3SS30L
SURFACE MOUNT SCHOTTKY BARRIER RECTIFIER
30 Volts
VOLTAGE
Amperes
CURRENT 3.0
FEATURES
* Ideal for surface mounted applications
* Low leakage current
* Metallurgically bonded construction
* Mounting position: Any
SOD-123FL
.114 (2.9)
.106 (2.7)
MECHANICAL DATA
* Epoxy: Device has UL flammability classification 94V-O
.077 (1.95)
.069 (1.75)
.035 (0.90)
.028 (0.70)
.008 (0.20)
.039 (1.00)
.035 (0.90)
.150 (3.8)
.142 (3.6)
.059 (1.50)
.043 (1.10)
MAXIMUM RATINGS AND ELECTRICAL CHARACTERISTICS
Ratings at 25 oC ambient temperature unless otherwise specified.
Single phase, resistive or inductive load.
.033 (0.85)
.014 (0.35)
.033 (0.85)
.030 (0.75)
.051 (1.3)
.035 (0.9)
Dimensions in inches and (millimeters)
O
MAXIMUM RATINGS (@ T
A
=25 C unless otherwise noted)
SYMBOL
VRRM
3SS30L
30
UNITS
Volts
Volts
Volts
RATINGS
Maximum Recurrent Peak Reverse Voltage
Maximum RMS Voltage
VRMS
21
VDC
30
Maximum DC Blocking Voltage
Max Avg Forword Rectify Current at Ambient Temp needs
To be corrected to Lead Temperature,TL
IO
3.0
Amps
Peak Forward Surge Current 8.3 ms single half sine-wave
superimposed on rated load (JEDEC method)
IFSM
I2T
50
Amps
A2S
10.37
Typical Current Square Time
R
R
55
17
J A
J L
0C/W
Typical Thermal Resistance (Note 1)
Typical Junction Capacitance (Note 2)
Operating Temperature Range
Storage Temperature Range
CJ
TJ
TSTG
200
-55 to + 150
pF
0 C
0 C
-55 to + 150
O
ELECTRICAL CHARACTERISTICS(@T
A
=25 C unless otherwise noted)
3SS30L
0.44
0.3
CHARACTERISTICS
Maximum Instantaneous Forward Voltage at 3.0A DC
SYMBOL
UNITS
Volts
VF
IR
@TA = 25oC
mA
mA
Maximum Average Reverse Current
@T
oC
at Rated DC Blocking Voltage
20
A = 150
NOTES : 1. Thermal Resistance : Mounted on PCB.
2019-03
REV: A
2. Measured at 1 MHz and applied reverse voltage of 4.0 volts.
3. “ROHS compliant”.
