IXS839BD2

型号：

IXS839BD2

品牌：

LITTELFUSE[ LITTELFUSE ]

页数：

13 页

PDF大小：

394 K

下载PDF手册
IXYS
IXS839 / IXS839A / IXS839B
Synchronous Buck MOSFET Driver
Features:
General Description
The IXS839/IXS839A/IXS839B are 2A Source / 4A
Sink Synchronous Buck MOSFET Drivers. These
Synchronous Buck MOSFET Drivers are specifically
designed to drive two N-channel power MOSFETs
in a synchronous buck converter. The High-Side
driver is powered via a bootstrapped power
connection. The driver is capable of 20ns High-Side
output, and 18ns Low-Side output transition times
driving a 3000pF load.
• Logic Level Gate Drive Compatible
• 2A Source, 4A Sink Peak Drive Current
• Programmable High-Side Driver Turn-on Delay
• Supports Floating Voltage for Top Driver Up to
24V
• IXS839/839B: Undervoltage Lockout
• IXS839A/B: Output Shutdown, Low Side
Shutdown Inputs
The IXS839 and IXS839B incorporate an
undervoltage lockout to prevent unintentional gate
drive output during low voltage conditions. The
IXS83A/B include External Shutdown and Low-Side
Drive Shutdown features. Simultaneous shutdown
of both outputs prevents rapid output capacitor
discharge. The high-side turn-on delay is adjustable
with an external capacitor added at the DLY pin.
• 10µA Shut Down Current
• 2mA Quiescent Current (Non- Switching)
• Bootstrapped High Side Driver
• Cross-Conduction Protection
Applications:
• Multiphase Desktop CPU Supplies
• Mobile CPU Core Voltage supplies
The IXS839/839A/839B are designed to operate
over a temperature range of -40°C to +85°C. The
IXS839 is available in an 8-Lead SOIC, the
IXS839A and the IXS839B in a 10-pin QFN.
• High Current / Low Voltage DC/DC
Synchronous Buck Converters
Figure 1. IXS839 Functional Block Diagram
and General Application Circuit
Figure 2. IXS839A Functional Block Diagram
and General Application Circuit
5V
VDD
VIN
5V
VDD
VIN
8
4
DBST
DBST
BST
HGD
SW
UVLO
BST
HGD
SW
3
2
1
8
Q1
SD
Q1
4
5
PWM
OVERLAP
PROTECTION
CIRCUIT
OVERLAP
PROTECTION
CIRCUIT
2
3
CBST
CBST
PWM
1
7
VOUT
VOUT
DLY
DLY
7
LGD
LGD
Q2
Q2
9
5
6
CDLY
CDLY
PGND
PGND
10
6
LSD
Copyright © IXYS CORPORATION 2005
9/9/2005
IXS839 / IXS839A / IXS839B
IXYS
Figure 3. IXS839B Functional Block Diagram and General Application Circuit
5V
VDD
VIN
5
DBST
UVLO
BST
HGD
SW
10
9
Q1
SD
1
2
OVERLAP
PROTECTION
CIRCUIT
CBST
PWM
8
VOUT
DLY
4
3
LGD
Q2
6
7
CDLY
PGND
LSD
Ordering Information
Part No.
Description
Package
Pack Quantity
Under Voltage Lockout
Under Voltage Lockout
Under Voltage Lockout
IXS839S1
IXS839S1T/R
IXS839D1
8-Pin SOIC 98 (Tube)
8-Pin SOIC 2500 (Tape & Reel)
Tested Die
Driver Shutdown, Low Side Shutdown
Driver Shutdown, Low Side Shutdown
Driver Shutdown, Low Side Shutdown
IXS839AQ2
IXS839AQ2T/R
IXS839AD2
IXS839BQ2
IXS839BQ2T/R
IXS839BD2
10-Pin QFN 121 (Tube)
10-Pin QFN 2000 (Tape & Reel)
Tested Die
10-Pin QFN 121 (Tube)
10-Pin QFN 2000 (Tape & Reel)
Tested Die
Under Voltage Lockout , Driver Shutdown, Low Side Shutdown
Under Voltage Lockout , Driver Shutdown, Low Side Shutdown
Under Voltage Lockout , Driver Shutdown, Low Side Shutdown
Absolute Maximum Ratings
Parameter
VDD
Rating
Absolute Maximum Ratings are stress ratings.
Stresses in excess of these ratings can cause
permanent damage to the device. Functional
operation of the device at these or any other
conditions beyond those indicated in the operational
sections of this data sheet is not implied. Exposure
of the device to the absolute maximum ratings for
