IXFT60N50P3 IXFQ60N50P3
IXFH60N50P3
Symbol
Test Conditions
Characteristic Values
TO-3P (IXFQ) Outline
(TJ = 25°C Unless Otherwise Specified)
Min.
Typ.
Max.
gfs
VDS = 20V, ID = 0.5 • ID25, Note 1
VGS = 0V, VDS = 25V, f = 1MHz
35
60
S
Ciss
Coss
Crss
6250
680
5
pF
pF
pF
RGi
Gate Input Resistance
1.0
Ω
td(on)
tr
td(off)
tf
18
16
37
8
ns
ns
ns
ns
Resistive Switching Times
V
GS = 10V, VDS = 0.5 • VDSS, ID = 0.5 • ID25
RG = 1Ω (External)
Qg(on)
Qgs
96
28
26
nC
nC
nC
VGS = 10V, VDS = 0.5 • VDSS, ID = 0.5 • ID25
Qgd
RthJC
RthCS
0.12 °C/W
°C/W
(TO-247 & TO-3P)
0.25
Source-Drain Diode
Symbol
Test Conditions
Characteristic Values
(TJ = 25°C Unless Otherwise Specified)
Min.
Typ.
Max.
IS
VGS = 0V
60
A
A
V
TO-247 Outline
ISM
VSD
Repetitive, Pulse Width Limited by TJM
IF = IS, VGS = 0V, Note 1
240
1.4
trr
250
ns
A
∅ P
IF = 30A, -di/dt = 100A/μs
1
2
3
IRM
QRM
11
1.0
VR = 100V, VGS = 0V
μC
Note
1. Pulse test, t ≤ 300μs, duty cycle, d ≤ 2%.
TO-263 Outline
e
Terminals: 1 - Gate
2 - Drain
3 - Source
Dim.
Millimeter
Inches
Min. Max.
Min. Max.
A
A1
A2
4.7
2.2
2.2
5.3
2.54
2.6
.185 .209
.087 .102
.059 .098
b
b1
b2
1.0
1.65
2.87
1.4
2.13
3.12
.040 .055
.065 .084
.113 .123
C
D
E
.4
.8
.016 .031
.819 .845
.610 .640
20.80 21.46
15.75 16.26
e
L
L1
5.20
19.81 20.32
4.50
5.72 0.205 0.225
ADVANCE TECHNICAL INFORMATION
The product presented herein is under development. The Technical Specifications offered are derived
from a subjective evaluation of the design, based upon prior knowledge and experience, and constitute a
"considered reflection" of the anticipated result. IXYS reserves the right to change limits, test
conditions, and dimensions without notice.
.780 .800
.177
∅P 3.55
Q
3.65
.140 .144
5.89
6.40 0.232 0.252
R
S
4.32
6.15 BSC
5.49
.170 .216
242 BSC
IXYS Reserves the Right to Change Limits, Test Conditions, and Dimensions.
