IXFN60N80P

型号：

IXFN60N80P

描述：

PolarHV HiPerFET功率MOSFET[ PolarHV HiPerFET Power MOSFET ]

品牌：

IXYS[ IXYS CORPORATION ]

页数：

4 页

PDF大小：

145 K

下载PDF手册
PolarHVTM HiPerFET
Power MOSFET
IXFN 60N80P
VDSS = 800 V
ID25 = 53 A
RDS(on) ≤ 140 mΩ
trr
≤ 250 ns
N-Channel Enhancement Mode
Avalanche Rated
Fast Intrinsic Diode
Symbol
Test Conditions
Maximum Ratings
miniBLOC, SOT-227 B (IXFN)
E153432
VDSS
VDGR
TJ = 25° C to 150° C
800
800
V
V
S
G
TJ = 25° C to 150° C; RGS = 1 MΩ
VGSS
VGSM
Continuous
Transient
30
40
V
V
S
ID25
IDM
TC =25° C
TC = 25° C, pulse width limited by TJM
53
250
A
A
D
IAR
TC =25° C
30
A
G = Gate
D = Drain
S = Source
EAR
EAS
TC =25° C
TC =25° C
100
5
mJ
J
Either Source terminal S can be used as the
Source terminal or the Kelvin Source (gate
return) terminal.
dv/dt
PD
IS ≤IDM, di/dt ≤100 A/µs, VDD ≤VDSS
TJ ≤150° C, RG = 2 Ω
,
20
V/ns
TC =25° C
1040
W
TJ
TJM
Tstg
-55 ... +150
150
-55 ... +150
°C
°C
°C
Features
• International standard package
• Encapsulating epoxy meets
UL94V-0, flammability classification
• miniBLOC with Aluminium nitride
isolation
TL
1.6 mm (0.062 in.) from case for 10 s
300
2500
3000
°C
V~
V~
VISOL
50/60 Hz, RMS
t = 1 min
IISOL ≤1 mA
t = 1 s
l
Md
Mounting torque
Terminal connection torque
1.5 / 13 Nm/lb.in.
1.5 / 13 Nm/lb.in.
Fast recovery diode
l
Unclamped Inductive Switching (UIS)
rated
Weight
30
g
l
Low package inductance
- easy to drive and to protect
Symbol
Test Conditions
Characteristic Values
Advantages
(TJ = 25° C, unless otherwise specified)
Min. Typ.
Max.
l
Easy to mount
Space savings
High power density
BVDSS
VGS(th)
IGSS
VGS = 0 V, ID = 3 mA
VDS = VGS, ID = 8 mA
VGS = 30 VDC, VDS = 0
800
V
V
l
l
3.0
5.0
200
nA
IDSS
VDS = VDSS
VGS = 0 V
25
3000
µA
µA
TJ = 125° C
RDS(on)
VGS = 10 V, ID = IT, Note 1
140 mΩ
DS99562E(02/06)
© 2006 IXYS All rights reserved
IXFN 60N80P
Symbol
gfs
Test Conditions
Characteristic Values
(TJ = 25°C, unless otherwise specified)
Min. Typ. Max.
SOT-227B Outline
VDS = 20 V; ID = IT, Note 1
35
67
S
Ciss
Coss
Crss
18
1200
44
nF
pF
pF
VGS = 0 V, VDS = 25 V, f = 1 MHz
td(on)
tr
td(off)
tf
36
29
ns
ns
ns
ns
VGS = 10 V, VDS = 0.5 VDSS, ID = IT
RG = 1 Ω (External)
110
26
Qg(on)
Qgs
250
90
nC
nC
nC
VGS = 10 V, VDS = 0.5 VDSS, ID = IT
Qgd
78
RthJC
RthCS
0.12 °C/W
°C/W
0.05
Source-Drain Diode
Characteristic Values
(TJ = 25°C, unless otherwise specified)
Min. Typ. Max.
Symbol
Test Conditions
IS