an extended period may degrade the device and
affect its reliability.
-0.3V to +7V
-0.3V to +30V
-0.3V to +7V
-0.2V to +24V
-0.3V to +7V
-40°C to +85°C
-40°C to +125°C
150°C/W
BST
BST to SW
SW
PWM
Operating Ambient Temp Range
Operating Junction Temp Range
θJA
θJC
40°C/W
Storage Temp Range
-65°C to +150°C
Lead Temperature (Soldering, 10 sec) +300°C
ESD Warning
ESD (electrostatic discharge) sensitive device. Electrostatic charges can readily accumulate on test equipment and the human body
in excess of 4000 Volts. This energy can discharge without detection. Although the IXS839/839A/839B feature proprietary ESD
protection circuitry, permanent damage may be sustained if subjected to high energy electrostatic discharges. Proper ESD
precautions are recommended to avoid performance degradation or loss of functionality.
2
IXS839 / IXS839A / IXS839B
IXYS
Pin Description and Configurations
IXS839 IXS839A IXS839B
Name
Description
Upper Gate Driver Floating DC Power Terminal for Bootstrap
Capacitor Connection.
1
2
3
5
10
2
BST
TTL-level Input Signal with active pull-down. PWM input to the
Gate Drivers.
PWM
DLY
Terminal for External Delay Capacitor Connection. Capacitor
to Ground at this pin adds propagation delay from Lower Gate
Driver going Low to the Upper Gate Driver going High.
3
4
7
8
4
5
t
DLY (nS) = CDLY (pF) x (0.5nS/pF)
Positive Supply Terminal for Logic and Lower Gate Driver. A
ceramic bypass capacitor of 1uF should be connected from
VDD to PGND.
VDD
Lower Gate Driver Output Terminal
5
6
7
8
9
10
1
6
7
8
9
LGD
PGND
SW
Lower Gate Driver DC Power Return Terminal, Logic and
Analog Ground
Upper Gate Driver Floating DC Power Return Terminal
Upper Gate Driver Output Terminal
2
HGD
__
SD
TTL-level Shut Down Input Signal with active pull-up.
SD enables normal operation when high. When SD is low,
the driver outputs are forced low and IDD is at its minimum.
N/A
N/A
4
6
1
3
___
LSD
TTL-level Low Side Shut Down Input Signal with active pull-
up. LSD, when low forces the Lower Gate Driver output low.
When LSD is high, the lower Gate Driver output is enabled.
SOIC and QFN Top View Pin Configurations
SW
1
PGND
LGD
10
9
SD
1
2
10 BST
8
7
HGD
SW
BST 1
PWM 2
DLY 3
VDD 4
PWM
HGD
BST
HGD
9
IXS839BQ2
2
IXS839AQ2
IXS839S1
8
8
SW
3
4
5
3
4
5
VDD
DLY
LSD
DLY
PGND
LGD
6
5
PGND
SD
7
6
7
6
PWM
LGD
LSD
VDD
3
IXS839 / IXS839A / IXS839B
IXYS
Electrical Characteristics
Power Supply Terminals
TA = -40°C to 85°C, VDD = 5V, 4V < VBST < 26V
Parameter
Symbol
Conditions
Min Typ Max Unit
Analog Supply
Voltage Range
High Gate Driver
Supply Voltage Range
Low Gate Driver
Supply Voltage Range
Floating Supply
Voltage Range
Analog Supply
Current
VDD
VDD
4.5
4.5
4.5
0.0
5.5
5.5
5.5
24.0
4
V
V
VBST - VSW
VDD - VPGND
VSW - VPGDN
V
V
Normal Mode
PWM = VPGND
IDD
2
mA
mA
IXS839/839B
IXS839A
0.5
1
1.5
High Gate Driver
Supply Current
Normal Mode
PWM = VPGND
IBST
IXS839/839B
IXS839A
10
50
Analog Supply
Current
Shut Down Mode, LSD = VDD,
SD = PWM = VPGND
IDD_Shutdown
IBST_Shutdown
µA
µA
High Gate Driver
Supply Current
Shut Down Mode
LSD = PWM = VPGND
<1
10
Digital Input Terminals
Parameter
TA = -40°C to 85°C, VDD = 5V, 4V < VBST < 26V
Symbol
Conditions
Min
Typ
Max
Unit
PWM = VPGND
LSD = SD = VDD
Input Leakage Current
IIN
-1
1
µA
Input pull-down Current
PWM = VDD
2
10
100
µA
µA
__
Input pull-up Current
Input pull-up Current
-2
-10
-100
SD = VPGND
___
LSD = VPGND
-2
-10
-100
µA
