyright © 2008–2016, Texas Instruments Incorporated
Submit Documentation Feedback
3
Product Folder Links: TPS3809J25-Q1 TPS3809L30-Q1 TPS3809K33-Q1 TPS3809I50-Q1

TPS3809J25-Q1, TPS3809L30-Q1, TPS3809K33-Q1, TPS3809I50-Q1
SGLS142B –JUNE 2008–REVISED MARCH 2016
www.ti.com
7 Specifications
7.1 Absolute Maximum Ratings
over operating free-air temperature range (unless otherwise noted)(1)
MIN
MAX
7
UNIT
V
(2)
Supply voltage, VDD
All other pins(2)
–0.3
7
V
Maximum low output current, IOL
Maximum high output current, IOH
5
mA
mA
mA
mA
–5
20
20
Input clamp current, IIK (VI<0 or VI>VDD
)
–20
–20
Output clamp current, IOK (VO<0 or VO>VDD
Continuous total power dissipation
Operating free-air temperature range, TA
Storage temperature, Tstg
)
–40
–65
125
150
°C
°C
(1) Stresses beyond those listed under Absolute Maximum Ratings may cause permanent damage to the device. These are stress ratings
only, which do not imply functional operation of the device at these or any other conditions beyond those indicated under Recommended
Operating Conditions. Exposure to absolute-maximum-rated conditions for extended periods may affect device reliability.
(2) All voltage values are with respect to GND. For reliable operation the device should not be operated at 7 V for more than t = 1000 h
continuously.
7.2 ESD Ratings
VALUE
±2000
±750
UNIT
Human-body model (HBM), per AEC Q100-002(1)
Charged-device model (CDM), per AEC Q100-011
V(ESD)
Electrostatic discharge
V
(1) AEC Q100-002 indicates that HBM stressing shall be in accordance with the ANSI/ESDA/JEDEC JS-001 specification.
7.3 Recommended Operating Conditions
over operating free-air temperature range (unless otherwise noted)
MIN
2
NOM
MAX
6
UNIT
VDD
TA
Supply voltage
V
Operating free-air temperature
–40
125
°C
7.4 Thermal Information
TPS3809xxx-Q1
DBV (SOT-23)
3 PINS
232.5
THERMAL METRIC(1)
UNIT
RθJA
Junction-to-ambient thermal resistance
°C/W
°C/W
°C/W
°C/W
°C/W
°C/W
RθJC(top)
RθJB
Junction-to-case (top) thermal resistance
Junction-to-board thermal resistance
187.6
104.1
ψJT
Junction-to-top characterization parameter
Junction-to-board characterization parameter
Junction-to-case (bottom) thermal resistance
40.5
ψJB
104.4
RθJC(bot)
N/A
(1) For more information about traditional and new thermal metrics, see the Semiconductor and IC Package Thermal Metrics application
report, SPRA953.
4
Submit Documentation Feedback
Copyright © 2008–2016, Texas Instruments Incorporated
Product Folder Links: TPS3809J25-Q1 TPS3809L30-Q1 TPS3809K33-Q1 TPS3809I50-Q1
TPS3809J25-Q1, TPS3809L30-Q1, TPS3809K33-Q1, TPS3809I50-Q1
www.ti.com
SGLS142B –JUNE 2008–REVISED MARCH 2016
7.5 Electrical Characteristics
over operating free-air temperature range (unless otherwise noted)
PARAMETER
TEST CONDITIONS
MIN
VDD – 0.2
VDD – 0.4
VDD – 0.4
VDD – 0.5
TYP
MAX
UNIT
VDD = 2.5 V to 6 V, IOH = −500 μA
VDD = 3.3 V, IOH = −2 μA
VOH
High-level output voltage
V
TA = −40°C to +25°C
VDD = 6 V, IOH = −4 mA
TA = 125°C
VDD = 2 V to 6 V, IOL = 500 μA
VDD = 3.3 V, IOL = 2 mA
VDD = 6 V, IOL = 4 mA
0.2
0.4
VOL
Low-level output voltage
Power-up reset voltage(1)
V
V
0.4
VDD ≥ 1.1 V, IOL = 50 μA
0.2
TPS3809J25-Q1
TPS3809L30-Q1
TPS3809K33-Q1
2.20
2.58
2.87
4.45
4.4
2.25
2.64
2.93
4.55
4.55
30
2.30
2.7
TA = −40°C to +125°C
Negative-going input threshold
voltage(2)
VIT−
2.99
4.65
4.65
V
TA = −40°C to +85°C
TA = −40°C to +125°C
TPS3809I50-Q1
TPS3809J25-Q1
TPS3809L30-Q1
TPS3809K33-Q1
TPS3809I50-Q1
35
Vhys
Hysteresis
mV
40
60
VDD = 2 V, Output unconnected
VDD = 6 V, Output unconnected
VI = 0 V to VDD
9
15
30
IDD
Ci
Supply current
μA
20
Input capacitance
5
pF
(1) The lowest supply voltage at which RESET becomes active. tr, VDD ≥ 15 µs/V.
