4N35X, 4N36X, 4N37X,
4N35, 4N36, 4N37,
OPTICALLY COUPLED
ISOLATOR
PHOTOTRANSISTOR OUTPUT
APPROVALS
Dimensions in mm
2.54
l
UL recognised, File No. E91231
1
6
5
4
7.0
6.0
'X' SPECIFICATION APPROVALS
2
3
l
VDE0884in3availableleadforms:-
-STD
-Gform
1.2
3.0
-SMDapprovedtoCECC00802
7.62
6.62
7.62
0.26
4.0
3.0
l
BSIapproved-CertificateNo. 8001
13°
Max
0.5
DESCRIPTION
3.35
0.5
The 4N35, 4N36, 4N37 series of optically
coupled isolators consist of infrared light
emitting diode and NPN silicon photo transistor
in a standard 6 pin dual in line plastic package.
ABSOLUTE MAXIMUM RATINGS
(25°C unless otherwise specified)
FEATURES
l
Options :-
Storage Temperature
Operating Temperature
Lead Soldering Temperature
(1/16 inch (1.6mm) from case for 10 secs) 260°C
-55°C to + 150°C
-55°C to + 100°C
10mm lead spread - add G after part no.
Surface mount - add SM after part no.
Tape&reel - add SMT&R after part no.
High Current Transfer Ratio (100% min.)
High Isolation Voltage (5.3kV ,7.5kVPK
All electrical parameters 100R%MStested
Custom electrical selections available
l
l
l
l
)
INPUT DIODE
Forward Current
Reverse Voltage
Power Dissipation
60mA
6V
105mW
APPLICATIONS
l
l
l
l
DC motor controllers
Industrial systems controllers
Measuring instruments
Signal transmission between systems of
different potentials and impedances
OUTPUT TRANSISTOR
Collector-emitter Voltage BVCEO
Collector-base Voltage BVCBO
Emitter-collector Voltage BVECO
Power Dissipation
30V
70V
6V
160mW
OPTION G
7.62
OPTION SM
SURFACE MOUNT
POWER DISSIPATION
Total Power Dissipation
(derate linearly 2.67mW/°C above 25°C)
200mW
0.6
0.1
1.25
0.75
0.26
10.46
9.86
10.16
ISOCOM INC
1024 S.GreenvilleAve,Suite240,
Allen, TX75002 USA
Tel:(214)495-0755 Fax:(214)495-0901
e-mail info@isocom.com
ISOCOM COMPONENTS LTD
Unit 25B, Park View Road West,
Park View Industrial Estate, Brenda Road
Hartlepool, Cleveland, TS25 1YD
Tel: (01429) 863609 Fax :(01429) 863581
http://www.isocom.com
5/2/03
DB90046m-AAS/A3