Minimum High Level
Input Voltage
Maximum Low Level
Input Voltage
VIH
VIL
2.0
V
V
0.8
UVLO Circuit
TA = -40°C to 85°C, VDD = 5V, 4V < VBST < 26V
Parameter
VDD Rising Threshold
VDD Falling Threshold
Symbol
UVOLRISE
UVOLFALL
Conditions
Min
4.2
3.9
Typ
4.4
4.25
Max
4.5
4.5
Unit
V
V
Delay Circuit
Parameter
TA = -40°C to 85°C, VDD = 5V, 4V < VBST < 26V
Symbol
Conditions
Min
Typ
Max
Unit
Upper Gate-Driver Turn
on Delay Time with
respect to external delay
capacitor
Capacitor CDLY(pF) from DLY
pin to PGND
tDLY
0.5
nS/pF
4
IXS839 / IXS839A / IXS839B
IXYS
Electrical Characteristics
High Side Gate Driver Circuit
TA = -40°C to 85°C, VDD = 5V, 4V < VBST < 26V
Parameter
Symbol
Conditions
Min
Typ
Max
Unit
High Side Gate-Driver
On-Resistance, Sourcing RHGD_SRC
Current
VBST – VSW = 4.6V
2.2
Ω
High Side Gate-Driver
On-Resistance, Sinking
Current
RHGD_SNK
VBST – VSW = 4.6V
1.2
20
15
Ω
CLOAD = 3nF
TR_HGD measured from 10% to
90% of (VHGD - VSW
CLOAD = 3nF
TF_HGD measured from 90% to
10% of (VHGD - VSW
High Side Gate-Driver(1)
Rise-Time
tR_HGD
nS
nS
)
High Side Gate-Driver(1)
Fall-Time
tF_HGD
)
35
50
nS
nS
tPD_HGD1
tPD_HGD2
CLOAD_HGD = CLOAD_LGD = 3nF
CDLY = 0pF
Propagation Delay(1)
Low Side Gate Driver Circuit
TA = -40°C to 85°C, VDD = 5V, 4V < VBST < 26V
Parameter
Symbol
Conditions
Min
Typ
Max
Unit
Low Side Gate-Driver
On-Resistance, Sourcing RLGD_SRC
Current
VDD – VPGND = 4.6V
2
Ω
Low Side Gate-Driver
On-Resistance, Sinking
Current
RLGD_SNK
VDD – VPGND = 4.6V
CLOAD = 3nF
1
Ω
Low Side Gate-Driver(1)
Rise-Time
tR_LGD
T
R_LGD measured from 10% to
18
12
nS
nS
90% of (VLGD – VPGND
CLOAD = 3nF
)
Low Side Gate-Driver(1)
Fall-Time
tF_LGD
T
F_LGD measured from 90% to
10% of (VLGD - VSW
CLOAD_HGD = CLOAD_LGD = 3nF
DLY = 0pF
)
60
20
nS
nS
tPD_LGD1
tPD_LGD2
Propagation Delay(1)
C
Shut Down Circuit Characteristics
TA = -40°C to 85°C, VDD = 5V, 4V < VBST < 26V
Parameter
Symbol
tPD_LGDSD1
tPD_LGDSD2
tPD_GDSD1
tPD_GDSD2
Conditions
Min
Typ
25
10
400
800
Max
50
20
800
1200
Unit
nS
nS
nS
nS
Propagation Delay(2)
Propagation Delay(2)
Propagation Delay(3)
Propagation Delay(3)
*Notes:
(1) See Timing Diagram in Figure 4
(2) See Timing Diagram in Figure 5
(3) See Timing Diagram in Figure 6
5
IXS839 / IXS839A / IXS839B
IXYS
Figure 4. Non-Overlap Timing Diagram for IXS839/839A/839B
PWM
tpd_lgd2
LGD
tpd_hgd2
tf_lgd
10%
tr_lgd
90%
tpd_lgd1
tr_hgd
90%
tf_hgd
tpd_hgd1
HGD-SW
10%
___
__
Figure 5. LSD Propagation Delay Timing
for IXS839A/B
Figure 6. SD Propagation Delay Timing
for IXS839A/B
LSD
10%
SD
10%
tpd_lgdsd2
tpd_gdsd2
tpd_lgdsd1
LGD
tpd_gdsd1
LGD/HGD
90%
90%
6
IXS839 / IXS839A / IXS839B
IXYS
IXS839 and IXS839B Die Size and Pad Locations:
Passivation Opening
Location (1)
X (um)
Ref. No.
Signal Name
HGD
HGD
SW
Signal Type
X (um)
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
N/A
N/A
N/A
N/A
N/A
N/A
100
100
Y (um)
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
N/A
N/A
N/A
N/A
N/A
N/A
100
100
Y (um)
266
412
598
744
968
1461
1608
1644
1644
1644
1644
1464
1237
899
672
477
280
N/A
N/A
N/A
N/A
N/A
N/A
0
1
2
3
4
5
6
7
8
Digital Output
Digital Output
Power Supply
Power Supply
Power Supply
Power Supply
Power Supply
Digital Output
Digital Output
Power Supply
Power Supply
2
2
2
2
0
2
2
SW
VSS
PGND
PGND
LGD
LGD
VDD
VDD
590
737
903
1050
1283
1283
1283
1283
1283
1283
N/A
N/A
N/A
N/A
N/A
N/A
337
190
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
PRDY (Power Ready) Digital Output
DLY
