IXFH12N90P IXFV12N90P
IXFV12N90PS
Symbol
Test Conditions
Characteristic Values
PLUS220 (IXFV) Outline
(TJ = 25°C unless otherwise specified)
Min.
Typ.
Max.
gfs
VDS = 20V, ID = 0.5 • ID25, Note 1
5.0
8.2
S
RGi
Gate input resistance
1.7
Ω
Ciss
Coss
Crss
3080
200
33
pF
pF
pF
VGS = 0V, VDS = 25V, f = 1MHz
td(on)
tr
td(off)
tf
32
34
50
68
ns
ns
ns
ns
Resistive Switching Times
VGS = 10V, VDS = 0.5 • VDSS, ID = 0.5 • ID25
RG = 2Ω (External)
Qg(on)
Qgs
56
18
27
nC
nC
nC
VGS = 10V, VDS = 0.5 • VDSS, ID = 0.5 • ID25
Qgd
RthJC
RthCS
0.33 °C/W
°C/W
(TO-247, PLUS220)
0.25
Source-Drain Diode
Characteristic Values
TJ = 25°C unless otherwise specified)
Min.
Typ.
Max.
IS
VGS = 0V
12
A
A
V
ISM
VSD
Repetitive, pulse width limited by TJM
IF = IS, VGS = 0V, Note 1
48
TO-247 (IXFH) Outline
1.5
trr
300 ns
IF = 6A, -di/dt = 100A/μs
QRM
IRM
0.9
μC
VR = 100V, VGS = 0V
7.8
A
∅ P
Note 1: Pulse test, t ≤ 300μs; duty cycle, d ≤ 2%.
PLUS220SMD (IXFV_S) Outline
e
Dim.
Millimeter
Inches
Min. Max.
Min. Max.
A
A1
A2
4.7
2.2
2.2
5.3
2.54
2.6
.185 .209
.087 .102
.059 .098
b
b1
b2
1.0
1.65
2.87
1.4
2.13
3.12
.040 .055
.065 .084
.113 .123
C
D
E
.4
.8
.016 .031
.819 .845
.610 .640
20.80 21.46
15.75 16.26
PRELIMINARY TECHNICAL INFORMATION
e
5.20
5.72 0.205 0.225
L
L1
19.81 20.32
4.50
.780 .800
.177
The product presented herein is under development. The Technical Specifications offered are derived
from data gathered during objective characterizations of preliminary engineering lots; but also may yet
contain some information supplied during a pre-production design evaluation. IXYS reserves the right
to change limits, test conditions, and dimensions without notice.
∅P 3.55
Q
3.65
.140 .144
5.89
6.40 0.232 0.252
R
S
4.32
5.49
.170 .216
242 BSC
6.15 BSC
IXYS reserves the right to change limits, test conditions, and dimensions.
