Product Name
Series
Type
Chip Beads Array
MZA Series
3216 Type
Part Number
MZA3216D301CT000
Product Lifecycle Stage PROD
Specification
Summary/Applications/Feature
The MZA series provide effective EMC
Mounting Method Flag
Processing
Yes
suppression in signal lines through simple in-
series implementation. 4lines array component.
It is applicable for lead free soldering.
MULTI-LAYER
Chip-Array
Summary
Shape
Number of Circuits
Material Code
Size Code
Nom
4
Applications PC,DVD,CDMA,LCD,PDC
D
The MZA series provide effective EMC
suppression in signal lines through simple in-
series implementation.
4lines array component.
3216
Feature
Body Length(L)
Body Breadth(W)
Body Height(T)
Impedance
Nom
Nom
Nom
Min
3.2 m m
1.6 m m
0.8 m m
225 Ohm
300 Ohm
-25 %
It is applicable for lead free soldering.
Packaging
Packing
Punched (Paper)Taping
[180mm Reel]
Impedance
Nom
Min
Minumum Package Qty Nom
Minimum Order Qty Nom
4000 Pcs
4000 Pcs
Impedance Tolerance
Max
Nom
Max
Max
Max
Min
25 %
Frequency of Impedance
Rated Voltage
100 M Hz
5 V
Rated Current
0.1 A
DC Resistance
0.8 Ohm
10 M Ohm
Reflow,Iron Soldering
Insulation Resistance
Soldering Method
Min
Max
Min
Max
Nom
-55 Cel
125 Cel
-55 Cel
125 Cel
0.015 g
Category Temperature
Range
Storage Temperature Range
Weight
[ Caution ]
Specifications which provide more details for the proper
and safe use of the described product are available upon request.
[ Notice of Revision and Improve ]
All specifications are subject to change without notice.
