INTEGRATED CIRCUITS
DATA SHEET
TZA3057HW
SDH/SONET, Fibre Channel and
Gigabit Ethernet multi-rate fibre
optic transmitter
Product specification
2003 Nov 07
Supersedes data of 2002 Aug 15
Philips Semiconductors
Product specification
SDH/SONET, Fibre Channel and Gigabit
Ethernet multi-rate fibre optic transmitter
TZA3057HW
FEATURES
APPLICATIONS
• A-rateTM(1) technology supports all bit rates from the
• SDH/SONET, Fibre Channel and Gigabit Ethernet
same reference frequency
optical transmission systems
• Supports eight bit rates:
• Physical interface IC in transmit channels
• Transponder applications
– SDH/SONET rates at 155.52 Mbits/s,
622.08 Mbits/s, 2488.32 Mbits/s and
2666.06 Mbits/s (STM16/OC48 + FEC)
• Dense Wavelength Division Multiplexing (DWDM)
systems.
– Fibre Channel at 1062.5 Mbits/s and 2125 Mbits/s
– Gigabit Ethernet at 1250 Mbits/s and 3125 Mbits/s
• 4-stage FIFO for wide tolerance to clock skew
• Loss Of Lock (LOL) indicator
GENERAL DESCRIPTION
The TZA3057HW is a fully integrated optical network
transmitter, containing an A-rate clock synthesizer core,
supporting all line rates from one single reference
frequency and a programmable multiplexer, supporting
16 : 1, 10 : 1, 8 : 1 or 4 : 1 multiplexing ratios. The
transmitter supports diagnostic and line loopback modes.
• ITU-T compliant jitter generation
• CML data and clock outputs, and loop mode inputs
• Line loopback input
• Diagnostic loopback output
• 16 : 1, 10 : 1, 8 : 1 or 4 : 1 multiplexing ratio
• Rail-to-rail parallel inputs compliant with LVPECL, CML
and LVDS
• Supports co-directional and contra-directional clocking
• Programmable parity checking
• Temperature alarm
• Pin compatible with continuous rate TZA3017HW
transmitter chip
• Single 3.3 V power supply.
(1) A-rate is a trademark of Koninklijke Philips Electronics N.V.
ORDERING INFORMATION
TYPE
PACKAGE
NUMBER
NAME
DESCRIPTION
VERSION
TZA3057HW
HTQFP100
plastic thermal enhanced thin quad flat package; 100 leads;
SOT638-1
body 14 × 14 × 1.0 mm; exposed die pad
2003 Nov 07
2
This text is here in white to force landscape pages to be rotated correctly when browsing through the pdf in the Acrobat reader.This text is here in
_white to force landscape pages to be rotated correctly when browsing through the pdf in the Acrobat reader.This text is here inThis text is here in
white to force landscape pages to be rotated correctly when browsing through the pdf in the Acrobat reader. white to force landscape pages to be ...
  a
DIN
MUXR1
MUXR0 CINQ
CIN
DINQ
46 45 81 82 78 79
55
56
74
73
44
OVERFLOW
FIFORESET
PARERR
84
TEMPERATURE
ALARM
TEMPAL
PARERRQ
PAREVEN
D
C
67
66
38
37
DOUT
2
2
PARITY
DOUTQ
PARITYQ
16
60
59
D00 to D15
COUT
PARITY
CHECKER
4, 6, 8, 10, 12, 15, 17,
19, 21, 23, 28, 30, 32,
95, 97, 99
MUX
2
16
16
16
16
COUTQ
D
C
4 : 1
4 deep
FIFO
8 : 1
2
10 : 1
16 : 1
16
D00Q to D15Q
89
88
DLOOP
2
2
3, 5, 7, 9, 11, 14, 16,
18, 20, 22, 27, 29, 31,
94, 96, 98
W
R
DLOOPQ
92
91
35
34
CLOOP
PICLK
CLOOPQ
PICLKQ
85
86
TZA3057HW
ENLOUTQ
ENLINQ
72
n.c.
POWER-ON
RESET
CLOCK
SYNTHESIZER
54
53
52
DR0
DR1
DR2
71
40
39
LINE RATE
SELECT
CLKDIR
POCLK
1, 25, 33, 36, 41, 49,
58, 61, 64, 65, 68, 77,
80, 83, 87, 90, 93, 100
POCLKQ
2, 13, 24,
26, 50,
70, 76
62
63
57 48 47 43 42
75
69
51
MGU708
18
7
V
V
V
V
V
EE
MD0 MD1
PRSCLO CREF
CCD CCA CCO
DD
LOL PRSCLOQ CREFQ
Fig.1 Block diagram.
Philips Semiconductors
Product specification
SDH/SONET, Fibre Channel and Gigabit
Ethernet multi-rate fibre optic transmitter
TZA3057HW
PINNING
SYMBOL
D00
PIN
DESCRIPTION
SYMBOL
VEE
PIN
DESCRIPTION
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
parallel data input 00
die
pad
common ground plane
VCCD
supply voltage (digital part)
parallel clock input inverted
parallel clock input
PICLKQ
PICLK
VCCD
VCCD
VEE
1
supply voltage (digital part)
ground
2
supply voltage (digital part)
parity input inverted
D12Q
D12
3
parallel data input 12 inverted
parallel data input 12
PARITYQ
PARITY
POCLKQ
POCLK
VCCD
4
parity input
D11Q
D11
5
parallel data input 11 inverted
parallel data input 11
parallel clock output inverted
parallel clock output
6
D10Q
D10
7
parallel data input 10 inverted
parallel data input 10
supply voltage (digital part)
reference clock input inverted
reference clock input
8
CREFQ
CREF
D09Q
D09
9
parallel data input 09 inverted
parallel data input 09
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
PAREVEN
MUXR1
MUXR0
PRSCLOQ
PRSCLO
VCCD
parity select (odd or even)
multiplexer ratio select 1 input
multiplexer ratio select 0 input
prescaler output signal inverted
prescaler output signal
supply voltage (digital part)
ground
D08Q
D08
parallel data input 08 inverted
parallel data input 08
VEE
ground
D07Q
D07
parallel data input 07 inverted
parallel data input 07
D06Q
D06
parallel data input 06 inverted
parallel data input 06
VEE
VDD
supply voltage (digital part)
data rate select 2 input
data rate select 1 input
data rate select 0 input
FIFO overflow alarm output
FIFO reset input
D05Q
D05
parallel data input 05 inverted
parallel data input 05
DR2
DR1
D04Q
D04
parallel data input 04 inverted
parallel data input 04
DR0
OVERFLOW
FIFORESET
LOL
D03Q
D03
parallel data input 03 inverted
parallel data input 03
loss of lock output
VEE
ground
VCCD
supply voltage (digital part)
serial clock output inverted
serial clock output
VCCD
VEE
supply voltage (digital part)
ground
COUTQ
COUT
D02Q
D02
parallel data input 02 inverted
parallel data input 02
VCCD
supply voltage (digital part)
MD0
parallel data input termination
mode select 0
D01Q
D01
parallel data input 01 inverted
parallel data input 01
MD1
63