(2) To ensure best stability of the threshold voltage, a bypass capacitor ( 0.1 µF, ceramic) should be placed near the supply terminals.
7.6 Timing Requirements
RL = 1 MΩ, CL = 50 pF, TA = 25°C
MIN
NOM
MAX
UNIT
tw
Pulse width at VDD
VDD = VIT− + 0.2 V, VDD = VIT− − 0.2 V
3
μs
7.7 Switching Characteristics
RL = 1 MΩ, CL = 50 pF, TA = 25°C
PARAMETER
TEST CONDITIONS
MIN
TYP
MAX UNIT
V
DD ≥ VIT− + 0.2 V, See
td
Delay time
120
200
280
ms
timing diagram, Figure 1
Propagation (delay) time,
high-to-low-level output
VIL = VIT− − 0.2 V, VIH = VIT−
+0.2 V
tPHL
VDD to RESET delay
1
μs
Copyright © 2008–2016, Texas Instruments Incorporated
Submit Documentation Feedback
5
Product Folder Links: TPS3809J25-Q1 TPS3809L30-Q1 TPS3809K33-Q1 TPS3809I50-Q1
TPS3809J25-Q1, TPS3809L30-Q1, TPS3809K33-Q1, TPS3809I50-Q1
SGLS142B –JUNE 2008–REVISED MARCH 2016
www.ti.com
V
DD
V
(NOM)
V
IT
1.1 V
t
RESET
1
0
t
t
t
d
d
For V < 1.1 V Undefined
DD
Behavior of RESET Output
Figure 1. Timing Diagram
6
Submit Documentation Feedback
Copyright © 2008–2016, Texas Instruments Incorporated
Product Folder Links: TPS3809J25-Q1 TPS3809L30-Q1 TPS3809K33-Q1 TPS3809I50-Q1
TPS3809J25-Q1, TPS3809L30-Q1, TPS3809K33-Q1, TPS3809I50-Q1
www.ti.com
SGLS142B –JUNE 2008–REVISED MARCH 2016
7.8 Typical Characteristics
2.75
50
T
= 25oC
A
V
DD
= 2.5 V
2.50
2.25
2.00
1.75
1.50
1.25
1.00
0.75
0.50
0.25
0
40
30
T
= 25oC
20
A
10
TPS3809J25
0
T
A
= 85oC
–10
–20
–30
–40
–50
T
= 0oC
A
T
A
= –40oC
0
2.5
5.0
7.5
10.0
12.5
–2
0
2
4
6
V
DD
– Supply Voltage – V
I
OL
– Low-Level Output Current – mA
Figure 3. Supply Current vs Supply Voltage
Figure 2. Low-Level Output Voltage vs
Low-Level Output Current
6.5
6.0
5.5
5.0
4.5
4.0
3.5
3.0
2.5
2.0
1.5
1.0
0.5
0
3.00
V
= 6 V
V
= 2.5 V
DD
DD
2.75
2.50
2.25
2.00
1.75
1.50
1.25
1.00
0.75
0.50
0.25
0
T
A
= –40oC
T
= –40oC
A
= 0oC
T
= 0oC
A
T
A
T
= 85oC
A
T
A
= 85oC
T
= 25oC
= 25oC
A
T
A
0
–10
–20
–30
–40
–50
0
–2
I – High-Level Output Current – mA
OH
–4
–6
–8
–10
I
– High-Level Output Current – mA
OH
VDD = 6 V
VDD = 2.5 V
Figure 4. High-Level Output Voltage vs
High-Level Output Current
Figure 5. High-Level Output Voltage vs
High-Level Output Current
1.001
1.000
0.999
0.998
0.997
0.996
0.995
3.5
V
DD
= 2.3 V
3.0
2.5
2.0
1.5
1.0
0.5
0
0
0.2
V – Threshold Overdrive Voltage – V
DD
0.4
0.6
0.8
1.0
–40
–20
0
20
40
60
85
T
A
– Free-Air Temperature – o
C
VDD = 2.3 V
Figure 6. Normalized Input Threshold Voltage vs
Free-Air Temperature at VDD
Figure 7. Minimum Pulse Duration at VDD vs
VDD Threshold Overdrive Voltage
Copyright © 2008–2016, Texas Instruments Incorporated
Submit Documentation Feedback
7
Product Folder Links: TPS3809J25-Q1 TPS3809L30-Q1 TPS3809K33-Q1 TPS3809I50-Q1
TPS3809J25-Q1, TPS3809L30-Q1, TPS3809K33-Q1, TPS3809I50-Q1
SGLS142B –JUNE 2008–REVISED MARCH 2016
www.ti.com
8 Detailed Description
8.1 Overview
The TPS3809xxx-Q1 device is a low-current supervisory circuit for monitoring system voltages above 2 V. The
device asserts an active-low RESET signal when VDD drops below a preset threshold. The RESET output
remains low until VDD returns above its threshold. The device design is also to be relatively immune to short
negative transients on the VDD pin.
8.2 Functional Block Diagram
TPS3809xxx-Q1
Reset
RESET
Logic
R1
_
+
+
V
DD
Timer
R2
GND
Oscillator
Reference
Voltage
of 1.137 V
8.3 Feature Description
8.3.1 VDD Monitoring
The VDD pin provides a terminal at which a system voltage can be monitored. If the voltage on this pin drops
below VIT, RESET is asserted low. The comparator has a built-in hysteresis to ensure smooth RESET assertions
