IXFH20N100P
IXFT20N100P
Symbol
Test Conditions
Characteristic Values
TO-247 (IXFH) Outline
(TJ = 25°C unless otherwise specified)
Min.
Typ.
Max.
gfs
VDS = 20V, ID = 0.5 • ID25, Note 1
8
14
S
Ciss
Coss
Crss
7300
456
55
pF
pF
pF
∅ P
VGS = 0V, VDS = 25V, f = 1MHz
Gate input resistance
RGi
1.20
Ω
td(on)
tr
td(off)
tf
40
37
56
45
ns
ns
ns
ns
Resistive Switching Times
VGS = 10V, VDS = 0.5 • VDSS, ID = 0.5 • ID25
RG = 2Ω (External)
e
Dim.
Millimeter
Min. Max.
Inches
Min. Max.
A
A1
A2
4.7
2.2
2.2
5.3
2.54
2.6
.185 .209
.087 .102
.059 .098
Qg(on)
Qgs
126
50
nC
nC
nC
b
b1
b2
1.0
1.65
2.87
1.4
2.13
3.12
.040 .055
.065 .084
.113 .123
VGS = 10V, VDS = 0.5 • VDSS, ID = 0.5 • ID25
Qgd
55
C
D
E
.4
.8
.016 .031
.819 .845
.610 .640
20.80 21.46
15.75 16.26
RthJC
RthCS
0.19 °C/W
°C/W
e
L
L1
5.20
5.72 0.205 0.225
19.81 20.32
4.50
(TO-247)
0.21
.780 .800
.177
∅P 3.55
3.65
.140 .144
Q
5.89
6.40 0.232 0.252
Source-Drain Diode
TJ = 25°C unless otherwise specified)
Characteristic Values
R
S
4.32
6.15 BSC
5.49
.170 .216
242 BSC
Min.
Typ.
Max.
IS
VGS = 0V
20
A
A
V
TO-268 Outline
ISM
VSD
Repetitive, pulse width limited by TJM
IF = IS, VGS = 0V, Note 1
80
1.5
trr
300 ns
IF = 10A, -di/dt = 100A/μs
QRM
IRM
0.9
μC
VR = 100V, VGS = 0V
9.0
A
Note 1: Pulse test, t ≤ 300μs; duty cycle, d ≤ 2%.
