IXGK400N30A3
IXGX400N30A3
Symbol
Test Conditions
Characteristic Values
TO-264 (IXGK) Outline
(TJ = 25°C, Unless Otherwise Specified)
Min.
Typ.
Max.
gfs
IC = 60A, VCE = 10V, Note 1
VCE = 25V, VGE = 0V, f = 1 MHz
100
170
S
Cies
Coes
Cres
19
1350
190
nF
pF
pF
Qg(on)
Qge
560
83
nC
nC
nC
IC = 100A, VGE = 15V, VCE = 0.5 • VCES
Qgc
185
td(on)
tr
td(off)
tf
td(on)
tr
td(off)
tf
45
45
ns
ns
ns
ns
ns
ns
ns
ns
Resistive load, TJ = 25°C
IC = 100A, VGE = 15V
VCE = 240V, RG = 1Ω
210
107
47
Resistive load, TJ = 125°C
53
IC = 100A, VGE = 15V
240
315
VCE = 240V, RG = 1Ω
RthJC
RthCK
0.125 °C/W
°C/W
0.15
PLUS247TM (IXGX) Outline
Note 1. Pulse test, t ≤ 300μs, duty cycle, d ≤ 2%.
Terminals: 1 - Gate
2 - Drain (Collector)
3 - Source (Emitter)
Dim.
Millimeter
Inches
Min. Max.
Min. Max.
A
A1
A2
4.83
2.29
1.91
5.21
2.54
2.16
.190 .205
.090 .100
.075 .085
b
b1
b2
1.14
1.91
2.92
1.40
2.13
3.12
.045 .055
.075 .084
.115 .123
C
D
E
0.61
20.80 21.34
15.75 16.13
0.80
.024 .031
.819 .840
.620 .635
e
5.45 BSC
.215 BSC
L
L1
19.81 20.32
.780 .800
.150 .170
3.81
4.32
Q
R
5.59
4.32
6.20
4.83
.220 0.244
.170 .190
