PX0430/SE

型号:

PX0430/SE

描述:

插头和插座( 2极接地)[ Plugs and Sockets (2 Pole Earth) ]

品牌:

BULGIN[ ELEKTRON COMPONENTS LTD. ]

页数:

1 页

PDF大小:

65 K

GENERAL PURPOSE CONNECTORS
Plugs and Sockets (2 Pole + Earth)
CIRCULAR MALE INLET
2 Pole + Earth
Mates with PX0430/SE and
PX0646
Key to Ensure Correct Polarity
Solder Tags
3A, 250V a.c.
PX0429
CIRCULAR FEMALE CONNECTOR
2 Pole + Earth
Mates with PX0429
Key Way to Ensure Correct
Polarity
Solder Tags
3A, 250V a.c.
PX0430/SE
CIRCULAR FEMALE CONNECTOR
2 Pole + Earth
Mates with PX0429
Key Way to Ensure Correct
Polarity
Solder Tags
3A, 250V a.c.
PX0646
Specification
PX0429
PX0430/SE
PX0646
Terminations:
Solder Tags
Solder Tags
Solder Tags
Max. Rating:
3A, 250V a.c.
3A, 250V a.c.
3A, 250V a.c.
Contact Resistance:
Insulation Resistance:
A.C. Breakdown:
<10m
<10m
<10m
>105 M
>105 M
>105 M
Pole-Pole 4.5kV
Pole-Pole 4.5kV
Pole-Pole 4.5kV
Poles-Panel 8.5kV
Poles-Accessible Parts 3.5kV
Poles-Accessible Parts 3.5kV
Operating Temp. Range:
Mouldings:
–20˚C to
+
60˚C
–20˚C to
+
60˚C
–20˚C to +60˚C
Glass Filled Nylon
Brass, Tin Plated
Nylon and Glass Filled Nylon
Brass, Silver Plated
Nylon and Glass Filled Nylon
Brass, Silver Plated
Contacts:
Accessories:
Mates With:
RoHS
P.No. 9455 (see page 151)
PX0430/SE & PX0646
Compliant
PX0429
PX0429
Compliant
Compliant
www.bulgin.co.uk
147
