IXFB30N120P
Symbol
Test Conditions
Characteristic Values
PLUS264TM (IXFB) Outline
(TJ = 25°C Unless Otherwise Specified)
Min.
Typ.
Max.
gfs
VDS = 20V, ID = 0.5 • ID25, Note 1
VGS = 0V, VDS = 25V, f = 1MHz
13
22
S
Ciss
Coss
Crss
22.5
950
28
nF
pF
pF
RGi
Gate Input Resistance
1.64
Ω
td(on)
tr
td(off)
tf
57
60
95
56
ns
ns
ns
ns
Resistive Switching Times
V
GS = 10V, VDS = 0.5 • VDSS, ID = 0.5 • ID25
RG = 1Ω (External)
Qg(on)
Qgs
310
104
137
nC
nC
nC
VGS = 10V, VDS = 0.5 • VDSS, ID = 0.5 • ID25
Qgd
RthJC
RthCS
0.10 °C/W
°C/W
0.13
Source-Drain Diode
Symbol
Test Conditions
Characteristic Values
(TJ = 25°C, Unless Otherwise Specified)
Min.
Typ. Max.
IS
VGS = 0V
30
120
1.5
A
A
V
ISM
VSD
Repetitive, Pulse Width Limited by TJM
IF = IS, VGS = 0V, Note 1
trr
300 ns
IF = 0.5 • ID25, VGS = 0V
QRM
IRM
1.6
μC
-di/dt = 100A/μs
VR = 100V
14
A
Note 1: Pulse test, t ≤ 300μs, duty cycle, d ≤ 2%.
