F-213
QTS–025–01–F–D–RA
®
(0,635 mm) .025"
QTS-RA SERIES
QTS–050–01–F–D–RA–WT
RIGHT ANGLE GROUND PLANE HEADER
Right
Angle
Integral metal plane
for power or ground
Board Mates:
QSS
SPECIFICATIONS
For complete specifications and
recommended PCB layouts see
www.samtec.com?QTS-RA
Selectively
plated
Insulator Material:
Liquid Crystal
Polymer
Rated @ 3dB
Terminal Material:
Phosphor Bronze
Plating:
QTS-RA/QSS-RA Type
Insertion Loss*
APPLICATIONS
Single-Ended
–D
4.50 GHz / 9 Gbps
Au or Sn over
Signaling
50µ" (1,27 µm) Ni
Current Rating:
1.2A per contact @ 30°C
Temperature Rise
Operating Temp Range:
-55°C to +125°C
Voltage Rating:
275 VAC mated with QSS-RA
RoHS Compliant:
Yes
Differential Pair
–D
4.50 GHz / 9 Gbps
Signaling
Rated @ 3dB
Insertion Loss*
QTS-RA/QSS
Type
–D
HORIZONTAL
Single-Ended
Signaling
5.5 GHz / 11 Gbps
6.0 GHz / 12 Gbps
Differential Pair
Signaling
–D
*Performance data includes effects of a
non-optimized PCB.
Processing:
Lead–Free Solderable:
Yes
SMT Lead Coplanarity:
(0,10 mm) .004" max (025-075)
Guide
Post
Complete test data available at
www.samtec.com?QTS-RA or contact
sig@samtec.com
PERPENDICULAR
PLATING
OPTION
NO. OF POSITIONS
OTHER
OPTION
RA
01
D
WT
QTS
PER ROW
–SP
= Solder
Pin
®
–F
–WT
–025, –050, –075
= Gold Flash on Signal Pins
and Ground Plane,
= Weld Tab
(Not available on
25 positions)
(50 total positions per bank)
Matte Tin on tails
–L
= 10µ" (0,25 µm) Gold on Signal
Pins and Ground Plane,
Matte Tin on tails
APPLICATION
SPECIFIC OPTION
• Guide posts
• Weld tabs
• 30µ" (0,76 µm) Gold
• Differential Pair
• “Partitionable” (combine
differential & single-ended
banks in same connector)
(No. of Positions per Row/25)
• PCB mounting
holes
x (20,00) .7875 + (14,73) .580
(No. of Positions per Row/25)
x (20,00) .7875 + (8,38) .330
• Solder pin
option
(3,18) .125 DIA
(6,35) .250 DIA
(10,29)
.405
(3,05)
.120
(1,40)
.055
• Lead Style for (2,36 mm)
.093" thick board
(7,11)
.280
• –LS1 Locking Screw
(Mates with QSS-RA-LS1)
• –LS2 Locking Screw
(Mates with QSS-LS2)
• 100 positions per row
Call Samtec.
(3,18)
.125
DIA
(0,89)
.035 DIA
(5,08) .200
(No. of Positions per Row/25)
x (20,00) .7875 + (5,72) .225
–SP OPTION
01
02
(1,50)
.059
(5,97) (9,42)
.235 .371
(0,10)
.004
(0,20) .008
(0,30)
.012
(0,635)
(0,38) .015
(2,03) .080
(0,635)
.025
Note: Some lengths,
.025 SQ
(1,73)
.068
styles and options are
non-standard, non-returnable.
