Signal Converters & Isolators
Threshold Relay PXL-10
TECHNICALDATA
WIRING DIAGRAM
Input
0
-
I
IN
VIN
+
Input:
+
Input signal
0-5V DC
0-10V DC
-10-+10V DC
0-20mA DC
4-20mA DC
Impedance
>100kOhm
>100kOhm
>100kOhm
50 Ohm
A1
15
Y2
Z3
Y3
Umax = 50Vp-p
MAX = 50mA
Latch
active
Y1
15
I
Inversion
relay
µ
50 Ohm
Coding:
Relay inverter: Z1-Z2
Latching:
16 18
A3
16
Z1
18
Z2
A2
Selected via switches on the front panel.
Z1-Z3
Hysteresis:
Response time:
±0,5-20% of range, adjustable.
Time constant (τ = approx. 0,3s,
worst case of response time max. 5xτ).
L(115/230) L(24V)
+ (24V)
N
-(0V)
AC supply
DC supply
Upper critical frequency 30 Hz.
Output:
SPDT relay:
Contact material, AgNi 0,15 with hardened
gold plating Au.
SPECIFICATIONS:
Max load AC:
8A/240V AC (cos ϕ=1)
Max. breaking capacity2000VA.
Inductive load. See fig. 1.
8A/24V DC.
PXL-10 is designed and developed with regard to relevant specifi-
cations:
• EN60204-1 / VDE0113 electrical material on machines.
Max load DC:
Max.breakingcapacity50-270W. Seefig. 2.
• VDE0110 / IEC664 Isolation specifications/creepage and clear-
Max. in rush
current:
Min. in rush
current:
Frequency :
Life span:
ance
distances.
15A (max. 4s/duty cycle less than 10%)
• Electrical safety in accordance with EN61010.
• IEC414 Safety regulations for control and monitoring equipment.
10mA, 24V DC.
• EMC:
Emission EN50081-1
Immunity EN50082-2
Max. 1000 operations pr. hour.
Mech. Min. 3 x 107 operations.
Elect. Min. 1x 105 operations with full load.
<20ms.
• Humidity in accordance with IEC68-2-3; RH=95%, 40°C.
• Vibration in accordance with IEC68-2-6:
• Shock when mounted, in accordance with IEC68-2-27.
Delay:
PXL-10 is CE-marked in accordance with EMC-and the Low Voltage
Directive.
Supply voltage:
Versions:
924 = 24V DC (20,4-27,6)V DC
115 = 24/115V AC (20,4-27,6/98-132)V AC
230 = 24/230V AC (20,4-27,6/196-264)V
AC
OUTPUT LOAD DIAGRAMS
Net frequency:
Consumption:
45-65Hz
AC; 3VA
DC; 2W
Fig. 1
1,0
Generaldata:
Ambienttemperature:-20to55°C.
0,9
Storage temperature:-40 to 80°C.
0,8
0,7
Mounting:
Terminals:
35mm DIN-rail (EN50022).
Screw terminals with dual compartment.
Terminal screws are combined
crosshead/slotted.
0,6
0,5
eRudinfacrto
Up to 2 x 2,5mm2 wire (2 x 1,5mm2
inc. ferrule).
0,4
0,2
0,4
0,6
0,8
1,0
ϕ
Recommendedtorque,0,5Nm.,
max. 0,7 Nm. (VDE0609-1).
Terminal identification in accordance with
DIN46199/EN50005.
cos
Fig. 2
U [V]
300
Indicators:
Green LED = operating voltage.
Red LED = relay switched on.
IP20.
3,75kVAC (1 min.) between input,
supply and relay output (EN60950).
Noryl (GE), UL94V1.
200
100
50
Protection:
Electric isolation:
20
Housing:
Terminal block:
Weight:
Noryl (GE), UL94V0.
180 g.
0,1 0,2 0,5
1,0
2,0
5,0
8,0 I [A]