SMOD (LSD BAR)
PWM
VSS
SD (SDI BAR)
VBG
TST
T0
T1
Digital I/O
Digital Input
Digital Input
Power Supply
Digital Input
No Connect
No Connect
No Connect
No Connect
No Connect
No Connect
Power Supply
Power Supply
T2
TGND
BST
BST
0
Notes:
(1) Location is the distance from origin to the center of the passivation opening.
7
IXS839 / IXS839A / IXS839B
IXYS
IXS839A Die Size and Pad Locations:
Passivation Opening
Location (1)
X (um)
0
56
534
673
953
936
940
893
508
282
57
Ref. No.
Signal Name
HGD
SW
VSS
PGND
PGND
LGD
VDD
DLY
SMOD (LSD BAR)
PWM
PDB (SDI BAR)
BST
Signal Type
X (um)
81
190
81
Y (um)
190
81
Y (um)
598
1211
1268
1268
1083
586
243
18
0
0
7
307
1
2
3
4
5
6
7
8
9
Digital Output
Power Supply
Power Supply
Power Supply
Power Supply
Digital Output
Power Supply
Digital I/O
Digital Input
Digital Input
Digital Input
Power Supply
81
81
81
81
81
81
81
190
190
100
115
115
100
190
100
100
100
100
81
10
11
12
0
Notes:
(1) Location is the distance from origin to the center of the passivation opening.
8
IXS839 / IXS839A / IXS839B
IXYS
Typical Performance Characteristics
Fig 7. HGD Fall and LGD Rise Times
Fig 8. LGD Fall and HGD Rise Times
25
20
25
20
15
15
HGD
HGD
10
5
0
10
LGD
LGD
5
Vdd=5V
Vdd=5V
Cl=3nF
Cl=3nF
0
-40
-15
10
35
60 85
-40
-15
10
35
Ta (°C)
60 85
Ta (°C)
Fig 9. HGD & LGD Rise Time vs. Temperature
Fig 10. HGD & LGD Fall Time vs. Temperature
25
20
25
20
HGD
15
15
HGD
10
10
LGD
LGD
5
5
Vdd=5V
Ta=25C
Vdd=5V
Ta=25C
0
0
1.0
1.0
2.0
3.0
4.0
5.0
2.0
3.0
Capacitance (nF)
4.0 5.0
Capacitance (nF)
Fig 11. HGD and LGD Rise Time vs. Load Capacitance
Fig 12. HGD and LGD Fall Time vs. Load Capacitance
9
IXS839 / IXS839A / IXS839B
IXYS
Typical Performance Characteristics
50
50
40
40
30
20
10
0
Tpd_lgd1
Tpd_hgd2
30
20
10
0
Tpd_hgd1
Vdd=5V
Cl=3nF
Vdd=5V
Cl=3nF
Tpd_lgd2
-40
-15
10
35
60
85
-40
-15
10
35
60
85
Ta (°C)
Ta (°C)
Fig 13. HGD Propagation Delay vs. Temperature
Fig 14. LGD Propagation Delay vs. Temperature
120
90
20
15
60
10
Vdd=5V
Ta=25C
30
5
250kHz
Vdd=5V
Cl=3nF
Cl=3nF
0
0
-40
-15
10
35
60 85
0
500
1000 1500 2000
Frequency (kHz)
Ta (°C)
Fig 15. Supply Current vs. Frequency
Fig 16. Supply Current vs. Temperature
10
IXS839 / IXS839A / IXS839B
IXYS
Package Outlines
8-PIN SOIC
QFN - 10
(REF.)
TOP VIEW
SIDE VIEW
11
IXS839 / IXS839A / IXS839B
IXYS
Low-Side Gate Driver
Theory of Operation
The Low-Side Gate Driver is designed to drive a
ground referenced N-Channel Power MOSFET. In
a synchronous buck converter application, it drives
the gate of the synchronous rectifier FET, (Q2).
When the driver is enabled, (IXS839A/B
SD=LSD=VDD), the driver output is 180˚ out of
phase with the PWM input. The internal overlap
protection circuit monitors the High-Side Gate
Driver, and allows the Low-Side Gate Driver to turn
on only when the High-Side Gate Driver output falls
below 1.0 Volt. The supply rails for the Low-Side
Gate Driver are VDD and PGND.
The IXS839/839A/839B are dual MOSFET drivers,
designed to drive two external N-channel power
MOSFETs. The low-side driver is designed to drive
a non-floating N-channel power MOSFET and its
output is out of phase with the PWM input. The
high-side driver is designed to drive a floating N-
channel power MOSFET and its output is in phase
with the PWM input. An external bootstrap circuit
provides the floating power supply to the high-side
driver.
The bootstrap circuit consists of a Schottky diode
and a boost capacitor. When the PWM input
