8XC51SL/LOW VOLTAGE 8XC51SL
PORT STRUCTURES AND
OPERATION
Idle Mode
Idle mode is initiated by an instruction that sets the
PCON.0 bit (SFR address 87H) in the 51SL. In Idle
mode, the internal clock signal to the 51SL CPU is
gated off, but not to the interrupt timer and Serial
Port functions. The 51SL status is preserved in its
entirety: the Stack Pointer, Program Counter, Pro-
gram Status Word, Accumulator, and all other regis-
ters maintain their data. The port pins hold the logic
levels they had when Idle mode was activated. ALE
and PSENL are held high. If an A/D conversion is in
process when Idle mode is entered, any conversion
results may contain erroneous data. Idle mode is ex-
ited via a hardware reset, or an enable interrupt.
All three 51SL ports are bidirectional. Each consists
of a latch (Special Function Registers P1 through
P3), an output driver, and an input buffer. Port 0 of
the 51SL CPU does not connect to the package
pins. It is used internally to drive the keyboard scan
logic.
The output drivers of ports 1 and 2 can be used in
accesses to external memory. The 51SL provides
the LOADREN signal to facilitate external memory
interfaces. When the LOADREN signal is high, Port
1 outputs the low byte of the external memory ad-
dress. If LOADREN is tied low, then the Port 1 sig-
nals continue to emit the P1 SFR content. Port 2
outputs the upper seven bits of the high byte of the
external address when the address is 15 bits wide
and either EAL is tied low or EAL is tied high and Bit
0 (ADDREN) of configuration register 1 is set. Other-
wise, the Port 2 pins continue to emit the P2 SFR
content.
Power Down Mode
Power Down mode is initiated by an instruction that
sets bit PCON.1 in the 51SL CPU. When the 51SL
enters Power Down mode, all internal clocks, includ-
ing the 51SL core clock, are turned off. If an external
crystal is used, the internal oscillator is turned off.
MEMCSL, the external memory select signal, goes
inactive unless it is configured as a general purpose
I/O (i.e., unless bit 3 of configuration register 1 is a
‘‘1’’). ALE and PSENL are both forced low. RAM
contents are preserved.
I/O Configurations
All port pins with the exception of P27/LED4,
P30/SIF00, P31/SIF01, P33/SIF10, and P35/SIF11
have fixed internal pullups and therefore are called
‘‘quasi-bidirectional ports’’. When configured as in-
puts, the pins are pulled high by the pullups and will
source current when externally pulled low.
Power Down mode can only be exited via a reset.
This reset may occur either from the RST pin, or an
internally generated reset. See the 51SL Hardware
Ý
Description (Order No. 272268) for a detailed de-
scription of this reset.
During a 15-bit external program memory access,
Port 2 outputs the high address byte. In the 80C51
the Port 2 drivers use the strong pullup during the
entire time that they are emitting a ‘‘1’’ on a Port 2
bit. In this instance, the 80C51 weak quasi-bidirec-
tional pullup condition that normally occurs after two
oscillator periods does not occur. Port 1 and Port 2
of the 51SL emulate the quasi-bidirectional pullup
condition during program memory access, not this
extended strong pullup condition.
HOST INTERFACE
The 51SL host interface is functionally compatible
with the 8042 style UPI interface. It consists of the
PCDB0–7 data bus; the RDL, WRL, A0 and CSL
control signals; and the Keyboard Status register,
Input Data register, and Output Data register. In ad-
dition, a second address line, A1, has been added to
decode a second set of registers for power manage-
ment functions. These registers are identical to the
keyboard registers. The host interface also includes
a PCOBF interrupt, GATEA20, and host reset (RCL)
outputs. Two additional OBF signals, AUXOBF1 and
AUXOBF2 are available through firmware configura-
tion of P34/T0 and P37/RDL respectively.
POWER MANAGEMENT
The 51SL uses low power CHMOS and provides for
two further power savings modes, available when in-
active: Idle mode, typically between keystrokes; and
Power Down mode, upon command from the host. A
four channel, eight-bit A/D converter is also includ-
ed for power management (i.e., battery voltage/tem-
perature monitoring, etc.).