parallel data input termination
mode select 1
D00Q
parallel data input 00 inverted
2003 Nov 07
4
Philips Semiconductors
Product specification
SDH/SONET, Fibre Channel and Gigabit
Ethernet multi-rate fibre optic transmitter
TZA3057HW
SYMBOL
VCCD
PIN
DESCRIPTION
SYMBOL
VCCD
PIN
DESCRIPTION
64
65
66
67
68
69
70
71
supply voltage (digital part)
supply voltage (digital part)
serial data output inverted
serial data output
83
84
85
supply voltage (digital part)
temperature alarm output
VCCD
TEMPAL
DOUTQ
DOUT
VCCD
ENLOUTQ
diagnostic loopback enable
input (active LOW)
ENLINQ
86
line loopback enable input
(active LOW)
supply voltage (digital part)
supply voltage (clock generator)
ground
VCCO
VCCD
87
88
89
90
91
92
93
94
95
96
97
98
99
supply voltage (digital part)
loop mode data output inverted
loop mode data output
VEE
DLOOPQ
DLOOP
VCCD
CLKDIR
selection between co- and
contra-directional clocking
supply voltage (digital part)
loop mode clock output inverted
loop mode clock output
n.c.
72
73
74
75
76
77
78
79
80
81
82
not connected
CLOOPQ
CLOOP
VCCD
PARERRQ
PARERR
VCCA
parity error output inverted
parity error output
supply voltage (digital part)
parallel data input 15 inverted
parallel data input 15
supply voltage (analog part)
ground
D15Q
D15
VEE
VCCD
DINQ
DIN
supply voltage (digital part)
loop mode data input inverted
loop mode data input
supply voltage (digital part)
loop mode clock input inverted
loop mode clock input
D14Q
D14
parallel data input 14 inverted
parallel data input 14
D13Q
D13
parallel data input 13 inverted
parallel data input 13
VCCD
CINQ
CIN
VCCD
100 supply voltage (digital part)
2003 Nov 07
5
Philips Semiconductors
Product specification
SDH/SONET, Fibre Channel and Gigabit
Ethernet multi-rate fibre optic transmitter
TZA3057HW
V
V
1
2
75
CCD
CCA
V
74 PARERR
EE
D12Q
D12
3
PARERRQ
n.c.
73
72
71
70
69
68
4
CLKDIR
D11Q
D11
5
6
V
EE
D10Q
D10
V
7
CCO
V
8
CCD
D09Q
D09
9
67 DOUT
10
66 DOUTQ
D08Q 11
V
V
65
64
CCD
CCD
D08
12
13
V
TZA3057HW
63 MD1
EE
D07Q 14
D07 15
MD0
V
62
61
CCD
16
D06Q
D06 17
18
60 COUT
59
58
57
COUTQ
V
D05Q
D05 19
CCD
LOL
20
21
22
23
24
25
D04Q
D04
56 FIFORESET
55 OVERFLOW
DR0
DR1
D03Q
D03
54
53
V
52 DR2
EE
V
V
DD
51
CCD
MGU709
Fig.2 Pin configuration.
2003 Nov 07
6
Philips Semiconductors
Product specification
SDH/SONET, Fibre Channel and Gigabit
Ethernet multi-rate fibre optic transmitter
TZA3057HW
FUNCTIONAL DESCRIPTION
Clock synthesizer
The TZA3057HW converts parallel input data into serial
output data with a bit rate of 155 Mbits/s to 3.1 Gbits/s (see
Table 1). An internal clock synthesizer synchronizes the
internal oscillator to an external reference frequency. The
parallel input data is multiplexed at a ratio of 16 : 1, 10 : 1,
8 : 1 or 4 : 1.
Refer to Fig.3. The clock synthesizer consists of a Voltage
Controlled Oscillator (VCO), main divider, Phase
Frequency Detector (PFD), integrated loop filter, Loss Of
Lock (LOL) detection circuit and a prescaler output buffer.
The internal VCO is phase-locked to a reference clock
signal of typically 19.44 MHz applied to pins CREF and
CREFQ.
Configuring the TZA3057HW using pins DR2 to DR0
The clock synthesizer does not require any external
components, allowing easier application use.
The IC supports eight bit rates using an external reference
clock frequency of 19.44 MHz. Pins DR2 to DR0 are
standard CMOS inputs that select one of the eight
pre-programmed bit rates using one external reference
clock frequency of 19.44 MHz (see Table 1).
To comply with most transmission standards, the
reference frequency must be very accurate with minimum
phase noise in order to synthesize a pure RF clock signal
that complies with the strictest requirements for jitter
generation; see Section “Jitter performance”.
Table 1 Truth table for pin DR
Prescaler outputs
BIT RATE
(Mbits/s)
DR2
DR1
DR0
PROTOCOL
The frequency of prescaler outputs PRSCLO and
PRSCLOQ is the VCO frequency divided by the main
division factor. If the synthesizer is in-lock, the frequency
of the prescaler output is equal to the reference frequency
at CREF and CREFQ. This provides an accurate
reference that can be used by other phase lock loops in the
application.
LOW
LOW
LOW
LOW STM1/OC3
155.52
622.08
LOW HIGH STM4/OC12
LOW HIGH LOW STM16/OC48
LOW HIGH HIGH STM16 + FEC
2488.32
2666.06
1250.00
3125.00
1062.50
2125.00
HIGH LOW
LOW GE
HIGH LOW HIGH 10GE
Loss of lock
HIGH HIGH LOW Fibre Channel
HIGH HIGH HIGH Fibre Channel
During normal operation, pin LOL should be LOW to
indicate that the clock synthesizer is in-lock and that the
output frequency corresponds to the programmed value.
If pin LOL goes HIGH, phase and/or frequency lock is lost
and the output frequency may deviate from the
programmed value.
LOL
CREF(Q)
up
VCO
PHASE-
CHARGE PUMP
to
FREQUENCY
DETECTOR
AND
down
MUX
LOOP FILTER
MAIN
DIVIDER
MGU710
PRSCLO(Q)
DR
Fig.3 Functional diagram of the clock synthesizer.
7
2003 Nov 07
Philips Semiconductors
Product specification
SDH/SONET, Fibre Channel and Gigabit
Ethernet multi-rate fibre optic transmitter
TZA3057HW
Jitter performance
Multiplexer
The clock synthesizer is optimized for minimum jitter
generation. For all SDH/SONET bit rates, the generated
jitter complies with ITU-T standard G.958, using a pure
reference clock. To ensure negligible loss of performance,
the reference signal should have a single sideband phase
noise of better than −140 dBc/Hz, at frequencies of more
than 12 kHz from the carrier.
The multiplexer comprises a high-speed input register, a
4-bit deep First In First Out (FIFO) elastic buffer, a parity
check circuit and a multiplexing tree.
Parallel input bus clocking schemes
