VER : A_0
update : 2013.08.08
AC-DC Power Module
AZC SERIES
2 Watts
KEY FEATURES
Switching Power Module for PCB Mountable
Fully Encapsulated Plastic Case
Universal Input Range 90-305VAC, 47-63 Hz
Isolation Class II
Maximum No-Load Watts < 0.3W
CE, CB and UL Approval
3-Years Product Warranty
ELECTRICAL SPECIFICATIONS
AZC-3.3S
2W
AZC-5S
AZC-9S
AZC-12S
AZC-15S
AZC-24S
Model No.
( Single Output )
Max Output Wattage (W)
Voltage
90-305 VAC or 120-430 VDC
47-63 Hz
Frequency (Hz)
Current (Full load)
75 mA max. (115 VAC) / 55 mA max. (230 VAC)
30 A max. (115 VAC) / 50 A max. (230 VAC)
0.25 mA max.
Input
Inrush Current (<2ms)
Leakage Current (<240 VAC)
External Fuse (recommend)
External Varistor
3.15 A slow blow type
10S471K
Voltage (V.DC.)
3.3V
5V
9V
12V
167
15V
133
24V
83
Voltage Accuracy
±6%
Current (mA) max
600
400
222
Line Regulation (LL-HL) (typ.)
Load Regulation (10-100%) (typ.)
Minimum Load
±5%
±6%
Output
0%
Maximum Capacitive Load
Ripple & Noise (Vp-p)
Efficiency (at 115 VAC)
Hold-up Time (at 230 VAC)
Over Power Protection
Short Circuit Protection
Input-Output (V.AC)
Operating Temperature
Storage Temperature
Temperature Coefficient
Humidity
7000uF
300mV
66%
4000uF
70%
1200uF
73%
500uF
73%
350uF
73%
110uF
75%
15 ms min.
Hiccup technique, auto-recovery
Protection
Isolation
Hiccup mode, indefinite (automatic recovery)
3000V
-40°C…+80°C ( with derating )
-40°C…+85°C
Environment
±0.02%/°C
95% RH
MTBF
>350,000 h @ 25°C (MIL-HDBK-217F)
Dimension (L x W x H)
Case Material
1.12 x 1.02 x 0.67 Inches ( 28.5 x 25.8 x 17.0 mm ) Tolerance 0.5 mm
Plastic resin with Fiberglass (flammability to UL 94V-0)
Pending
Physical
Weight
Cooling Method
Free air convection (Pending)
Safety
EMC
Agency Approvals
UL, cUL, CE, CB (Pending)
EMI (Conducted & Radiated Emission)
EMS (Noise Immunity)
EN 55022 class B (Pending)
EN 55024 (Pending)
1. All specifications valid at normal input voltage, full load and +25°C after warm-up time unless otherwise stated.
2. Ripple & Noise are measured at 20MHz of bandwidth with 0.1uF & 47uF parallel capacitor.
http://www.archcorp.com.tw
TEL: +886-2-26989508 FAX: +886-2-26981319
-1-
