Product specification
PZTA56
SOT-223
Unit: mm
■ Features
+0.2
+0.2
3.50-0.2
6.50-0.2
● Power dissipation：PC=1W
● Collector current (DC)：IC=500mA
● Complementary NPN Type Available (PZTA06)
+0.2
0.90-0.2
+0.1
3.00-0.1
+0.3
7.00-0.3
4
1 Base
2 Collector
1
2
3
+0.1
3 Emitter
0.70-0.1
2.9
4.6
4 Collector
■ Absolute Maximum Ratings Ta = 25℃
Parameter
Collector-Base Voltage
Collector-Emitter Voltage
Emitter-Base Voltage
Symbol
VCBO
VCEO
VEBO
IC
Rating
-80
Unit
V
-80
V
-4.0
-500
1
V
Collector Current -Continuous
Collector Power Dissipation
Junction Temperature
mA
W
℃
℃
PD
Tj
150
Storage Temperature
Tstg
-55 to 150
■ Electrical Characteristics Ta = 25℃
Parameter
Symbol
Test conditons
Min
-80
-80
-4.0
Typ Max
Unit
V
Collector-to-base breakdown voltage
Collector-to-emitter breakdown voltage
Emitter-to-base breakdown voltage
Collector cutoff current
V(BR)CBO Ic= -100 μA,IE=0
V(BR)CEO
V(BR)EBO
IcBO
V
Ic= -1 mA， IB=0
V
IE= -100 μA， IC=0
VCB= -80 V , IE=0
-100
-100
nA
nA
Emitter cut-off current
IEBO
VCE= -4V , IC=0
VCE= -1.0V, IC= -10mA
VCE= -10V, IC= -100mA
100
100
DC current gain
hFE
Collector-emitter saturation voltage
Base-Emitter On Voltage
Transition frequency
VCE(sat) IC=-100 mA, IB= -10mA
VBE(on) IC=-100 mA, VCE=-1.0V
-0.25
-1.2
V
V
fT
VCE= -1.0V, IC= -100mA,f=100MHz
50
MHz
■ Marking
Marking
A56
