Preliminary
XTL1030
• High Performance Crystal for Wide Temperature Applications
• Excellent Frequency Stability and Reliability
• Ultra-miniature Surface Mount Seam Weld Package
• Complies with Directive 2002/95/EC (RoHS)
24.305 MHz
Crystal Unit
P
b
The XTL1030 is a high stability 24.305 MHz crystal suitable for
TPMS and other wide temperature range applications.
SM3225-4 Case
Electrical Characteristics
Characteristic
Sym
Notes
Minimum
Typical
Maximum
Units
F
Nominal Frequency
24.305
MHz
O
Mode of Oscillation
Fundamental
Storage Temperature Range
Operating Temperature Range
Frequency Stability over Operating Temperature Range
Frequency Make Tolerance
Equivalent Series Resistance
Motional Capacitance
-40
-40
+125
+125
°C
°C
±50 ppm (referred to the value at 25 °C)
F
±30 ppm @ 25 °C ±3 °C
L
ESR
110
Ω
fF
C
3.0
M
C
Shunt Capacitance
1.5
pF
µW
pF
O
Nominal Drive Level
Load Capacitance
50
C
7
±10 ppm/10 year
500
L
Aging
Insulation Resistance
Standard Shipping Quantity on 178 mm (7”) Reel
Lid Symbolization
MΩ
units
3000
1030 YWWS
C
r
y
s
t
a
l
E
q
u
i
v
a
l
e
n
t
C
i
r
c
u
i
t
E
S
R
1
3
C
O
CAUTION: Electrostatic Sensitive Device. Observe precautions for handling.
Notes:
1.
2.
3.
US and international patents may apply.
The design, manufacturing process, and specifications of this device are subject to change without notice.
RFM, stylized RFM logo, and RF Monolithics, Inc. are registered trademarks of RF Monolithics, Inc.
www.RFM.com E-mail: info@rfm.com
©2010 by RF Monolithics, Inc.
Page 1 of 4
XTL1030 - 9/27/10
