XTL1014
•
•
•
•
Ulta-miniature Surface Mount Seam-weld Package
Good Frequency Stability over Temperature
Excellent Reliability
48.53000 MHz
Crystal Unit
Complies with Directive 2002/95/EC (RoHS)
P
b
The XTL1014 is a surface mount 2.5 x 2.0 x 0.6 mm crystal unit for use in wireless
telecommunications devices, especially where an ultra-miniature package is
needed for mobility.
SM2520-4 Case
Electrical Characteristics
Characteristic
Nominal Frequency
Load Capacitance
Mode of Vibration
Drive Level
Sym
Notes
Minimum
Typical
48.53000
8
Maximum
Units
MHz
pF
F
O
C
L
Fundamental
10
uW
ppm
Ω
F
Frequency Make Tolerance
Resistance
±30 ppm @ 25 °C ±3 °C
L
ESR
50
2
C
Static Shunt Capacitance
pF
O
Frequency Stability Over Operating Temperature Range
Storage Temperature Range
±30 ppm (referred to the value at 25 °C)
-40
-40
85
85
°C
°C
Operating Temperature Range
Aging
1 ppm/year
3000
Stanard Shipping Quantity on 178 mm (7”) Reel
Lid Symbolization (in addition to Lot and/or Date Codes)
units
2F YW
C
r
y
s
t
a
l
E
q
u
i
v
a
l
e
n
t
C
i
r
c
u
i
t
E
S
R
1
3
C
O