transitions to a logic low, the low-side power
MOSFET turns ON, the SW node is pulled to
ground, and the bootstrap capacitor is charged to
VDD through the Schottky diode. When the PWM
transitions to a logic high, the high side power
MOSFET begins to turn on and the SW node rises
up to the input supply, VIN. In turn the boost
capacitor raises the BST node voltage to a level
equal to the input supply plus the boost capacitor
voltage, providing sufficient voltage to the BST
node to turn on the High-Side Power MOSFET. An
High-Side Gate Driver
The High-Side Gate Driver is designed to drive a
floating N-Channel Power MOSFET referenced to
SW. In a synchronous buck converter application, it
drives the gate of the high side power MOSFET,
(Q1). When the driver is enabled (IXS839A/B
SD=VDD), the driver output is in phase with the
PWM input. The bootstrap supply rails for the High-
Side Gate Driver are BST and SW, and are
generated by an external bootstrap circuit. The
bootstrap circuit consists of a Schottky diode
DBST, and a bootstrap capacitor CBST. During
start up, the SW pin is at ground and the bootstrap
capacitor CBST charges up to VDD through the
Schottky diode DBST. When the PWM input
transitions high the High-Side Gate Driver begins to
turn Q1 ON by transferring charge from the
bootstrap capacitor CBST to the gate of Q1. As Q1
turns on the SW pin will rise up to VIN, forcing the
BST pin to VIN + VBOOSTCAP. This supplies the
required gate to source voltage to Q1. When PWM
transitions low the High-Side Driver and in turn Q1
switch off. When SW falls below 1 Volt the Low-
Side Gate Driver turns on and recharges the
bootstrap capacitor which completes the cycle.
internal
cross-conduction
prevention
circuit
monitors both gate driver outputs and allows each
driver output to turn ON only when the other output
driver turns OFF and falls below 1V.
The IXS839A is
a
cost reduced Driver,
differentiated by the absence of the undervoltage
lockout protection circuit featured in the IXS839 and
IXS839B. IXS839A/B must be enabled using the
SD terminal when the driver supply reaches the
operating range. SD can be used to turn off both
driver outputs to prevent the rapid discharge of the
buck converter output capacitors. An additional
terminal, LSD can be used to turn off the Low-Side
Gate Driver Output. The High-Side Gate Driver
remains active in this mode.
Overlap Protection Circuit
The overlap protection circuit (OPC) monitors the
High Side and Low Side Gate Driver Outputs and
prevents both main power switches, Q1 and Q2,
from being ON at the same time. This inhibits
excessive shoot-through currents and minimizes
the associated losses.
Detailed Circuit Description
(Refer to the Application Diagrams)
The PMW input signal controls both the High Side
and Low Side power MOSFET drivers. The Power
MOSFETs are driven so that the SW node follows
the polarity of the PWM signal.
When the PWM input transitions low, Q1 begins to
turn OFF, and Q2 turns ON only when the High-
Side Gate Driver output falls below 1 volt. By
12
IXS839 / IXS839A / IXS839B
IXYS
waiting for the voltage on the High Side Gate
Driver Output pin to reach 1 volt, the overlap
protection circuit ensures that Q1 is OFF before Q2
turns on.
Application Information
Supply Capacitor Selection
A 1 uF ceramic bypass capacitor is recommended
for the VDD input to provide noise suppression.
