Performance Specifications
Phase Stability (continued)
Parameter
Min
Min
Typ
0.001
0.05
0.8
Max
Units
ns
Notes
TDEV 1s
Wander Generation per GR1244, system
performance when locked through a
1mHz loop bandwidth, see typical perfor-
mance data.
TDEV 10s
TDEV 100s
ns
ns
TDEV 1000s
3.5
ns
Phase Noise
Max
Parameter
Typ
Units
dBc/Hz
dBc/Hz
dBc/Hz
dBc/Hz
dBc/Hz
dBc/Hz
Notes
Phase Noise at 1 Hz Offset
Phase Noise at 10 Hz Offset
Phase Noise at 100 Hz Offset
Phase Noise 1 kHz Offset
-85
-115
-135
-145
Phase Noise at 10 kHz Offset
Phase Noise at 100kHz Offset
-150
-150
RF Output
Signal
HCMOS
15
Load
pF
ns
ns
ꢁ
V
10ꢁ
Rise Time
Fall Time
Duty Cycle
V Low
<10
<10
45/55
0.4
@ 10ꢁ to 90ꢁ Vout
@90ꢁ to 10ꢁ Vout
@ 50ꢁ Vout
WIth VS 3.0V and 15pF load
WIth VS 3.0V and 15pF load
WIth VS 5.0V and 15pF load
WIth VS 5.0V and 15pF load
V High
V Low
2.4
V
0.5
V
V High
3.5
V
Supply
Supply Voltage (VS)
Power consumption
Power consumption
3.3, 5.0
<1.5
V
10ꢁ
W
W
Steady state, @ VS = 3.3V, 25ꢀC
During warm up, @ VS = 3.3V, 25ꢀC
<3.3
Additional Parameters
Warm Up Time
3
minutes
@25ꢀC to final frequency (1 Hour) within
0.1ppm
ROHS
ROHS 6 compliant
Washable
Washable device (hermetically sealed).
Absolute Maximum Ratings
Min
-40
Max
85
Units
ꢀC
Operating temperature range
Storage temperature range
-50
90
ꢀC
