Preliminary
XTL1029
• High Performance Crystal for Wireless Communications Devices
• Excellent Frequency Stability and Reliability
13.52915 MHz
Crystal Unit
• Ultra-Miniature Surface Mount Seam Weld Package
• Complies with Directive 2002/95/EC (RoHS)
P
b
The XTL1029 is a very high stability 13.52915 MHz crystal
suitable for a wide range of communications applications. The XTL1029’s
excellent frequency stability supports operation from -40 to +85 °C.
SM3225-4 Case
Electrical Characteristics
Characteristic
Sym
Notes
Minimum
Typical
13.52915
Maximum
Units
F
Nominal Frequency
MHz
O
Mode of Oscillation
Fundamental
Storage Temperature Range in Tape and Reel
Operating Temperature Range
Frequency Stability over Operating Temperature Range
-40
-40
+85
+85
°C
°C
±100 ppm (referred to the value at 25 °C)
F
Frequency Make Tolerance
Equivalent Series Resistance
Shunt Capacitance
±30 ppm @ 25 °C ±3 °C
L
ESR
70
Ω
pF
µW
pF
C
7
O
Nominal Drive Level
100
C
Load Capacitance
16
±1.0 ppm/year @ 25 °C
500
L
Aging
Insulation Resistance
MΩ
Standard Shipping Quantity on 178 mm (7”) Reel
Lid Symbolization (in addition to Lot and/or Date Codes)
3000
units
1029 YWWS
C
r
y
s
t
a
l
E
q
u
i
v
a
l
e
n
t
C
i
r
c
u
i
t
E
S
R
1
3
C
O
CAUTION: Electrostatic Sensitive Device. Observe precautions for handling.
Notes:
1.
2.
3.
US and international patents may apply.
The design, manufacturing process, and specifications of this device are subject to change without notice.
RFM, stylized RFM logo, and RF Monolithics, Inc. are registered trademarks of RF Monolithics, Inc.
www.RFM.com E-mail: info@rfm.com
©2009-2010 by RF Monolithics, Inc.
Page 1 of 5
XTL1029 2/4/10