The bypass capacitor should be located as close
as possible to the IXS939/A/B.
Similarly, when the PWM input transitions high, Q2
begins to turn OFF, and Q1 turns ON after the
overlap protection circuit detects that the voltage at
the Low-Side Gate Driver output has dropped
below 1 volt. Once the driver output voltage falls
below 1 volt, the overlap protection circuit initiates
a delay timer that adds additional delay set by the
external capacitor connected to the DLY pin. This
programmable delay circuit allows adjustments to
optimize performance based on the switching
characteristics of the external power MOSFET.
Bootstrap Circuit
The bootstrap circuit requires a charge storage
capacitor CBST and a Schottky diode DBST, as
shown in Figure 1. Selecting these components
should be done with consideration of the electrical
characteristics of the high-side FET chosen.
The bootstrap capacitor voltage rating must
exceed the maximum input voltage, (VIN) + the
maximum VDD voltage. The capacitance is
determined using the following equation:
QGATE
Low-Side Driver Shutdown
The IXS839A/B include a Low-Side Gate Driver
shutdown feature. A logic low signal at the LSD
input shuts down the Low Side Gate Driver, and in
turn the synchronous rectifier FET. This signal can
be used to achieve maximum battery life under
light load conditions and maximum efficiency under
heavy load conditions. Under heavy load
conditions, LSD should be high so that the
synchronous switch is controlled by the PWM
signal for maximum efficiency. Under light load
conditions the LSD can be low to disable the Low
Side Gate Driver so the switching current can be
minimized.
CBST
=
∆VBST
Where, QGATE is the total gate charge of Q1, and
∆VBST is the allowable Q1 voltage droop.
To maximize the available drive for Q1 in the
bootstrap circuit a Schottky diode is recommended.
The bootstrap diode voltage rating must exceed
the maximum input voltage, (VIN) + the maximum
VDD voltage. The average forward current can be
estimated by:
IF(AVG) = QGATE X FMAX
where FMAX is the maximum PWM input switching
frequency. Peak surge current is dependent on the
source impedance of the 5V supply and the ESR
of CBST, and should be checked in-circuit.
Shutdown
For optimal system power management, the
IXS839A/B drivers can be shut down to conserve
power. When the SD pin is high, the IXS839A/B
are enabled for normal operation. Pulling the SD
pin low forces the HGD and LGD outputs low, and
reduces the supply current by disabling the internal
reference.
Delay Capacitor Selection
A ceramic capacitor is recommended for the DLY
input, and should be located as close a possible to
the DLY pin.
Under Voltage Lockout (IXS839 and IXS839B)
The Under Voltage Lockout (UVLO) circuit holds
both driver outputs low during VDD supply ramp-
up. The UVLO logic becomes active and in control
of the driver outputs at a supply voltage of no
greater than 1.5 V. When the supply voltage rises
above the UVLO upper threshold the circuit allows
the PWM input to control the drivers.
Printed Circuit Board Layout Considerations
Use the following general guidelines when
designing printed circuit boards:
1. Trace out the high current paths and use short,
wide traces to make these connections.
2. Locate the VDD bypass capacitor as close as
possible to the VDD and PGND pins.
3. Connect the source of the Lower MOSFET,
(Q2) as close as possible the PGND.
13
厂商 型号 描述 页数 下载