and deassertions. Refer to Voltage Options to determine the VDD voltage threshold for each device.
8.4 Device Functional Modes
TPS3809xxx-Q1 monitors one supply using the VDD pin. When VDD is above the VIT threshold for the device,
RESET will be high. When VDD is below the VIT threshold for the device, RESET will be low.
8
Submit Documentation Feedback
Copyright © 2008–2016, Texas Instruments Incorporated
Product Folder Links: TPS3809J25-Q1 TPS3809L30-Q1 TPS3809K33-Q1 TPS3809I50-Q1
TPS3809J25-Q1, TPS3809L30-Q1, TPS3809K33-Q1, TPS3809I50-Q1
www.ti.com
SGLS142B –JUNE 2008–REVISED MARCH 2016
9 Application and Implementation
NOTE
Information in the following applications sections is not part of the TI component
specification, and TI does not warrant its accuracy or completeness. TI’s customers are
responsible for determining suitability of components for their purposes. Customers should
validate and test their design implementation to confirm system functionality.
9.1 Application Information
The TPS3809xxx-Q1 voltage supervisor device design asserts an active-low RESET signal when VDD drops
below a voltage threshold VIT. The RESET signal remains low until the voltage returns above its threshold. The
typical application is with a processor or microcontroller, which needs to be reset when the supply rail drops
below a specified tolerance.
9.2 Typical Application
TPS76333
3.3 V
OUT
5 V
IN
GND
V
DD
TMS320LC54x
V
DD
TPS3809K33-Q1
RESET
RESET
GND
GND
Figure 8. Typical Application Schematic
9.2.1 Design Requirements
Each device has a fixed=voltage monitoring threshold, and the device should be chosen based on the voltage
being monitored. Refer to Voltage Options to determine the VDD voltage threshold for each device. In this
example, a 3.3V supply rail to a microcontroller will be monitored.
9.2.2 Detailed Design Procedure
Because a 3.3-V supply rail needs to be monitored, TPS3809K33-Q1 should be used. This device has a 2.93-V
threshold for reset. Connect the 3.3-V supply to the VDD pin and the reset output of the supervisor to the reset pin
of the microcontroller.
Copyright © 2008–2016, Texas Instruments Incorporated
Submit Documentation Feedback
9
Product Folder Links: TPS3809J25-Q1 TPS3809L30-Q1 TPS3809K33-Q1 TPS3809I50-Q1
TPS3809J25-Q1, TPS3809L30-Q1, TPS3809K33-Q1, TPS3809I50-Q1
SGLS142B –JUNE 2008–REVISED MARCH 2016
www.ti.com
Typical Application (continued)
9.2.3 Application Curves
50
40
1.001
1.000
0.999
0.998
0.997
0.996
0.995
T
A
= 25oC
V
DD
= 2.3 V
30
20
10
TPS3809J25
0
–10
–20
–30
–40
–50
–2
0
2
4
6
–40
–20
0
20
40
60
85
– Free-Air Temperature – o
C
V
DD
– Supply Voltage – V
T
A
VDD = 2.3 V
Figure 9. Supply Current vs Supply Voltage
Figure 10. Normalized Input Threshold Voltage vs Free-Air
Temperature at VDD
10
Submit Documentation Feedback
Copyright © 2008–2016, Texas Instruments Incorporated
Product Folder Links: TPS3809J25-Q1 TPS3809L30-Q1 TPS3809K33-Q1 TPS3809I50-Q1
TPS3809J25-Q1, TPS3809L30-Q1, TPS3809K33-Q1, TPS3809I50-Q1
www.ti.com
SGLS142B –JUNE 2008–REVISED MARCH 2016
10 Power Supply Recommendations
The TPS3809xxx-Q1 device design operates from an input supply from 2 V to 6 V. TI recommends placing a 0.1-
µF capacitor near the VDD pin.
11 Layout
11.1 Layout Guidelines
TI recommends placing the 0.1-µF decoupling capacitor close to the VDD pin. The VDD and GND traces should be
able to carry 30 µA without a significant drop in voltage.
11.2 Layout Example
GND
CVDD
TPS3809xxx-Q1
VDD
RESET
Denotes GND Via
Figure 11. Layout Example
Copyright © 2008–2016, Texas Instruments Incorporated
Submit Documentation Feedback
11
Product Folder Links: TPS3809J25-Q1 TPS3809L30-Q1 TPS3809K33-Q1 TPS3809I50-Q1
