1SS355
200mW Surface Mount High speed Switching Diode
SOD-323 Flat Lead
RoHS
Pb
COMPLIANCE
Features
ꢀ
ꢀ
ꢀ
ꢀ
ꢀ
ꢀ
High Speed Switching Device (Trr < 4.0nS)
Flat Lead SOD-323 Small Outline Plastic Package
Surface Device Type Mounting
Moisture Sensitivity Level 1
Green EMC
Clip Bonding Construction, Good Thermal Capability
ꢀ
ꢀ
RoHS Compliant & Matte Tin(Sn) Lead Finish
Green compound with suffix "G" on packing code
& prefix "G" on datecode.
Mechanical Data
Dimensions in inches and (millimeters
ꢀ
ꢀ
ꢀ
Cases: Molded plastic
Epoxy: UL 94V-O rate flame retardant
Lead: Pure tin plated, lead free, solderable per
MIL-STD-202, Method 208 guaranteed
ELECTRICAL SYMBOL
ꢀ
ꢀ
Polarity: Color band denotes cathode.
High temperature soldering guaranteed: 260oC/10 seconds
/.375”,(9.5mm) lead lengths at 5 lbs., (2.3kg) tension
ꢀ
ꢀ
Weight: 0.006 gram
Marking code : S4
Maximum Ratings and Electrical Characteristics
Rating at 25℃ambient temperature unless otherwise specified.
Single phase, half wave, 60 Hz, resistive or inductive load.
For capacitive load, derate current by 20%
Type Number
Value
200
90
Units
mW
V
Symbol
PD
Power Dissipation
Repetitive Peak Reverse Voltage
Reverse Voltage
VRRM
VR
80
V
Minimum Breakdown Voltage at IR = 100uA
Forward Current
VBR
IF
80
V
250
150
500
100
1.2
mA
mA
mA
nA
V
Continue Forward Current
Io
Repetitive Peak Forward Current
Maximum Reverse Leakage Current at VR=80V
Maximum Forward Voltage at IF = 100mA
IFSM
IR
VF
Maximum Reverse Recovery Time
at IF = 10mA, VR=6V,RL=100Ohms
4
Trr
nS
Maximum Junction capacitance at VR=0.5V,f=1MHz
Operating Temperature Range
4
Cj
pF
OC
OC
TOPR
TSTG
-65 to +150
-65 to +150
Storage Temperature Range
Notes: These ratings are limiting values above which the serviceability of the diode may be impaired
Page : 1 of 1
Version : A08
