XTL1003-1
•
•
•
•
Surface Mount Seam-Weld Package
Good Frequency Stability over Temperature
Excellent Reliability
13.56000 MHz
Crystal Unit
Complies with Directive 2002/95/EC (RoHS)
P
b
The XTL1003-1 is a surface mount 5.0 x 3.2 mm crystal unit for use in wireless
telecommunications devices, especially where an ultra-miniature package is
needed for mobility.
SM5032-4 Case
Electrical Characteristics
Characteristic
Sym
Notes
Minimum
Typical
13.56000
Maximum
Units
Nominal Frequency
MHz
Mode of Oscillation
Fundamental
Storage Temperature Range, Crystal Only
Storage Temperature Range, in Tape and Reel
Operating Temperature Range
Frequency Stability over Operating Temperature Range
-50
-40
-20
+125
+85
°C
°C
°C
+70
±20 ppm (referred to the value at 25 °C)
F
Frequency Make Tolerance
Equivalent Series Resistance
Shunt Capacitance
±10 ppm @ 25 °C ±3 °C
L
ESR
40
Ω
pF
fF
C
2.0
O
C
Motional Capacitance
4.2 ±20%
M
Nominal Drive Level
10
13.5
µW
pF
MΩ
C
Load Capacitance
L
Insulation Resistance at 100 VDC
500
Aging
±1.0 ppm/year @ 25 °C
0.037 ±0.005
3000
Weight
g
Stanard Shipping Quantity on 330 mm (13”) Reel
Lid Symbolization (in addition to Lot and/or Date Codes)
units
1003-1 YWWS
C
r
y
s
t
a
l
E
q
u
i
v
a
l
e
n
t
C
i
r
c
u
i
t
E
S
R
1
3
C
O
CAUTION: Electrostatic Sensitive Device. Observe precautions for handling.
Notes:
1.
2.
3.
US and international patents may apply.
The design, manufacturing process, and specifications of this device are subject to change without notice.
RFM, stylized RFM logo, and RF Monolithics, Inc. are registered trademarks of RF Monolithics, Inc.
www.RFM.com E-mail: info@rfm.com
©2009-2010 by RF Monolithics, Inc.
Page 1 of 6
XTL1003-1 - 2/3/10