TPS3809J25-Q1, TPS3809L30-Q1, TPS3809K33-Q1, TPS3809I50-Q1
SGLS142B –JUNE 2008–REVISED MARCH 2016
www.ti.com
12 Device and Documentation Support
12.1 Related Links
The table below lists quick access links. Categories include technical documents, support and community
resources, tools and software, and quick access to sample or buy.
Table 1. Related Links
TECHNICAL
DOCUMENTS
TOOLS &
SOFTWARE
SUPPORT &
COMMUNITY
PARTS
PRODUCT FOLDER
SAMPLE & BUY
TPS3809J25-Q1
TPS3809L30-Q1
TPS3809K33-Q1
TPS3809I50-Q1
Click here
Click here
Click here
Click here
Click here
Click here
Click here
Click here
Click here
Click here
Click here
Click here
Click here
Click here
Click here
Click here
Click here
Click here
Click here
Click here
12.2 Community Resources
The following links connect to TI community resources. Linked contents are provided "AS IS" by the respective
contributors. They do not constitute TI specifications and do not necessarily reflect TI's views; see TI's Terms of
Use.
TI E2E™ Online Community TI's Engineer-to-Engineer (E2E) Community. Created to foster collaboration
among engineers. At e2e.ti.com, you can ask questions, share knowledge, explore ideas and help
solve problems with fellow engineers.
Design Support TI's Design Support Quickly find helpful E2E forums along with design support tools and
contact information for technical support.
12.3 Trademarks
E2E is a trademark of Texas Instruments.
All other trademarks are the property of their respective owners.
12.4 Electrostatic Discharge Caution
These devices have limited built-in ESD protection. The leads should be shorted together or the device placed in conductive foam
during storage or handling to prevent electrostatic damage to the MOS gates.
12.5 Glossary
SLYZ022 — TI Glossary.
This glossary lists and explains terms, acronyms, and definitions.
13 Mechanical, Packaging, and Orderable Information
The following pages include mechanical, packaging, and orderable information. This information is the most
current data available for the designated devices. This data is subject to change without notice and revision of
this document. For browser-based versions of this data sheet, refer to the left-hand navigation.
12
Submit Documentation Feedback
Copyright © 2008–2016, Texas Instruments Incorporated
Product Folder Links: TPS3809J25-Q1 TPS3809L30-Q1 TPS3809K33-Q1 TPS3809I50-Q1
PACKAGE OPTION ADDENDUM
www.ti.com
22-Dec-2016
PACKAGING INFORMATION
Orderable Device
2T09I50QDBVRG4Q
Status Package Type Package Pins Package
Eco Plan
Lead/Ball Finish
MSL Peak Temp
Op Temp (°C)
-40 to 125
-40 to 125
-40 to 125
-40 to 125
-40 to 125
-40 to 125
-40 to 125
-40 to 125
Device Marking
Samples
Drawing
Qty
(1)
(2)
(6)
(3)
(4/5)
ACTIVE
SOT-23
SOT-23
SOT-23
SOT-23
SOT-23
SOT-23
SOT-23
SOT-23
DBV
3
3
3
3
3
3
3
3
3000
Green (RoHS
& no Sb/Br)
CU NIPDAU
CU NIPDAU
CU NIPDAU
CU NIPDAU
CU NIPDAU
CU NIPDAU
CU NIPDAU
CU NIPDAU
Level-1-260C-UNLIM
Level-1-260C-UNLIM
Level-1-260C-UNLIM
Level-1-260C-UNLIM
Level-1-260C-UNLIM
Level-1-260C-UNLIM
Level-1-260C-UNLIM
Level-1-260C-UNLIM
PDCQ
2T09J25QDBVRG4Q
2U3809K33QDBVRG4Q1
2U3809L30QDBVRG4Q1
TPS3809I50QDBVRQ1
TPS3809J25QDBVRQ1
TPS3809K33QDBVRQ1
TPS3809L30QDBVRQ1
LIFEBUY
LIFEBUY
LIFEBUY
ACTIVE
LIFEBUY
ACTIVE
ACTIVE
DBV
DBV
DBV
DBV
DBV
DBV
DBV
3000
3000
3000
3000
3000
3000
3000
Green (RoHS
& no Sb/Br)
PCZQ
PDBQ
PDAQ
PDCQ
PCZQ
PDBQ
PDAQ
Green (RoHS
& no Sb/Br)
Green (RoHS
& no Sb/Br)
Green (RoHS
& no Sb/Br)
Green (RoHS
& no Sb/Br)
Green (RoHS
& no Sb/Br)
Green (RoHS
& no Sb/Br)
(1) The marketing status values are defined as follows:
ACTIVE: Product device recommended for new designs.
