SOT23 N-CHANNEL ENHANCEMENT
MODE VERTICAL DMOS FET
ZVN3310F
ISSUE 3 – OCTOBER 1995
✪
FEATURES
*
*
100 Volt VDS
RDS(on)= 10Ω
S
D
G
COMPLEMENTARY TYPE -
PARTMARKING DETAIL -
ZVP3310F
MF
SOT23
ABSOLUTE MAXIMUM RATINGS.
PARAMETER
SYMBOL
VDS
VALUE
UNIT
V
Drain-Source Voltage
100
100
Continuous Drain Current at Tamb=25°C
Pulsed Drain Current
ID
mA
A
IDM
2
Gate-Source Voltage
VGS
V
± 20
Power Dissipation at Tamb=25°C
Operating and Storage Temperature Range
Ptot
330
mW
°C
Tj:Tstg
-55 to +150
ELECTRICAL CHARACTERISTICS (at T
= 25°C unless otherwise stated).
amb
PARAMETER
SYMBOL MIN. MAX. UNIT CONDITIONS.
Drain-Source
Breakdown Voltage
BVDSS
100
V
ID=1mA, VGS=0V
Gate-Source Threshold
Voltage
VGS(th)
0.8
2.4
20
V
ID=1mA, VDS= VGS
Gate-Body Leakage
IGSS
IDSS
nA
V
GS=± 20V, VDS=0V
Zero Gate Voltage
Drain Current
1
50
V
V
DS=100V, VGS=0
DS=80V, VGS=0V, T=125°C(2)
µA
µA
On-State Drain Current(1)
ID(on)
500
100
mA
VDS=25V, VGS=10V
VGS=10V, ID=500mA
Static Drain-Source On-State
Resistance (1)
RDS(on)
10
Ω
Forward Transconductance
(1)(2)
gfs
mS
VDS=25V, ID=500mA
Input Capacitance (2)
Ciss
40
15
pF
pF
Common Source
Output Capacitance (2)
Coss
VDS=25V, VGS=0V, f=1MHz
Reverse Transfer Capacitance Crss
(2)
5
pF
Turn-On Delay Time (2)(3)
Rise Time (2)(3)
td(on)
tr
td(off)
tf
3 typ
5 typ
4 typ
5 typ
5
7
6
7
ns
ns
ns
ns
V
DD ≈25V, ID=500mA
Turn-Off Delay Time (2)(3)
Fall Time (2)(3)
(1) Measured under pulsed conditions. Width=300µs. Duty cycle ≤2% (2) Sample test.
(3) Switching times measured with 50Ω source impedance and <5ns rise time on a pulse generator
