VUO 27
IdAV = 28 A
VRRM = 600-1200 V
Three Phase Rectifier Bridge
Preliminary data
D
VRSM
V
VRRM
V
Type
N
A
H
700
900
1300
600
800
1200
VUO 27-06NO7
VUO 27-08NO7
VUO 27-12NO7
K
Symbol
Conditions
Maximum Ratings
Features
• Package with DCB ceramic base plate
• Isolation voltage 3000 V~
• Planar passivated chips
IdAV
IFSM
①
TC = 100°C, module
28
A
TVJ = 45°C; t = 10 ms (50 Hz), sine
100
106
A
A
VR = 0;
t = 8.3 ms (60 Hz), sine
• Low forward voltage drop
• Leads suitable for PC board soldering
TVJ = TVJM
VR = 0;
;
t = 10 ms (50 Hz), sine
t = 8.3 ms (60 Hz), sine
85
90
A
A
Applications
I2t
TVJ = 45°C; t = 10 ms (50 Hz), sine
50
47
A2s
A2s
• Supplies for DC power equipment
• Input rectifiers for PWM inverter
• Battery DC power supplies
VR = 0;
t = 8.3 ms (60 Hz), sine
TVJ = TVJM
VR = 0;
;
t = 10 ms (50 Hz), sine
t = 8.3 ms (60 Hz), sine
36
33
A2s
A2s
• Field supply for DC motors
TVJ
TVJM
Tstg
-40...+150
150
-40...+125
°C
°C
°C
Advantages
• Easy to mount with two screws
• Space and weight savings
• Improved temperature and power
cycling capability
VISOL
50/60 Hz, RMS; t = 1 min
ISOL ≤ 1 mA; t = 1 s
2500
3000
V~
V~
I
• Small and light weight
Md
Mounting torque (M4)
1.5 - 2
Nm
14 - 18
lb.in.
Weight
typ.
18
g
Dimensions in mm (1 mm = 0.0394")
10,8
10,8
Symbol
IR
Conditions
Characteristic Values
I
J
KL
H
M
N
VR = VRRM; TVJ = 25°C
VR = VRRM; TVJ = TVJM
≤
≤
0.3
5
mA
mA
5
1
6
2
8
4
7
3
VF
IF = 7 A; TVJ = 25°C
≤
1.12
V
VT0
rT
For power-loss calculations only
0.8
40
V
mΩ
A
B
C
DE
F
G
RthJC
RthJH
per diode; DC current
per module
per diode, DC current
per module
2.3
0.39
2.8
K/W
K/W
K/W
K/W
R0,75
0.47
dS
dA
a
Creeping distance on surface
Creepage distance in air
Max. allowable acceleration
11.2
9.7
50
mm
mm
39
47
m/s2
Data according to IEC 60747 refer to a single diode unless otherwise stated
① for resistive load at bridge output.
IXYS reserves the right to change limits, test conditions and dimensions.
© 2003 IXYS All rights reserved
1 - 1