VGS = 0 V
60
150
1.5
A
ISM
VSD
trr
Repetitive
A
V
IF = IS, VGS = 0 V, Note 1
IF = 25A, -di/dt = 100 A/µs
250
ns
QRM
IRM
VR = 100V
0.6
6.0
µC
A
Notes:
1. Pulse test, t ≤300 µs, duty cycle d≤ 2 %
Test current IT = 30 A
IXYS reserves the right to change limits, test conditions, and dimensions.
IXYS MOSFETs and IGBTs are covered by 4,835,592 4,931,844
one or moreof the following U.S. patents: 4,850,072 5,017,508
4,881,106 5,034,796
5,049,961
5,063,307
5,187,117
5,237,481
5,381,025
5,486,715
6,162,665
6,259,123 B1
6,306,728 B1
6,404,065 B1 6,683,344
6,727,585
6,534,343
6,583,505
6,710,405B2 6,759,692
6,710,463 6,771,478 B2
IXFN 60N80P
Fig. 1. Output Characteristics
@ 25ºC
Fig. 2. Extended Output Characteristics
@ 25ºC
60
55
50
45
40
35
30
25
20
15
10
5
120
100
80
60
40
20
0
VGS = 10V
7V
V
= 10V
7V
GS
6V
6V
5V
5V
6
0
0
0
0
1
2
3
4
5
7
8
9
0
3
6
9
12
15
18
21
24
27
30
150
150
VDS - Volts
VDS - Volts
Fig. 4. RDS(on) Normalized to ID = 30A Value
vs. Junction Temperature
Fig. 3. Output Characteristics
@ 125ºC
60
55
50
45
40
35
30
25
20
15
10
5
3.2
2.8
2.4
2
V
= 10V
7V
GS
V
= 10V
GS
6V
I
= 60A
D
I
= 30A
1.6
1.2
0.8
0.4
D
5V
14
0
2
4
6
8
10
12
16
18
20
-50
-25
0
25
50
75
100
125
VDS - Volts
TJ - Degrees Centigrade
Fig. 5. RDS(on) Normalized to ID = 30A Value
vs. Drain Current
Fig. 6. Maximum Drain Current vs.
Case Temperature
2.8
2.6
2.4
2.2
2
60
55
50
45
40
35
30
25
20
15
10
5
V
= 10V
GS
T
J
= 125ºC
1.8
1.6
1.4
1.2
1
T
J
= 25ºC
0
0.8
-50
-25
0
25
50
75
100
125
20
40
60
80
100
120
TJ - Degrees Centigrade
ID - Amperes
© 2006 IXYS All rights reserved
IXFN 60N80P
Fig. 8. Transconductance
Fig. 7. Input Admittance
80
70
60
50
40
30
20
10
0
130
120
110
100
90
TJ = 125ºC
25ºC
- 40ºC
80
T
J
= - 40ºC
70
25ºC
125ºC
60
50
40
30
20
10
0
4
4.25 4.5 4.75
5
5.25 5.5 5.75
6
6.25 6.5 6.75
0
10
20
30
40
50
60
70
80
VGS - Volts
ID - Amperes
Fig. 9. Forward Voltage Drop of
Intrinsic Diode
Fig. 10. Gate Charge
180
160
140
120
100
80
10
9
8
7
6
5
4
3
2
1
0
V
= 400V
DS
I
I
= 30A
D
G
= 10mA
60
T
J
= 125ºC
40
T
J
= 25ºC
20
0
0.3 0.4
0.5 0.6
0.7 0.8
0.9
1
1.1 1.2
1.3 1.4
0
20 40 60 80 100 120 140 160 180 200 220 240 260
QG - NanoCoulombs
VSD - Volts
Fig. 12. Maximum Transient Thermal
Resistance
Fig. 11. Capacitance
1.000
0.100
0.010
0.001
100,000
10,000
1,000
100
f = 1 MHz
C
C
iss
oss
C
rss
10
0.0001
0.001
0.01
0.1
1
10
0
5
10
15
20
25
30
35
40
Pulse Width - Seconds
VDS - Volts