The TZA3057HW supports both co-directional and
contra-directional clocking schemes for the parallel data
bus (see Figs 5 and 6). The clocking scheme is selected
by pin CLKDIR. Co-directional clocking is the default
setting and is selected when pin CLKDIR is HIGH. With
co-directional clocking selected, the incoming clock is
applied to pins PICLK and PICLKQ and the input data is
applied to pins D00 to D00Q and D15 to D15Q. A parallel
output clock is available at pins POCLK and POCLKQ.
Reference input
For optimum jitter performance and Power Supply
Rejection Ratio (PSRR), the sensitive reference input
should be driven differentially. If the reference frequency
source (fref) is single-ended, the unused CREF or CREFQ
input should be terminated with an impedance which
matches the source impedance Rsource (see Fig.4).
The PSRR can be improved by AC coupling the reference
frequency source to inputs CREF and CREFQ. Any low
frequency noise injected from the fref power supply will be
attenuated by the resulting high-pass filter. The low cut-off
frequency of the AC coupling must be lower than the
reference frequency, otherwise the reference signal will be
attenuated and the signal to noise ratio will be made
worse. The value of coupling capacitor C is calculated
When contra-directional clocking is selected, any incoming
clock at pins PICLK and PICLKQ is not used.
In contra-directional clocking mode, the incoming data on
the parallel data bus is sampled by the internally generated
parallel output clock. In this mode, the parallel data source
must be clocked using the parallel output clock signal at
pins POCLK and POCLKQ.
1
using the formula: C >
-----------------------------------
2πRsourcefref
V
handbook, halfpage
CCD
V
CC
50 Ω
50 Ω
43 CREF
42 CREFQ
C
C
R
R
source
source
f
ref
on-chip off-chip
MDB060
Fig.4 Reference input with single-ended clock
source.
2003 Nov 07
8
Philips Semiconductors
Product specification
SDH/SONET, Fibre Channel and Gigabit
Ethernet multi-rate fibre optic transmitter
TZA3057HW
FRAMER
TZA3057HW
PARITY
TX_PARITY
PARITYQ
16
16
D00 to D15
D00Q to D15Q
PICLK
TX_DATA
TX_CLK
PICLKQ
POCLK
TX_CLK_SRC
POCLKQ
FIFORESET CREF
MGU711
system
clock
Fig.5 Co-directional clocking diagram.
FRAMER
TZA3057HW
PARITY
TX_PARITY
TX_DATA
PARITYQ
16
16
D00 to D15
D00Q to D15Q
POCLK
TX_CLK_SRC
POCLKQ
FIFORESET CREF
MGU712
system
clock
Fig.6 Contra-directional clocking diagram.
9
2003 Nov 07
Philips Semiconductors
Product specification
SDH/SONET, Fibre Channel and Gigabit
Ethernet multi-rate fibre optic transmitter
TZA3057HW
FIFO
multiplexing ratio selected by pins MUXR0 and MUXR1.
Any unused parallel data bus inputs are disabled. The
configuration settings and active inputs for each
multiplexing ratio are shown in table 2. The highest
supported speed for the parallel data bus is 400 Mbits/s.
Therefore the multiplexing ratio of 4 : 1 will only support
the following bit rates: 155 Mbits/s, 622 Mbits/s,
1062.5 Mbits/s (FC) and 1250 Mbits/s (GE).
In the co-directional clocking scheme, the FIFO input
register samples the incoming parallel data on the rising
edge of the clock signal at pins PICLK and PICLKQ. Data
is retrieved from the FIFO by an internal clock, derived
from the multiplexing tree clock generator. This provides a
high tolerance to jitter, or clock skew, at inputs on the
parallel interface. The FIFO can compensate for brief
phase deviations, or clock skew, of up to plus or minus
1 unit interval. Large phase deviations will most likely
cause the FIFO to either overflow or underflow, and is
Table 2 Setting the multiplexing ratio
PIN
PIN
MULTIPLEX ACTIVE OUTPUTS
indicated by a HIGH level at pin OVERFLOW.
DMXR1 DMXR0
RATIO
LSB TO MSB
LOW
LOW
HIGH
HIGH
LOW
HIGH
LOW
HIGH
4 : 1
8 : 1
D06 to D09
D04 to D11
D03 to D12
D00 to D15
The overflow condition exists until the FIFO is reset by a
HIGH level on pin FIFORESET. FIFORESET also
initializes the FIFO. For optimum performance, the FIFO
should be reset whenever there has been a loss of lock
condition, or whenever the bit rate is changed.
10 : 1
16 : 1
The FIFORESET signal is re-timed by the internal clock
generator signal. The FIFO will initialize two clock cycles
after FIFORESET goes HIGH and is operational two clock
cycles after FIFORESET goes LOW. The FIFO can be
initialized automatically when an overflow occurs by
connecting pin OVERFLOW to pin FIFORESET.
Parity checking
The parity checking function verifies the integrity of the
incoming data on the parallel data bus. The calculated
parity is compared to the parity expected at pins PARITY
and PARITYQ. If these levels do not match, a parity error
has occurred and pin PARERR goes HIGH during the next
parallel clock period at pins PICLK and PICLKQ (see
Fig.7).
Adjustable multiplexing ratio
For optimum layout connectivity, the physical positions of
parallel data bus pins D00(Q) to D15(Q) on the chip are
located on either side of pin VEE (pin 13). The number of
parallel data bus inputs that are used depends on the
The calculated parity can be configured to be either odd or
even by pin PAREVEN. Odd parity is configured by a LOW
level at pin PAREVEN.
PICLK
D00-D15
PARITY
PARERR
PARITY
ERROR
MDB063
Fig.7 Parity timing.
2003 Nov 07
10
Philips Semiconductors
Product specification
SDH/SONET, Fibre Channel and Gigabit
Ethernet multi-rate fibre optic transmitter
TZA3057HW
Rail-to-rail parallel data and clock inputs
Table 3 Input termination mode selection
The differential parallel data, parity and clock inputs, D00
to D15, D00Q to D15Q, PARITY, PARITYQ, PICLK and
PICLKQ can handle input swings from 100 mV,
