IXDA 20N120AS
IC25
VCES
= 38A
=1200V
High Voltage IGBT
VCE(sat) typ = 2.4V
Short Circuit SOA Capability
Square RBSOA
TAB
1
3
h
TAB
Features
IGBT
• NPT IGBT
- low saturation voltage
- positive temperature coefficient for
easy paralleling
• TO-263 package
Symbol
VCES
Conditions
Maximum Ratings
TVJ = 25°C to 150°C
1200
20
V
VGES
V
IC25
IC90
TC = 25°C
TC = 90°C
38
25
A
A
- SMD assembly
- industry standard outline
ICM
VCEK
VGE = 15 V; RG = 82 W; TVJ = 125°C
35
VCES
A
µs
W
Applications
RBSOA, clamped inductive load; L = 100 µH
• drives
• power supplies
- switched mode power supplies
- uninterruptible power supplies
tSC
V
CE = VCES
;
VGE = 15 V; RG = 82 W; TVJ = 125°C
10
(SCSOA) non-repetitive
Ptot
TC = 25°C
200
Symbol
Conditions
Characteristic Values
(TVJ = 25°C, unless otherwise specified)
min.
typ.
max.
VCE(sat)
IC = 20 A; VGE = 15 V; TVJ = 25°C
TVJ = 125°C
2.4
2.6
3.0
V
V
VGE(th)
ICES
IC = 0.6 mA; VGE = VCE
4.5
6.5
0.8
V
VCE = VCES; VGE = 0 V; TVJ = 25°C
TVJ = 125°C
mA
mA
0.8
IGES
VCE = 0 V; VGE
=
20 V
200
nA
td(on)
tr
td(off)
tf
Eon
Eoff
100
75
500
70
3.1
2.4
ns
ns
ns
ns
mJ
mJ
Inductive load; TVJ = 125°C
VCE = 600 V; IC = 20 A
VGE = 15 V; RG = 82 W
Cies
QGon
VCE = 25 V; VGE = 0 V; f = 1 MHz
VCE = 600 V; VGE = 15 V; IC = 18 A
1000
70
pF
nC
RthJC
0.63
K/W
IXYS reserves the right to change limits, test conditions and dimensions.
© 2011 IXYS All rights reserved
20110118a
1 - 5