LIFEBUY: TI has announced that the device will be discontinued, and a lifetime-buy period is in effect.
NRND: Not recommended for new designs. Device is in production to support existing customers, but TI does not recommend using this part in a new design.
PREVIEW: Device has been announced but is not in production. Samples may or may not be available.
OBSOLETE: TI has discontinued the production of the device.
(2) Eco Plan - The planned eco-friendly classification: Pb-Free (RoHS), Pb-Free (RoHS Exempt), or Green (RoHS & no Sb/Br) - please check http://www.ti.com/productcontent for the latest availability
information and additional product content details.
TBD: The Pb-Free/Green conversion plan has not been defined.
Pb-Free (RoHS): TI's terms "Lead-Free" or "Pb-Free" mean semiconductor products that are compatible with the current RoHS requirements for all 6 substances, including the requirement that
lead not exceed 0.1% by weight in homogeneous materials. Where designed to be soldered at high temperatures, TI Pb-Free products are suitable for use in specified lead-free processes.
Pb-Free (RoHS Exempt): This component has a RoHS exemption for either 1) lead-based flip-chip solder bumps used between the die and package, or 2) lead-based die adhesive used between
the die and leadframe. The component is otherwise considered Pb-Free (RoHS compatible) as defined above.
Green (RoHS & no Sb/Br): TI defines "Green" to mean Pb-Free (RoHS compatible), and free of Bromine (Br) and Antimony (Sb) based flame retardants (Br or Sb do not exceed 0.1% by weight
in homogeneous material)
(3) MSL, Peak Temp. - The Moisture Sensitivity Level rating according to the JEDEC industry standard classifications, and peak solder temperature.
Addendum-Page 1
PACKAGE OPTION ADDENDUM
www.ti.com
22-Dec-2016
(4) There may be additional marking, which relates to the logo, the lot trace code information, or the environmental category on the device.
(5) Multiple Device Markings will be inside parentheses. Only one Device Marking contained in parentheses and separated by a "~" will appear on a device. If a line is indented then it is a continuation
of the previous line and the two combined represent the entire Device Marking for that device.
(6) Lead/Ball Finish - Orderable Devices may have multiple material finish options. Finish options are separated by a vertical ruled line. Lead/Ball Finish values may wrap to two lines if the finish
value exceeds the maximum column width.
Important Information and Disclaimer:The information provided on this page represents TI's knowledge and belief as of the date that it is provided. TI bases its knowledge and belief on information
provided by third parties, and makes no representation or warranty as to the accuracy of such information. Efforts are underway to better integrate information from third parties. TI has taken and
continues to take reasonable steps to provide representative and accurate information but may not have conducted destructive testing or chemical analysis on incoming materials and chemicals.
TI and TI suppliers consider certain information to be proprietary, and thus CAS numbers and other limited information may not be available for release.
In no event shall TI's liability arising out of such information exceed the total purchase price of the TI part(s) at issue in this document sold by TI to Customer on an annual basis.
OTHER QUALIFIED VERSIONS OF TPS3809-Q1, TPS3809I50-Q1, TPS3809J25-Q1, TPS3809K33-Q1, TPS3809L30-Q1 :
Catalog: TPS3809I50, TPS3809J25, TPS3809K33, TPS3809L30
•
Enhanced Product: TPS3809-EP, TPS3809I50-EP, TPS3809K33-EP, TPS3809L30-EP
•