single-ended, to a maximum of 1000 mV. These rail-to-rail
inputs can also accept any absolute value between VEE
INPUT
MODE
PIN MD1 PIN MD0
TERMINATION
LOW
LOW
LOW
floating
LVDS
100 Ω differential
HIGH
100 Ω differential
(hysteresis on)
and VCC
.
HIGH
HIGH
LOW
CML
50 Ω to VCC
To keep the number of external components required to a
minimum, most of the common standards: LVPECL, CML
and LVDS are terminated internally (see Fig.8).
HIGH
LVPECL
50 Ω to VCC − 2 V
The LVDS mode has a differential hysteresis of 30 mV
implemented by default.
The termination mode is determined by pins MD0 and
MD1; see Table 3.
V
V
CCD
CCD
V
CCD
2 V
D
D
D
50 Ω
50 Ω
50 Ω
50 Ω
50 Ω
50 Ω
DQ
DQ
DQ
V
EE
V
V
EE
CML termination
EE
Floating and LVDS termination
LVPECL termination
MDB062
Fig.8 Rail-to-rail input termination configurations.
Loop mode I/Os
CMOS control inputs
In line loopback mode, the internal data and clock routing
switch selects serial data and clock signals from input pins
DIN, DINQ, CIN and CINQ instead of from the output of the
multiplexer. Line loopback mode is activated by a LOW
level on pin ENLINQ.
CMOS control input pins DR0, DR1, DR2, MUXR0,
MUXR1, PAREVEN, CLKDIR, ENLOUTQ, ENLINQ, MD0,
MD1 and FIFORESET have an internal pull-up resistor so
that these pins go HIGH when open circuit and go LOW
when deliberately forced.
In diagnostic loopback mode, the synthesized serial data
and clock signals are available at loop mode output pins
DLOOP, DLOOPQ, CLOOP and CLOOPQ and at output
pins DOUT, DOUTQ, COUT and COUTQ. Diagnostic
loopback mode is activated when pin ENLOUTQ is LOW.
Temperature alarm
The TZA3057HW features a temperature alarm. The
temperature alarm switches the open-drain output of pin
TEMPAL to LOW at a junction temperature above 130 oC.
The CML RF outputs have an amplitude of 280 mV (p-p),
single-ended (when DC-coupled in the application).
2003 Nov 07
11
Philips Semiconductors
Product specification
SDH/SONET, Fibre Channel and Gigabit
Ethernet multi-rate fibre optic transmitter
TZA3057HW
Power supply connections
main ground return of the IC, this connection must also
have a low DC impedance. The voltage supply levels
should be in accordance with the values specified in
Chapters “Limiting values” and “Characteristics”.
Four separate supply domains (VDD, VCCD, VCCO and
VCCA) provide isolation between the various functional
blocks. Each supply domain should be connected to a
common VCC using a separate filter. All supply pins,
including the exposed die pad, must be connected.
The die pad connection to ground must have the lowest
possible inductance. Since the die pad is also used as the
All external components should be surface mounted, with
a preferable size of 0603 or smaller. The components
must be mounted as close to the IC as possible.
LIMITING VALUES
In accordance with the Absolute Maximum Rating System (IEC 60134).
SYMBOL PARAMETER
MIN.
−0.5
MAX.
+3.6
UNIT
VCCD, VCCA, supply voltages
V
VCCO,VDD
Vn
DC voltage on pins
D00 to D15, D00Q to D15Q, PICLK, PICLKQ, PARITY and PARITYQ VCC − 0.5 VCC + 0.5
V
V
V
POCLK, POCLKQ, PARERR, PARERRQ, PRSCLO and PRSCLOQ
VCC − 2.5 VCC + 0.5
DR0, DR1, DR2, CLKDIR, PAREVEN, FIFORESET, MD0, MD1,
ENLOUTQ and ENLINQ
−0.5
VCC + 0.5
LOL and OVERFLOW
TEMPAL
−0.5
−0.5
VCC + 0.5
CC + 0.5
V
V
V
In
input current on pins
D00 to D15, D00Q to D15Q, PICLK, PICLKQ, PARITY and PARITYQ −25
+25
+20
+2
mA
mA
mA
°C
CREF, CREFQ, CIN, CINQ, DIN and DINQ
TEMPAL
−20
−2
Tamb
Tj
ambient temperature
−40
−
+85
125
+150
junction temperature
°C
Tstg
storage temperature
−65
°C
THERMAL CHARACTERISTICS
SYMBOL
PARAMETER
thermal resistance from junction to ambient
CONDITIONS
notes 1 and 2
VALUE
UNIT
Rth(j-a)
16
K/W
Notes
1. In compliance with JEDEC standards JESD51-5 and JESD51-7.
2. Four-layer Printed-Circuit Board (PCB) in still air with 36 plated vias connected with the heatsink and the second and
fourth ground layer in the PCB.
2003 Nov 07
12
Philips Semiconductors
Product specification
SDH/SONET, Fibre Channel and Gigabit
Ethernet multi-rate fibre optic transmitter
TZA3057HW
CHARACTERISTICS
VCC = 3.14 to 3.47 V; Tamb = −40 to +85 °C; Rth(j-a) ≤ 16 K/W; all voltages are referenced to ground; positive currents
flow into the device; unless otherwise specified.
SYMBOL
Supplies
PARAMETER
CONDITIONS
MIN.
TYP.
MAX.
UNIT
ICCA
ICCD
IDD
analog supply current
digital supply current
digital supply current
oscillator supply current
total supply current
0.5
170
0
1.2
2.4
mA
mA
mA
mA
mA
W
note 1
215
2
270
4
ICCO
ICC(tot)
Ptot
20
31
41
note 1
note 1
190
0.6
250
0.82
318
1.1
total power dissipation
CMOS input: pins DR0, DR1, DR2, MD0, MD1, ENLINQ, ENLOUTQ, FIFORESET, PAREVEN and CLKDIR
VIL
VIH
IIL
LOW-level input voltage
HIGH-level input voltage
LOW-level input current
HIGH-level input current
−
−
−
−
−
0.2VCC
V
0.8VCC
−200
−
−
V
VIL = 0 V
VIH = VCC
−
µA
µA
IIH
10
CMOS output: pins OVERFLOW and LOL
VOL
VOH
LOW-level output voltage
IOL = 1 mA
0
−
−
0.2
V
V
HIGH-level output voltage IOH = −0.5 mA
V
CC − 0.2
VCC
Open-drain output: pin TEMPAL
VOL
IOH
LOW-level output voltage
HIGH-level output current
IOL = 1 mA
VOH = VCC
0
−
−
0.2
10
V
−
µA
Serial output: pins COUT, COUTQ, DOUT, DOUTQ, CLOOP, CLOOPQ, DLOOP and DLOOPQ
Vo(p-p)
output voltage swing
(peak-to-peak value)
single-ended with 50 Ω
external load
220
280
340
mV
VO
Zo
tr
DC output voltage
output impedance
rise time
V
CC − 2
−
VCC
60
V
single-ended to VCC
20% to 80%
40
−
50
60
60
−
Ω
90
ps
ps
ps
tf
fall time
80% to 20%
−
90
tD-C
data-to-clock delay
between differential
−50
+50
crossovers; see Fig.13
δ
duty cycle COUT and
COUTQ
