OZ2206

型号：

OZ2206

描述：

电源开关\n[ Power Switches ]

品牌：

ETC[ ETC ]

页数：

7 页

PDF大小：

47 K

下载PDF手册
OZ2206
Short Form Datasheet
Dual-Slot Serial PCMCIA/CardBus Power Controller
FEATURES
GENERAL DESCRIPTION
The OZ2206 is a dual slot PCMCIA (Personal Computer
Memory Card International Association) PC Card and
CardBus power controller. It is used in conjunction with a
serial data output, CardBus controller to control and
distribute Vcc and Vpp voltages to two PC Card slots.
When connected to 3.3V, 5V, and 12V system power
supplies, the OZ2206 can switch its Vcc and Vpp outputs
between 0V, 3.3V, and 5.0V, in accordance with the control
commands from the three-wire serial interface. The
OZ2206 also features low on-resistance MOSFET switches
for 5V and 3.3V Vcc.
•
Complete VCC and VPP switch for dual-slot PC Card
interface
Standard 3-wire serial interface compatible with
CardBus Controllers
High-efficiency, low-resistance switches
Meets PC Card standard
Compatible with 3.3V, 5V and 12V PC Cards
Operates in 3.3V low voltage mode when 3.3V is the
only available input voltage
Current limit and over temperature shutdown
12V supply can be disabled except during 12V Flash
memory programming
Break-before-make switching
Low on-resistance for 5V Vcc
•
•
•
•
•
•
•
The OZ2206 operation does not require 12V and 5V
supplies, making it possible to operate the PC cards in low-
power 3.3V modes. The internal logic and the MOSFET
drive circuitry are powered by the 3V supply input.
•
•
•
Low on-resistance for 3.3V Vcc
The OZ2206 is protected by over temperature shutdown,
and it protects itself and the system with current limiting
and cross-conduction lockout.
ORDERING INFORMATION
The OZ2206 is designed for full compatibility with the
PCMCIA PC Card Specification, including the CardBus and
Zoomed Video (ZV) options, and is pin-to-pin compatible
with Texas Instrument’s TPS2206/2216.
OZ2206S – 30-pin SSOP
OZ2206R – 32-pin TSSOP
09/11/02
Copyright © 2001 - 02 by O2Micro
OZ2206-SF-1.0
All Rights Reserved
Page 1
OZ2206
PIN CONFIGURATION – 30 PIN
OZ2206
5V
5V
1
2
3
4
5
6
30
29
28
27
26
25
5V
•
NC
NC
NC
NC
NC
DATA
CLOCK
LATCH
RESET
12V
AVPP
AVCC
AVCC
AVCC
GND
7
24
23
22
21
20
19
18
17
16
12V
8
BVPP
BVCC
BVCC
BVCC
NC
9
10
11
12
13
14
15
NC
OC#
RESET#
3.3V
3.3V
3.3V
OZ2206-SF-1.0
Page 2
OZ2206
PIN CONFIGURATION – 32 PIN
OZ2206
5V
5V
1
2
3
4
5
6
32
31
30
29
28
27
5V
•
NC
NC
NC
NC
NC
NC
DATA
CLOCK
LATCH
RESET
12V
7
26
25
24
23
22
21
20
19
18
17
NC
8
12V
AVPP
AVCC
AVCC
AVCC
GND
9
BVPP
BVCC
BVCC
BVCC
OC#
NC
10
11
12
13
14
15
16
RESET#
NC
3.3V
3.3V
3.3V
OZ2206-SF-1.0
Page 3
OZ2206
PIN DESCRIPTION
Pin No.
Name
Pin No.
30-pin SSOP 32-pin SSOP
I/O
Description
5V
5V
1
2
3
4
5
1
2
4
5
6
I
I
I
I
I
5V VCC input for card power.
5V VCC input for card power.
Serial data word.
Clock for serial data word.
Latch for serial data word.
DATA
CLOCK
LATCH
RESET
12V
Reset, active high. Do not connect when Pin 14 is used.
12V VPP input for card power.
6
7
7
8
I
I
AVPP
AVCC
AVCC
AVCC
GND
8
9
10
11
12
13
9
O
O
O
O
Slot A VPP output that delivers 0V, 3.3V, 5V, 12V, or Hi-Z to card.
Slot A VCC output that delivers 0V, 3.3V, 5V, or Hi-Z to card.
Slot A VCC output that delivers 0V, 3.3V, 5V, or Hi-Z to card.
Slot A VCC output that delivers 0V, 3.3V, 5V, or Hi-Z to card.
10
11
12
13
15
GND Ground.
No internal connection.
NC
Reset, active low. Do not connect when Pin 6 (for 30-pin) or Pin 7
(for 32-pin) is used.
RESET#
14
14
I
3.3V
3.3V
3.3V
15
16
17
16
17
18
I
I
I
3.3V VCC input for card power and/or chip power.
3.3V VCC input for card power and/or chip power.
3.3V VCC input for card power and/or chip power.
Over-current output goes low when an over-current/over-temperature
condition exists. See Note 1.
OC#
18
20
O
NC
BVCC
BVCC
BVCC
BVPP
12V
NC
NC
NC
NC
NC
19
20
21
22
23
24
25
26
27
28
29
30
-
19
21
22
23
24
25
26
27
28
29
30
32
31
3
No internal connection.
O
O
O
O
I
Slot B VCC output that delivers 0V, 3.3V, 5V, or Hi-Z to card.
Slot B VCC output that delivers 0V, 3.3V, 5V, or Hi-Z to card.
Slot B VCC output that delivers 0V, 3.3V, 5V, or Hi-Z to card.
Slot B VPP output that delivers 0V, 3.3V, 5V, 12V, or Hi-Z to card.