NOTE: Qualified Version Definitions:
Catalog - TI's standard catalog product
•
Enhanced Product - Supports Defense, Aerospace and Medical Applications
•
Addendum-Page 2
PACKAGE MATERIALS INFORMATION
www.ti.com
22-Dec-2016
TAPE AND REEL INFORMATION
*All dimensions are nominal
Device
Package Package Pins
Type Drawing
SPQ
Reel
Reel
A0
B0
K0
P1
W
Pin1
Diameter Width (mm) (mm) (mm) (mm) (mm) Quadrant
(mm) W1 (mm)
2T09I50QDBVRG4Q
2T09J25QDBVRG4Q
SOT-23
SOT-23
DBV
DBV
DBV
DBV
DBV
DBV
DBV
DBV
3
3
3
3
3
3
3
3
3000
3000
3000
3000
3000
3000
3000
3000
180.0
180.0
180.0
180.0
180.0
180.0
180.0
180.0
9.0
9.0
9.0
9.0
9.0
9.0
9.0
9.0
3.3
3.3
3.3
3.3
3.3
3.3
3.3
3.3
3.2
3.2
3.2
3.2
3.2
3.2
3.2
3.2
1.47
1.47
1.47
1.47
1.47
1.47
1.47
1.47
4.0
4.0
4.0
4.0
4.0
4.0
4.0
4.0
8.0
8.0
8.0
8.0
8.0
8.0
8.0
8.0
Q3
Q3
Q3
Q3
Q3
Q3
Q3
Q3
2U3809K33QDBVRG4Q1 SOT-23
2U3809L30QDBVRG4Q1 SOT-23
TPS3809I50QDBVRQ1 SOT-23
TPS3809J25QDBVRQ1 SOT-23
TPS3809K33QDBVRQ1 SOT-23
TPS3809L30QDBVRQ1 SOT-23
Pack Materials-Page 1
PACKAGE MATERIALS INFORMATION
www.ti.com
22-Dec-2016
*All dimensions are nominal
Device
Package Type Package Drawing Pins
SPQ
Length (mm) Width (mm) Height (mm)
2T09I50QDBVRG4Q
2T09J25QDBVRG4Q
SOT-23
SOT-23
SOT-23
SOT-23
SOT-23
SOT-23
SOT-23
SOT-23
DBV
DBV
DBV
DBV
DBV
DBV
DBV
DBV
3
3
3
3
3
3
3
3
3000
3000
3000
3000
3000
3000
3000
3000
182.0
182.0
182.0
182.0
182.0
182.0
182.0
182.0
182.0
182.0
182.0
182.0
182.0
182.0
182.0
182.0
20.0
20.0
20.0
20.0
20.0
20.0
20.0
20.0
2U3809K33QDBVRG4Q1
2U3809L30QDBVRG4Q1
TPS3809I50QDBVRQ1
TPS3809J25QDBVRQ1
TPS3809K33QDBVRQ1
TPS3809L30QDBVRQ1
Pack Materials-Page 2
IMPORTANT NOTICE
Texas Instruments Incorporated and its subsidiaries (TI) reserve the right to make corrections, enhancements, improvements and other
changes to its semiconductor products and services per JESD46, latest issue, and to discontinue any product or service per JESD48, latest
issue. Buyers should obtain the latest relevant information before placing orders and should verify that such information is current and
complete. All semiconductor products (also referred to herein as “components”) are sold subject to TI’s terms and conditions of sale
supplied at the time of order acknowledgment.
TI warrants performance of its components to the specifications applicable at the time of sale, in accordance with the warranty in TI’s terms
and conditions of sale of semiconductor products. Testing and other quality control techniques are used to the extent TI deems necessary
to support this warranty. Except where mandated by applicable law, testing of all parameters of each component is not necessarily
performed.
TI assumes no liability for applications assistance or the design of Buyers’ products. Buyers are responsible for their products and
applications using TI components. To minimize the risks associated with Buyers’ products and applications, Buyers should provide
adequate design and operating safeguards.
TI does not warrant or represent that any license, either express or implied, is granted under any patent right, copyright, mask work right, or
other intellectual property right relating to any combination, machine, or process in which TI components or services are used. Information
published by TI regarding third-party products or services does not constitute a license to use such products or services or a warranty or
endorsement thereof. Use of such information may require a license from a third party under the patents or other intellectual property of the
third party, or a license from TI under the patents or other intellectual property of TI.
