XTL1013
•
•
•
•
Surface Mount Seam-Weld Package
Good Frequency Stability over Temperature
Excellent Reliability
26.00000 MHz
Crystal Unit
Complies with Directive 2002/95/EC (RoHS)
P
b
The XTL1013 is a surface mount 3.2 x 2.5 mm crystal unit for use in wireless
telecommunications devices, especially where an ultra-miniature package is
needed for mobility.
SM3225-4 Case
Electrical Characteristics
Characteristic
Sym
Notes
Minimum
Typical
26.00000
Maximum
Units
F
Nominal Frequency
MHz
O
Mode of Oscillation
Fundamental
Storage Temperature Range
Operating Temperature Range
Frequency Stability over Operating Temperature Range
-40
-20
+85
+75
°C
°C
±10 ppm (referred to the value at 25°C)
F
Frequency Make Tolerance
Equivalent Series Resistance
Nominal Drive Level
±10 ppm @ 25°C ±3°C
L
ESR
50
Ω
uW
pF
pF
100
C
Shunt Capacitance
3
O
C
Load Capacitance
10.3
L
Insulation Resistance
500 MΩ min @ 100 VDC
3000
Stanard Shipping Quantity on 178 mm (7”) Reel
Lid Symbolization (in addition to Lot and/or Date Codes)
units
Line1: 1013 Line2: YWWS
C
r
y
s
t
a
l
E
q
u
i
v
a
l
e
n
t
C
i
r
c
u
i
t
E
S
R
2
4
C
O
CAUTION: Electrostatic Sensitive Device. Observe precautions for handling.
