MD1
THRU
MD7
RECTRON
SEMICONDUCTOR
TECHNICAL SPECIFICATION
SINGLE-PHASE GLASS PASSIVATED
SILICON MINI BRIDGE RECTIFIER
VOLTAGE RANGE 50 to 1000 Volts CURRENT 0.5 Ampere
FEATURES
* Surge overload rating - 30 amperes peak
* Ideal for printed circuit board
* Reliable low cost construction utilizing molded
* Glass passivated device
* Polarity symbols molded on body
* Mounting position: Any
MD
* Weight: 0.5 gram
MECHANICAL DATA
.157(4.0)
.145(3.6)
*
Epoxy : Device has UL flammability classification 94V-0
* UL listed the recognized component directory, file #E94233
(
)
.217 5.50
.193(4.9)
.177(4.5)
.106(2.7)
.091(2.3)
MAXIMUM RATINGS AND ELECTRICAL CHARACTERISTICS
Ratings at 25 oC ambient temperature unless otherwise specified.
Single phase, half wave, 60 Hz, resistive or inductive load.
For capacitive load, derate current by 20%.
(3.45)
.136
.020
(
)
0.5
(
)
.104 2.65
Dimensions in inches and (millimeters)
MAXIMUM RATINGS (At T
A
= 25oC unless otherwise noted)
RATINGS
SYMBOL
MD1
50
MD2
100
70
MD3
200
MD4
400
MD5
600
MD6
800
MD7
1000
700
UNITS
Volts
V
RRM
RMS
Maximum Recurrent Peak Reverse Voltage
Maximum RMS Bridge Input Voltage
Maximum DC Blocking Voltage
V
35
140
280
420
560
Volts
V
DC
100
200
400
600
800
1000
Volts
50
Maximum Average Forward Output Rectified
Current at TA
= 30oC
I
O
Amp
0.5
Peak Forward Surge Current 8.3 ms single half sine-wave
superimposed on rated load (JEDEC method)
I
FSM
30
Amps
0 C
T
J,
T
STG
-55 to + 150
Operating and Storage Temperature Range
ELECTRICAL CHARACTERISTICS (At TA
= 25oC unless otherwise noted)
CHARACTERISTICS
SYMBOL
MD1
MD2
MD3
MD4
1.05
MD5
MD6
MD7
UNITS
Volts
Maximum Forward Voltage Drop per Bridge
Element at 0.5A DC
V
F
uAmps
Maximum Reverse Current at rated
DC Blocking Voltage per element
@T
@T
A
A
= 25oC
= 125oC
5.0
0.5
I
R
mAmps
2003-12
