IXFR14N100Q2
Symbol
Test Conditions
Characteristic Values
ISOPLUS247 (IXFR) Outline
(TJ = 25°C Unless Otherwise Specified)
Min.
Typ.
Max.
gfs
VDS = 10V, ID = 7A, Note 1
10
14
S
Ciss
Coss
Crss
2800
287
pF
pF
pF
VGS = 0V, VDS = 25V, f = 1MHz
100
td(on)
tr
td(off)
tf
12
10
28
12
ns
ns
ns
ns
Resistive Switching Times
VGS = 10V, VDS = 0.5 • VDSS, ID = 7A
RG = 2Ω (External)
Qg(on)
Qgs
83
20
40
nC
nC
nC
VGS = 10V, VDS = 0.5 • VDSS, ID = 7A
Qgd
RthJC
RthCS
0.62 °C/W
°C/W
0.15
Source-Drain Diode
Characteristic Values
TJ = 25°C Unless Otherwise Specified)
Min.
Typ.
Max.
IS
VGS = 0V
14
A
A
V
ISM
VSD
Repetitive, Pulse Width Limited by TJM
IF = IS, VGS = 0V, Note 1
56
1.5
trr
300 ns
IF = 14A, -di/dt = 100A/μs
QRM
IRM
0.8
μC
VR = 100V, VGS = 0V
7
A
Note 1: Pulse test, t ≤ 300μs; duty cycle, d ≤ 2%.
