Blade Fuses
MAXI® BLADE FUSE RATED 58V
Specifications
Voltage Rating:
58 VDC
Interrupting Ratings:
Operating Temperature Range:
Terminals:
Housing Material:
Complies with:
1000A @ 58 VDC
-40˚C to +125˚C
Ag plated zinc alloy
PA66
SAE J 1888
ISO 8820-3:2002(E)
Ordering Information
Part Number
Package Size
0999xxx.ZXN
1200
Dimensions
Description
The MAXI® fuse uses “Diffusion Pill Technology” to provide
predictable time delay characteristic and low heat dissipation.
Dimensions in mm
Time-Current Characteristics
% of Rating
Opening Time Min / Max (s)
100
135
200
350
600
360,000 s / –
60 s / 1,800 s
2 s / 60 s
0.20 s / 7 s
0.040 s / 1 s
Ratings
Part Number
Current Rating
Housing Color
Typ. Voltage Drop
Cold Resistance
I2t
0999020._
0999025._
0999030._
0999035._
0999040._
0999050._
0999060._
0999070._
0999080._
20 A
25 A
30 A
35 A
40 A
50 A
60 A
70 A
80 A
76 mV
75 mV
77 mV
75 mV
75 mV
73 mV
77 mV
61 mV
62 mV
3.10 mΩ
1100 A²s
2087 A²s
4070 A²s
6032 A²s
8450 A²s
11300 A²s
15300 A²s
6900 A²s
8800 A²s
2.39 mΩ
1.95 mΩ
1.71 mΩ
1.42 mΩ
1.10 mΩ
0.89 mΩ
0.64 mΩ
0.54 mΩ
Corresponding holder see Section “Fuse Holders.”
