Mixer
The content of this specification may change without notification 7/01/09
Mixer
P/N: JXWBHP-T-3000-4000-7
RF Frequency(GHz)
LO Frequency(GHz)
IF Frequency(GHz)
Conversion Loss(dB)
LO Power(dBm)
3-4
3-4
DC-0.5
7 Typ.
+7
LO to RF Isolation(dB)
LO to IF Isolation(dB)
Connector
Operating Temperature(°C)
Storage Temperature(°C)
> 28
> 20
SMA-Female
-40 ~+80
-55 ~+85
Outline Drawing (Size: mm)
For current data sheets, please contact: sales@aacix.com
188 Technology Drive, Unit H, Irvine, CA 92618
1
Tel: 949-453-9888 Fax: 949-453-8889 Email: sales@aacix.com
American Accurate Components, Inc.