Reproduction of significant portions of TI information in TI data books or data sheets is permissible only if reproduction is without alteration
and is accompanied by all associated warranties, conditions, limitations, and notices. TI is not responsible or liable for such altered
documentation. Information of third parties may be subject to additional restrictions.
Resale of TI components or services with statements different from or beyond the parameters stated by TI for that component or service
voids all express and any implied warranties for the associated TI component or service and is an unfair and deceptive business practice.
TI is not responsible or liable for any such statements.
Buyer acknowledges and agrees that it is solely responsible for compliance with all legal, regulatory and safety-related requirements
concerning its products, and any use of TI components in its applications, notwithstanding any applications-related information or support
that may be provided by TI. Buyer represents and agrees that it has all the necessary expertise to create and implement safeguards which
anticipate dangerous consequences of failures, monitor failures and their consequences, lessen the likelihood of failures that might cause
harm and take appropriate remedial actions. Buyer will fully indemnify TI and its representatives against any damages arising out of the use
of any TI components in safety-critical applications.
In some cases, TI components may be promoted specifically to facilitate safety-related applications. With such components, TI’s goal is to
help enable customers to design and create their own end-product solutions that meet applicable functional safety standards and
requirements. Nonetheless, such components are subject to these terms.
No TI components are authorized for use in FDA Class III (or similar life-critical medical equipment) unless authorized officers of the parties
have executed a special agreement specifically governing such use.
Only those TI components which TI has specifically designated as military grade or “enhanced plastic” are designed and intended for use in
military/aerospace applications or environments. Buyer acknowledges and agrees that any military or aerospace use of TI components
which have not been so designated is solely at the Buyer's risk, and that Buyer is solely responsible for compliance with all legal and
regulatory requirements in connection with such use.
TI has specifically designated certain components as meeting ISO/TS16949 requirements, mainly for automotive use. In any case of use of
non-designated products, TI will not be responsible for any failure to meet ISO/TS16949.
Products
Applications
Audio
www.ti.com/audio
amplifier.ti.com
dataconverter.ti.com
www.dlp.com
Automotive and Transportation www.ti.com/automotive
Communications and Telecom www.ti.com/communications
Amplifiers
Data Converters
DLP® Products
DSP
Computers and Peripherals
Consumer Electronics
Energy and Lighting
Industrial
www.ti.com/computers
www.ti.com/consumer-apps
www.ti.com/energy
dsp.ti.com
Clocks and Timers
Interface
www.ti.com/clocks
interface.ti.com
logic.ti.com
www.ti.com/industrial
www.ti.com/medical
Medical
Logic
Security
www.ti.com/security
Power Mgmt
Microcontrollers
RFID
power.ti.com
Space, Avionics and Defense
Video and Imaging
www.ti.com/space-avionics-defense
www.ti.com/video
microcontroller.ti.com
www.ti-rfid.com
www.ti.com/omap
OMAP Applications Processors
Wireless Connectivity
TI E2E Community
e2e.ti.com
www.ti.com/wirelessconnectivity
Mailing Address: Texas Instruments, Post Office Box 655303, Dallas, Texas 75265
Copyright © 2016, Texas Instruments Incorporated
厂商 型号 描述 页数 下载