12V VPP input for card power.
No internal connection.
No internal connection.
No internal connection.
No internal connection.
No internal connection.
5V VCC input for card power.
No internal connection.
No internal connection.
5V
NC
NC
I
-
Note 1: For PC-Card applications, it is suggested that this pin is left as ‘No Connection’.
OZ2206-SF-1.0
Page 4
OZ2206
PACKAGE SPECIFICATIONS – 30 PIN SSOP (209 MIL)
L1
R1
R1
GAUGE PLANE
L
DETAIL A
e
D
b
c
DETAIL A
B
*Notes: Dimension "D" does not include
mold flash or protrusions, but does include
mold mismatch. Mold flash or protrusion
shall not exceed 0.20MM per side.
E1
E
A2
A
A1
Dimension In MM
Dimension in Inch
Symbol
Min.
Nom.
Max.
Min.
-
0.002
0.065
0.009
0.004
Nom.
-
-
Max.
0.079
-
0.073
0.013
0.008
A
A1
A2
b
c
e
D
E
E1
L
L1
R1
-
-
-
2.0
-
0.05
1.65
0.22
0.09
1.75
0.30
0.15
0.65 Basic
10.20
7.80
5.30
0.75
1.25 Ref.
-
1.85
0.33
0.21
0.069
0.012
0.006
0.026 Basic
0.402
0.307
0.209
0.030
0.049 Ref.
-
9.90
7.40
5.00
0.55
10.50
8.20
5.60
0.95
0.390
0.291
0.197
0.022
0.413
0.323
0.220
0.038
0.09
0
-
8
0.004
0
-
8
4
4
JEDEC
MO-150 (AJ)
OZ2206-SF-1.0
Page 5
OZ2206
PACKAGE SPECIFICATIONS – 32 PIN TSSOP
L1
R
R1
GAUGE PLANE
DETAIL A
e
L
L1
D
b
c
DETAIL A
A1
A2
A
E1
E
Dimension In MM
Dimension in Inch
Symbol
Min.
Nom.
-
Max.
1.20
Min.
Nom.
Max.
A
A1
A2
b
-
-
-
-
0.043
0.006
0.041
0.012
0.008
0.05
0.80
0.19
0.09
-
0.15
1.05
0.30
0.20
0.002
0.031
0.007
0.004
0.90
-
-
0.035
-
-
c
e
0.65 Basic
0.026 Basic
D
10.90
11
11.1
-
-
-
E
8.10 Basic
0.319 Basic
E1
L
6.00
0.50
6.10
0.60
6.20
0.75
0.236
0.020
0.240
0.024
0.244
0.030
L1
R
R1
1.0 Ref.
0.039 Ref.
0.09
0.09
0
-
-
-
-
-
8
0.004
0.004
0
-
-
-
-
-
8
JEDEC
MO-153 (DC)
OZ2206-SF-1.0
Page 6
OZ2206
IMPORTANT NOTICE
No portion of O2Micro specifications/datasheets or any of its subparts may be reproduced in any form, or by any means,
without prior written permission from O2Micro.
O2Micro and its subsidiaries reserve the right to make changes to their datasheets and/or products or to discontinue any
product or service without notice, and advise customers to obtain the latest version of relevant information to verify, before
placing orders, that information being relied on is current and complete. All products are sold subject to the terms and
conditions of sale supplied at the time of order acknowledgment, including those pertaining to warranty, patent infringement,
and limitation of liability.
O2Micro warrants performance of its products to the specifications applicable at the time of sale in accordance with O2Micro’s
standard warranty. Testing and other quality control techniques are utilized to the extent O2Micro deems necessary to support
this warranty. Specific testing of all parameters of each device is not necessarily performed, except those mandated by
government requirements.
Customer acknowledges that O2Micro products are not designed, manufactured or intended for incorporation into any systems
or products intended for use in connection with life support or other hazardous activities or environments in which the failure of
the O2Micro products could lead to death, bodily injury, or property or environmental damage (“High Risk Activities”). O2Micro
hereby disclaims all warranties, and O2Micro will have no liability to Customer or any third party, relating to the use of O2Micro
products in connection with any High Risk Activities.
Any support, assistance, recommendation or information (collectively, “Support”) that O2Micro may provide to you (including,
without limitation, regarding the design, development or debugging of your circuit board or other application) is provided “AS
IS.” O2Micro does not make, and hereby disclaims, any warranties regarding any such Support, including, without limitation,
any warranties of merchantability or fitness for a particular purpose, and any warranty that such Support will be accurate or
error free or that your circuit board or other application will be operational or functional. O2Micro will have no liability to you
under any legal theory in connection with your use of or reliance on such Support.
COPYRIGHT © 2002, O2Micro International Limited
OZ2206-SF-1.0
Page 7
