1. SPECIFICATIONS OF
IN SERIES
Horizontal Surface Mounting Devices
SM
SANYO has succeeded in developing the chip-type OS-CON.
Ideal for use in products such as switching power supplies, VCRs,
etc. where a surface mounting design is necessary.
Series
Case color : Purple
Marking
: Polarity( ), Rated voltage,
Capacitance, Lot.No.
Specifications
Items
Characteristics
1. Operating temperature range
-55°C to +105°C
M : ±20%
2. Capacitance tolerance
(120Hz)
3. Tangent of loss angle(tanδ) (120Hz)
4. Leakage current (µA/2min.)(or less) *1
5. ESR (100k to 300kHz)
Value in Table 9 or less
A, B size 0.03CV or 1 (whichever is the greater) C, D, E size 0.05CV
Value in Table 9 or less
-55°C
Z / Z20°C
1.0 to 2.0
0.6 to 1.0
6. Temperature characteristics
Impedance ratio at 100kHz., +20°C
+105°C
Z / Z20°C
∆C/C
tanδ
Leakage current
∆C/C
Within ±20%
1.5 times of Item 3 or less
Item 4 or less
Within ±20%
1.5 times of Item 3 or less
Item 4 or less
7. High-temperature load
105°C, 2,000Hrs.
Rated voltage applied
8. Moisture resistance
(60°C, 90 to 95%RH, 500Hrs.
no voltage)
tanδ
Leakage current
9. Reverse voltage guarantee
Temporary:less than 20% of the rated voltage, Continuous:less than 10% of the rated voltage
∆C/C
tanδ
Leakage current
Within ±10%
2 times of Item 3 or less
Item 4 or less
10.Solder heat resistance (VPS) *2
(230°C X 10sec.)
*1 If any doubt arises, measure the current after applying voltage (voltage treatment) for 120 minutes at 105°C.
The rated voltage should be applied for all wv.
*2 The electrostatic capacity of SM series products may be changed by soldering such as reflow.
Refer to page 40 for soldering specifications.
Dimensions
(unit : mm)
Size Code
L
7.3
W
H
P
X
W1
-
A, B, E
Size
A
B
C
D
E
4.6
5.6
7.0
7.0
8.8
4.6
5.6
7.0
7.0
8.8
3.6
4.4
5.5
5.5
7.0
0.2max.
0.2max.
0.3max.
0.3max.
0.3max.
7.3
-
9.0
5.6
5.6
-
P±0.2
X
12.0
13.0
W+0.2max.
L+0.2max.
L+0.2max.
W+0.2max.
W1
3.4±0.3
C, D
Size
P±0.2
X
Recommended land pattern
dimension of PWB.
WV : Rated voltage
(SV) : Surge voltage(room temperature)
Size List
WV
(SV)
6.3
10
16
20
(23)
A
B
B
C
C
C
D
D
D
E
E
X
µF
(7.2)
(11.5)
(18.4)
1.0
2.2
3.3
4.7
6.8
10
15
22
33
47
68
100
150
Y
a
Y
A
A
B
B
(unit : mm)
a
A
B
C
A
B
X
Y
Size
A
B
C
D
E
4.7±0.1
4.7±0.1
4.7±0.1
4.7±0.1
4.7±0.1
2.0±0.1
2.2±0.1
2.5±0.1
2.5±0.1
2.8±0.1
1.6±0.1
2.2±0.1
3.0±0.1
3.0±0.1
4.2±0.1
C
C
C
D
D
E
E
