PolarTM Power MOSFET
HiPerFETTM
VDSS = 1200V
ID25 = 30A
RDS(on) ≤ 350mΩ
≤ 300ns
IXFN30N120P
N-Channel Enhancement Mode
Avalanche Rated
Fast Intrinsic Diode
trr
miniBLOC, SOT-227 B (IXFN)
E153432
Symbol
VDSS
Test Conditions
Maximum Ratings
S
TJ = 25°C to 150°C
1200
1200
V
V
G
VDGR
TJ = 25°C to 150°C, RGS = 1MΩ
VGSS
VGSM
Continuous
Transient
± 30
± 40
V
V
S
ID25
IDM
TC = 25°C
30
75
A
A
D
D = Drain
TC = 25°C, pulse width limited by TJM
G = Gate
S = Source
IA
TC = 25°C
TC = 25°C
15
2
A
J
EAS
Either Source terminal S can be used as the
Source terminal or the Kelvin Source (gate
return) terminal.
dV/dt
PD
IS ≤ IDM, VDD ≤ VDSS, TJ ≤ 150°C
TC = 25°C
20
V/ns
W
890
Features
TJ
-55 ... +150
150
°C
°C
°C
TJM
Tstg
• International standard package
• Encapsulating epoxy meets
UL94V-0, flammability classification
• miniBLOC with Aluminium nitride
isolation
-55 ... +150
TL
1.6mm (0.062 in.) from case for 10s
300
°C
VISOL
50/60 Hz, RMS
t = 1min
2500
3000
V~
V~
• Fast recovery diode
• Unclamped Inductive Switching (UIS)
rated
IISOL ≤ 1mA
t = 1s
Md
Mounting torque
Terminal connection torque
1.5/13
1.3/11.5
Nm/lb.in.
Nm/lb.in.
• Low package inductance
- easy to drive and to protect
Weight
30
g
Advantages
• Easy to mount
• Space savings
• High power density
Symbol
Test Conditions
Characteristic Values
(TJ = 25°C, unless otherwise specified)
Min.
Typ. Max.
Applications
BVDSS
VGS(th)
IGSS
VGS = 0V, ID = 3mA
VDS = VGS, ID = 1mA
VGS = ± 30V, VDS = 0V
1200
3.5
V
V
z High Voltage Switched-mode and
resonant-mode power supplies
z High Voltage Pulse Power
Applications
6.5
± 300 nA
z High Voltage Discharge circuits in
Laser Pulsers, Spark Igniters, RF
Generators
z High Voltage DC-DC converters
z High Voltage DC-AC inverters
IDSS
VDS = VDSS
VGS = 0V
50 μA
5 mA
TJ = 125°C
RDS(on)
VGS = 10V, ID = 0.5 • ID25, Note 1
350 mΩ
DS99884A (4/08)
© 2008 IXYS CORPORATION, All rights reserved