between differential
crossovers
40
50
50
60
%
Serial input: pins DIN, DINQ, CIN and CINQ
Vi(p-p)
input voltage
single-ended
−
1000
mV
(peak-to-peak value)
Vi
Zi
input voltage
V
CC − 1
−
VCC + 0.25
60
V
input impedance
single-ended to VCC
40
50
Ω
2003 Nov 07
13
Philips Semiconductors
Product specification
SDH/SONET, Fibre Channel and Gigabit
Ethernet multi-rate fibre optic transmitter
TZA3057HW
SYMBOL
PARAMETER
CONDITIONS
MIN.
TYP.
MAX.
UNIT
Parallel input (rail-to-rail): pins D00 to D15, D00Q to D15Q, PARITY, PARITYQ, PICLK and PICLKQ
Vi
input voltage
V
EE − 0.25
−
−
VCC + 0.25
1000
V
Vi(p-p)
input voltage swing
(peak-to-peak value)
single-ended
100
mV
mV
Ω
Vi(hys)
Zi(dif)
input differential hysteresis MD1 = LOW;
voltage
−
30
−
MD0 = HIGH
differential input
impedance
MD1 = LOW
80
40
−
100
50
120
60
−
Zi(se)
single-ended input
impedance
MD1 = HIGH
Ω
VT(CML)
VT(LVPECL)
tsu(co)
th(co)
input termination voltage in MD1 = HIGH;
CML mode MD0 = LOW
input termination voltage in MD1 = HIGH;
VCC
V
V
CC − 2.3
V
CC − 2
V
−
−
−
−
CC − 1.7
V
LVPECL mode
MD0 = HIGH
co-directional clocking
set-up time
see Fig.11
0
−
ps
ps
ps
ps
%
co-directional clocking hold see Fig.11
time
1000
1300
−300
40
−
tsu(contra)
th(contra)
δ
contra-directional clocking see Fig.12
set-up time
−
contra-directional clocking see Fig.12
hold time
−
duty cycle PICLK and
PICLKQ
between differential
crossovers
50
60
LVPECL output: pins POCLK, POCLKQ, PARERR, PARERRQ, PRSCLO and PRSCLOQ
VOH
HIGH-level output voltage 50 Ω termination to
CC − 2V
50 Ω termination to
CC − 2V
V
CC − 1.2
V
CC − 1.0
V
CC − 0.9
CC − 1.7
V
V
V
VOL
LOW-level output voltage
V
CC − 2.2
VCC − 1.9
V
V
tr
tf
rise time
fall time
20% to 80%
80% to 20%
300
300
350
350
400
400
ps
ps
Reference frequency input: pins CREF and CREFQ
Vi(p-p)
input voltage
single-ended
50
−
1000
mV
(peak-to-peak value)
VI
DC input voltage
input impedance
V
CC − 1
−
VCC + 0.25
60
V
Zi
single-ended to VCC
40
−20
50
−
Ω
∆fCREF
reference clock frequency SDH/SONET
accuracy requirement
+20
ppm
2003 Nov 07
14
Philips Semiconductors
Product specification
SDH/SONET, Fibre Channel and Gigabit
Ethernet multi-rate fibre optic transmitter
TZA3057HW
SYMBOL
PARAMETER
CONDITIONS
MIN.
TYP.
MAX.
UNIT
Jitter generation
Jgen(p-p)
jitter generation
(peak-to-peak value)
STM16/OC3 mode;
note 2
f = 500 Hz to 1.3 MHz
f = 12 kHz to 1.3 MHz
f = 65 kHz to 1.3 MHz
−
−
−
−
−
−
0.016
UI
0.016
0.004
UI
UI
STM16/OC12 mode;
note 2
f = 1 kHz to 5 MHz
f = 12 kHz to 5 MHz
f = 250 kHz to 5 MHz
−
−
−
−
−
−
0.063
0.063
0.013
UI
UI
UI
STM16/OC48 mode;
note 2
f = 5 kHz to 20 MHz
f = 12 kHz to 20 MHz
f = 1 MHz to 20 MHz
−
−
−
0.035
0.032
0.007
0.250
0.050
0.050
UI
UI
UI
Notes
1. Default settings: DR = LOW (STM16/OC48); PAREVEN = HIGH (even parity); FIFORESET = LOW; MD0 = LOW,
MD1 = LOW (100 Ω differential); CLKDIR = HIGH (co-directional clocking); ENLOUTQ = HIGH (DLOOP, DLOOPQ,
CLOOP and CLOOPQ disabled); ENLINQ = HIGH (DIN, DINQ, CIN and CINQ disabled); CREF and
CREFQ = 19.44 MHz; COUT, COUTQ, DOUT, DOUTQ, POCLK, POCLKQ, PARERR, PARERRQ, PRSCLO and
PRSLOQ are not connected.
2. Reference frequency of 19.44 MHz with a phase noise of less than −140 dBc for frequencies of more than 12 kHz
from the carrier. Measured for 60 seconds within the appropriate bandwidth.
2003 Nov 07
15
Philips Semiconductors
Product specification
SDH/SONET, Fibre Channel and Gigabit
Ethernet multi-rate fibre optic transmitter
TZA3057HW
SWING CONTROL
V
CC
V
2 V
term
optional
AC coupling
transmission
lines
OUT
to high-
impedance
input
50 Ω
50 Ω
OUTQ
I
swing
50 Ω
50 Ω
in
on-chip
off-chip
MBL562
Fig.9 Parallel output standard LVPECL mode.
SWING CONTROL
V
CC
50 Ω
50 Ω
50 Ω
transmission
50 Ω
lines
OUT
to high-
impedance
input
50 Ω
50 Ω
OUTQ
I
swing
in
on-chip
off-chip
MDB069
Fig.10 Serial output CML mode (DC-coupled).
16
2003 Nov 07
Philips Semiconductors
Product specification
SDH/SONET, Fibre Channel and Gigabit
Ethernet multi-rate fibre optic transmitter
TZA3057HW
PICLK
t
h(co)
t
su(co)
D00 to D15,
PARITY
valid data
POCLK
MBL581
The timing is measured from the crossover point of the reference signal to the crossover point of the input.
Fig.11 Parallel bus co-directional timing.
D00 to D15,
valid data
PARITY
t
su(contra)
t
h(contra)
POCLK
MBL582
The timing is measured from the crossover point of the reference signal to the crossover point of the input.
Fig.12 Parallel bus contra-directional timing.
2003 Nov 07
17
Philips Semiconductors
Product specification
SDH/SONET, Fibre Channel and Gigabit
Ethernet multi-rate fibre optic transmitter
TZA3057HW
COUT, CLOOP
t
D-C
DOUT, DLOOP
MBL583
The timing is measured from the crossover point of the reference signal to the crossover point of the output.
Fig.13 RF output timing.
2003 Nov 07
18
Philips Semiconductors
Product specification
SDH/SONET, Fibre Channel and Gigabit
Ethernet multi-rate fibre optic transmitter
TZA3057HW
PACKAGE OUTLINE
HTQFP100: plastic thermal enhanced thin quad flat package; 100 leads;
body 14 x 14 x 1 mm; exposed die pad
SOT638-1
c
y
exposed die pad side
X
D
h
A
75
51
50
76
Z
E
e
H
E
E
E
(A )
3
A
h
2
A
A
1
w
p
M
θ
b
L
p
pin 1 index
L
detail X
26
100
1
25
w
M
Z
v
M
A
B
D
b
p
e
D
B
H
v
M
D
0
10 mm
scale
DIMENSIONS (mm are the original dimensions)
A
(1)
(1)
(1)
(1)
UNIT
A
A
A
b
c
D
D
E
E
e
H
H
L
L
p
v
w
y
Z
Z
E
θ
1
2
3
p
h
h
D
E
D
max.
0.15 1.05
0.05 0.95
0.27 0.20 14.1 7.1 14.1 7.1
0.17 0.09 13.9 6.1 13.9 6.1
16.15 16.15
15.85 15.85
0.75
0.45
1.15 1.15
0.85 0.85
7°
0°
mm
1.2
0.25
0.5
1
0.2 0.08 0.08
Note
1. Plastic or metal protrusions of 0.25 mm maximum per side are not included.
REFERENCES
OUTLINE