TI

 		2U3809L30QDBVRG4Q1 [ 3-Pin Supply Voltage Supervisors for Automotive 3-SOT-23 -40 to 125 ] 9 页

TI

 		2U3820-50QDBVRG4Q1 处理器监控电路[ PROCESSOR SUPERVISORY CIRCUITS ] 14 页

TI

 		2U3823-25QDBVRG4Q1 处理器监控电路[ PROCESSOR SUPERVISORY CIRCUITS ] 14 页

TI

 		2U3823-30QDBVRG4Q1 处理器监控电路[ PROCESSOR SUPERVISORY CIRCUITS ] 14 页

TI

 		2U3823-33QDBVRG4Q1 处理器监控电路[ PROCESSOR SUPERVISORY CIRCUITS ] 14 页

TI

 		2U3823-50QDBVRG4Q1 处理器监控电路[ PROCESSOR SUPERVISORY CIRCUITS ] 14 页

TI

 		2U3824-25QDBVRG4Q1 处理器监控电路[ PROCESSOR SUPERVISORY CIRCUITS ] 14 页

TI

 		2U3824-33QDBVRG4Q1 处理器监控电路[ PROCESSOR SUPERVISORY CIRCUITS ] 14 页

TI

 		2U3824-50QDBVRG4Q1 处理器监控电路[ PROCESSOR SUPERVISORY CIRCUITS ] 14 页

TI

 		2U3825-33QDBVRG4Q1 处理器监控电路[ PROCESSOR SUPERVISORY CIRCUITS ] 14 页

购物指南

支付方式

配送服务

售后服务

发票须知

优惠券使用规则

特色服务

PCBA制造

国产品牌推荐

国产料号替代

质量保证

技术资料

行业资讯

关于我们

关于壹壹捌

联系我们

联系我们

服务热线：400-618-9990

企业邮箱：sales@ic118.com

服务时间：周一至周六 8:30-17:30

壹壹捌官方微信号

PDF索引：

A

B

C

D

E

F

G

H

I

J

K

L

M

N

O

P

Q

R

S

T

U

V

W

X

Y

Z

0

1

2

3

4

5

6

7

8

9

IC型号索引：

A

B

C

D

E

F

G

H

I

J

K

L

M

N

O

P

Q

R

S

T

U

V

W

X

Y

Z

0

1

2

3

4

5

6

7

8

9

Copyright 2024 gkzhan.com Al Rights Reserved 京ICP备06008810号-21 京

深圳网络警察报警平台
公共信息安全网络监察
经营性网站备案信息
不良信息举报中心
工商网监电子标识
全国公安机关备案
0.193875s