LITTELFUSE

 		IXS839AD2 [ Half Bridge Based MOSFET Driver, DIE-12 ] 13 页

LITTELFUSE

 		IXS839AQ2 [ Half Bridge Based MOSFET Driver, MO-229VEED-5, QFN-10 ] 13 页

LITTELFUSE

 		IXS839AQ2T/R [ Half Bridge Based MOSFET Driver, MO-229VEED-5, QFN-10 ] 13 页

LITTELFUSE

 		IXS839BQ2 [ Half Bridge Based MOSFET Driver, MO-229VEED-5, QFN-10 ] 13 页

LITTELFUSE

 		IXS839BQ2T/R [ Half Bridge Based MOSFET Driver, MO-229VEED-5, QFN-10 ] 13 页

LITTELFUSE

 		IXS839D1 [ Half Bridge Based MOSFET Driver, DIE-12 ] 13 页

LITTELFUSE

 		IXS839S1 [ Half Bridge Based MOSFET Driver, PDSO8, MS-012AA, SOIC-8 ] 13 页

LITTELFUSE

 		IXS839S1T/R [ Half Bridge Based MOSFET Driver, PDSO8, MS-012AA, SOIC-8 ] 13 页

IXYS

 		IXSA10N60B2D1 高速IGBT与二极管[ High Speed IGBT with Diode ] 6 页

ETC

 		IXSA12N60AU1 晶体管| IGBT | N -CHAN | 600V V（ BR ） CES | 24A I（C ） | TO- 263AA\n[ TRANSISTOR | IGBT | N-CHAN | 600V V(BR)CES | 24A I(C) | TO-263AA ] 2 页

购物指南

支付方式

配送服务

售后服务

发票须知

优惠券使用规则

特色服务

PCBA制造

国产品牌推荐

国产料号替代

质量保证

技术资料

行业资讯

关于我们

关于壹壹捌

联系我们

联系我们

服务热线：400-618-9990

企业邮箱：sales@ic118.com

服务时间：周一至周六 8:30-17:30

壹壹捌官方微信号

PDF索引：

A

B

C

D

E

F

G

H

I

J

K

L

M

N

O

P

Q

R

S

T

U

V

W

X

Y

Z

0

1

2

3

4

5

6

7

8

9

IC型号索引：

A

B

C

D

E

F

G

H

I

J

K

L

M

N

O

P

Q

R

S

T

U

V

W

X

Y

Z

0

1

2

3

4

5

6

7

8

9

Copyright 2024 gkzhan.com Al Rights Reserved 京ICP备06008810号-21 京

深圳网络警察报警平台
公共信息安全网络监察
经营性网站备案信息
不良信息举报中心
工商网监电子标识
全国公安机关备案
0.201282s