EUROPEAN
PROJECTION
ISSUE DATE
VERSION
IEC
JEDEC
JEITA
01-03-30
03-04-07
SOT638-1
2003 Nov 07
19
Philips Semiconductors
Product specification
SDH/SONET, Fibre Channel and Gigabit
Ethernet multi-rate fibre optic transmitter
TZA3057HW
SOLDERING
To overcome these problems the double-wave soldering
method was specifically developed.
Introduction to soldering surface mount packages
If wave soldering is used the following conditions must be
observed for optimal results:
This text gives a very brief insight to a complex technology.
A more in-depth account of soldering ICs can be found in
our “Data Handbook IC26; Integrated Circuit Packages”
(document order number 9398 652 90011).
• Use a double-wave soldering method comprising a
turbulent wave with high upward pressure followed by a
smooth laminar wave.
There is no soldering method that is ideal for all surface
mount IC packages. Wave soldering can still be used for
certain surface mount ICs, but it is not suitable for fine pitch
SMDs. In these situations reflow soldering is
recommended.
• For packages with leads on two sides and a pitch (e):
– larger than or equal to 1.27 mm, the footprint
longitudinal axis is preferred to be parallel to the
transport direction of the printed-circuit board;
– smaller than 1.27 mm, the footprint longitudinal axis
must be parallel to the transport direction of the
printed-circuit board.
Reflow soldering
Reflow soldering requires solder paste (a suspension of
fine solder particles, flux and binding agent) to be applied
to the printed-circuit board by screen printing, stencilling or
pressure-syringe dispensing before package placement.
Driven by legislation and environmental forces the
The footprint must incorporate solder thieves at the
downstream end.
• For packages with leads on four sides, the footprint must
be placed at a 45° angle to the transport direction of the
printed-circuit board. The footprint must incorporate
solder thieves downstream and at the side corners.
worldwide use of lead-free solder pastes is increasing.
Several methods exist for reflowing; for example,
convection or convection/infrared heating in a conveyor
type oven. Throughput times (preheating, soldering and
cooling) vary between 100 and 200 seconds depending
on heating method.
During placement and before soldering, the package must
be fixed with a droplet of adhesive. The adhesive can be
applied by screen printing, pin transfer or syringe
dispensing. The package can be soldered after the
adhesive is cured.
Typical reflow peak temperatures range from
215 to 270 °C depending on solder paste material. The
top-surface temperature of the packages should
preferably be kept:
Typical dwell time of the leads in the wave ranges from
3 to 4 seconds at 250 °C or 265 °C, depending on solder
material applied, SnPb or Pb-free respectively.
• below 220 °C (SnPb process) or below 245 °C (Pb-free
process)
A mildly-activated flux will eliminate the need for removal
of corrosive residues in most applications.
– for all BGA and SSOP-T packages
Manual soldering
– for packages with a thickness ≥ 2.5 mm
– for packages with a thickness < 2.5 mm and a
Fix the component by first soldering two
diagonally-opposite end leads. Use a low voltage (24 V or
less) soldering iron applied to the flat part of the lead.
Contact time must be limited to 10 seconds at up to
300 °C.
volume ≥ 350 mm3 so called thick/large packages.
• below 235 °C (SnPb process) or below 260 °C (Pb-free
process) for packages with a thickness < 2.5 mm and a
volume < 350 mm3 so called small/thin packages.
When using a dedicated tool, all other leads can be
soldered in one operation within 2 to 5 seconds between
270 and 320 °C.
Moisture sensitivity precautions, as indicated on packing,
must be respected at all times.
Wave soldering
Conventional single wave soldering is not recommended
for surface mount devices (SMDs) or printed-circuit boards
with a high component density, as solder bridging and
non-wetting can present major problems.
2003 Nov 07
20
Philips Semiconductors
Product specification
SDH/SONET, Fibre Channel and Gigabit
Ethernet multi-rate fibre optic transmitter
TZA3057HW
Suitability of surface mount IC packages for wave and reflow soldering methods
SOLDERING METHOD
PACKAGE(1)
WAVE
not suitable
REFLOW(2)
BGA, LBGA, LFBGA, SQFP, SSOP-T(3), TFBGA, VFBGA
suitable
suitable
DHVQFN, HBCC, HBGA, HLQFP, HSQFP, HSOP, HTQFP,
HTSSOP, HVQFN, HVSON, SMS
not suitable(4)
PLCC(5), SO, SOJ
LQFP, QFP, TQFP
SSOP, TSSOP, VSO, VSSOP
PMFP(8)
suitable
suitable
not recommended(5)(6) suitable
not recommended(7)
suitable
not suitable
not suitable
Notes
1. For more detailed information on the BGA packages refer to the “(LF)BGA Application Note” (AN01026); order a copy
from your Philips Semiconductors sales office.
2. All surface mount (SMD) packages are moisture sensitive. Depending upon the moisture content, the maximum
temperature (with respect to time) and body size of the package, there is a risk that internal or external package
cracks may occur due to vaporization of the moisture in them (the so called popcorn effect). For details, refer to the
Drypack information in the “Data Handbook IC26; Integrated Circuit Packages; Section: Packing Methods”.
3. These transparent plastic packages are extremely sensitive to reflow soldering conditions and must on no account
be processed through more than one soldering cycle or subjected to infrared reflow soldering with peak temperature
exceeding 217 °C ± 10 °C measured in the atmosphere of the reflow oven. The package body peak temperature
must be kept as low as possible.
