Advance Technical Data
HiPerFASTTM IGBT
VCES
IC25
= 600 V
70 A
IXGH34N60B2
=
VCE(sat) < 1.55 V
Optimized for 10-25 KHz hard
switching and up to 150 KHz
resonant switching
tfityp
= 150 ns
Symbol
Test Conditions
Maximum Ratings
VCES
VCGR
TJ = 25°C to 150°C
600
600
V
V
TJ = 25°C to 150°C; RGE = 1 MΩ
VGES
VGEM
Continuous
Transient
20
30
V
V
IC25
IC110
ICM
TC = 25°C (limited by leads)
TC = 110°C
70
34
A
A
A
TO-247 AD
(IXGH)
TC = 25°C, 1 ms
150
C (TAB)
SSOA
(RBSOA)
PC
VGE = 15 V, TVJ = 125°C, RG = 10 Ω
Clamped inductive load @ ≤ 600 V
TC = 25°C
ICM = 60
A
G
C
E
190
W
G = Gate,
E = Emitter,
C = Collector,
TAB = Collector
TJ
-55 ... +150
150
°C
°C
°C
TJM
Tstg
-55 ... +150
Features
Maximum lead temperature for soldering
1.6 mm (0.062 in.) from case for 10 s
300
°C
z
Medium frequency IGBT
Square RBSOA
High current handling capability
MOS Gate turn-on
z
z
z
Md
Mounting torque (M3)
1.13/10Nm/lb.in.
Weight
TO-247 AD
6
4
g
g
- drive simplicity
TO-268 SMD
Applications
z
PFC circuits
Uninterruptible power supplies (UPS)
Switched-mode and resonant-mode
z
Symbol
Test Conditions
Characteristic Values
(TJ = 25°C, unless otherwise specified)
min. typ. max.
z
power supplies
AC motor speed control
DC servo and robot drives
DC choppers
z
z
VGE(th)
ICES
IC = 250 µA, VCE = VGE
2.5
5.0
V
z
VCE = VCES
VGE = 0 V
TJ = 25°C
50
µA
TJ = 150°C
1
100
mA
nA
V
IGES
VCE = 0 V, VGE = 20 V
IC = 24 A, VGE = 15 V
VCE(sat)
TJ = 25°C
1.55
© 2005 IXYS All rights reserved
DS99345(02/05)
