MoCA
Hi-RF Front End IC
June 2010 - Rev 14-Jun-10
Z1003-QT
Features
MoCA Compliant Front-End IC
Linear Power Amplifier
Integrated PA Bias Control
Transmit/Receive Switch
Transmit Power Detector
Transmit Attenuator
Receive Attenuator
3.3 or 5 Volt Single Supply
Integrated Digital Control Logic
Compatible with EN2210 and EN2510
RoHs Compliant 3x3mm QFN Package
General Description
The XZ1003-QT is a front-end IC for MoCA Hi-RF applications which is compatible with current and future chipsets
from Entropic Communications. It is housed in an industry standard 3x3mm QFN package and operates from a single
3.3 or 5 volt supply. Circuit operating modes are digitally controlled by Entropic’s EN2510 and other compatible
chipsets.The XZ1003-QT includes a power amplifier, power detector, transmit/receive switch, switched attenuators, bias
circuits and digital control circuitry. A switched attenuator in the receiver provides an adjustable gain step set using
one external resistor.The integrated transmitter bias circuit stabilizes amplifier performance over temperature and
process variation with bias adjustment possible using an external pull-up/pull-down resistor.The transmit path
includes a power detector and switched attenuator to allow for transmit power calibration.
Contact Mimix Broadband for a complete datasheet.