4. These packages are not suitable for wave soldering. On versions with the heatsink on the bottom side, the solder
cannot penetrate between the printed-circuit board and the heatsink. On versions with the heatsink on the top side,
the solder might be deposited on the heatsink surface.
5. If wave soldering is considered, then the package must be placed at a 45° angle to the solder wave direction.
The package footprint must incorporate solder thieves downstream and at the side corners.
6. Wave soldering is suitable for LQFP, TQFP and QFP packages with a pitch (e) larger than 0.8 mm; it is definitely not
suitable for packages with a pitch (e) equal to or smaller than 0.65 mm.
7. Wave soldering is suitable for SSOP, TSSOP, VSO and VSSOP packages with a pitch (e) equal to or larger than
0.65 mm; it is definitely not suitable for packages with a pitch (e) equal to or smaller than 0.5 mm.
8. Hot bar or manual soldering is suitable for PMFP packages.
2003 Nov 07
21
Philips Semiconductors
Product specification
SDH/SONET, Fibre Channel and Gigabit
Ethernet multi-rate fibre optic transmitter
TZA3057HW
DATA SHEET STATUS
DATA SHEET
STATUS(1)
PRODUCT
STATUS(2)(3)
LEVEL
DEFINITION
I
Objective data
Development This data sheet contains data from the objective specification for product
development. Philips Semiconductors reserves the right to change the
specification in any manner without notice.
II
Preliminary data Qualification
This data sheet contains data from the preliminary specification.
Supplementary data will be published at a later date. Philips
Semiconductors reserves the right to change the specification without
notice, in order to improve the design and supply the best possible
product.
III
Product data
Production
This data sheet contains data from the product specification. Philips
Semiconductors reserves the right to make changes at any time in order
to improve the design, manufacturing and supply. Relevant changes will
be communicated via a Customer Product/Process Change Notification
(CPCN).
Notes
1. Please consult the most recently issued data sheet before initiating or completing a design.
2. The product status of the device(s) described in this data sheet may have changed since this data sheet was
published. The latest information is available on the Internet at URL http://www.semiconductors.philips.com.
3. For data sheets describing multiple type numbers, the highest-level product status determines the data sheet status.
DEFINITIONS
DISCLAIMERS
Short-form specification
The data in a short-form
Life support applications
These products are not
specification is extracted from a full data sheet with the
same type number and title. For detailed information see
the relevant data sheet or data handbook.
designed for use in life support appliances, devices, or
systems where malfunction of these products can
reasonably be expected to result in personal injury. Philips
Semiconductors customers using or selling these products
for use in such applications do so at their own risk and
agree to fully indemnify Philips Semiconductors for any
damages resulting from such application.
Limiting values definition Limiting values given are in
accordance with the Absolute Maximum Rating System
(IEC 60134). Stress above one or more of the limiting
values may cause permanent damage to the device.
These are stress ratings only and operation of the device
at these or at any other conditions above those given in the
Characteristics sections of the specification is not implied.
Exposure to limiting values for extended periods may
affect device reliability.
Right to make changes
Philips Semiconductors
reserves the right to make changes in the products -
including circuits, standard cells, and/or software -
described or contained herein in order to improve design
and/or performance. When the product is in full production
(status ‘Production’), relevant changes will be
Application information
Applications that are
communicated via a Customer Product/Process Change
Notification (CPCN). Philips Semiconductors assumes no
responsibility or liability for the use of any of these
products, conveys no licence or title under any patent,
copyright, or mask work right to these products, and
makes no representations or warranties that these
products are free from patent, copyright, or mask work
right infringement, unless otherwise specified.
described herein for any of these products are for
illustrative purposes only. Philips Semiconductors make
no representation or warranty that such applications will be
suitable for the specified use without further testing or
modification.
2003 Nov 07
22
Philips Semiconductors – a worldwide company
Contact information
For additional information please visit http://www.semiconductors.philips.com.
Fax: +31 40 27 24825
For sales offices addresses send e-mail to: sales.addresses@www.semiconductors.philips.com.
© Koninklijke Philips Electronics N.V. 2003
SCA75
All rights are reserved. Reproduction in whole or in part is prohibited without the prior written consent of the copyright owner.
The information presented in this document does not form part of any quotation or contract, is believed to be accurate and reliable and may be changed
without notice. No liability will be accepted by the publisher for any consequence of its use. Publication thereof does not convey nor imply any license
under patent- or other industrial or intellectual property rights.
Printed in The Netherlands
403510/02/pp23
Date of release: 2003 Nov 07
Document order number: 9397 750 11711
厂商 型号 描述 页数 下载

RHOMBUS-IND

 		TZA1-10 TZA / TYA系列5抽头高性能无源延时模块[ TZA / TYA Series 5-Tap High Performance Passive Delay Modules ] 1 页

RHOMBUS-IND

 		TZA1-20 TZA / TYA系列5抽头高性能无源延时模块[ TZA / TYA Series 5-Tap High Performance Passive Delay Modules ] 1 页

RHOMBUS-IND

 		TZA1-5 TZA / TYA系列5抽头高性能无源延时模块[ TZA / TYA Series 5-Tap High Performance Passive Delay Modules ] 1 页

RHOMBUS-IND

 		TZA1-7 TZA / TYA系列5抽头高性能无源延时模块[ TZA / TYA Series 5-Tap High Performance Passive Delay Modules ] 1 页

RHOMBUS-IND

 		TZA10-10 TZA / TYA系列5抽头高性能无源延时模块[ TZA / TYA Series 5-Tap High Performance Passive Delay Modules ] 1 页

RHOMBUS-IND

 		TZA10-20 TZA / TYA系列5抽头高性能无源延时模块[ TZA / TYA Series 5-Tap High Performance Passive Delay Modules ] 1 页

RHOMBUS-IND

 		TZA10-5 TZA / TYA系列5抽头高性能无源延时模块[ TZA / TYA Series 5-Tap High Performance Passive Delay Modules ] 1 页

RHOMBUS-IND

 		TZA10-7 TZA / TYA系列5抽头高性能无源延时模块[ TZA / TYA Series 5-Tap High Performance Passive Delay Modules ] 1 页

NXP

 		TZA1000 QIC读写放大器[ QIC read-write amplifier ] 24 页

NXP

 		TZA1000T/N3 [ IC 1 CHANNEL READ WRITE AMPLIFIER CIRCUIT, PDSO24, 7.50 MM, PLASTIC, SOT-137-1, SOP-24, Drive Electronics ] 26 页

购物指南

支付方式

配送服务

售后服务

发票须知

优惠券使用规则

特色服务

PCBA制造

国产品牌推荐

国产料号替代

质量保证

技术资料

行业资讯

关于我们

关于壹壹捌

联系我们

联系我们

服务热线：400-618-9990

企业邮箱：sales@ic118.com

服务时间：周一至周六 8:30-17:30

壹壹捌官方微信号

PDF索引：

A

B

C

D

E

F

G

H

I

J

K

L

M

N

O

P

Q

R

S

T

U

V

W

X

Y

Z

0

1

2

3

4

5

6

7

8

9

IC型号索引：

A

B

C

D

E

F

G

H

I

J

K

L

M

N

O

P

Q

R

S

T

U

V

W

X

Y

Z

0

1

2

3

4

5

6

7

8

9

Copyright 2024 gkzhan.com Al Rights Reserved 京ICP备06008810号-21 京

深圳网络警察报警平台
公共信息安全网络监察
经营性网站备案信息
不良信息举报中心
工商网监电子标识
全国公安机关备案
0.230416s
