applications
OV7710
¬ security/surveillance cameras
¬ video conferencing
¬ video phones
¬ video e-mail
¬ finger print equipment
ordering information
¬ OV07710-C00A
(color, CLCC-48)
¬ toys
¬ medical and dental equipment
¬ OV07211-C00A
(b&w, CLCC-48)
product features
product specifications
¬ OmniPixel2™ technology
¬ white balance, exposure time,
gain control, etc.
¬ array size: 656 x 492
¬ minimum illumination (3000K):
0.04 Lux @ f/1.2
¬ single chip 1/4", VGA sensor
¬ power supply
¬ low power consumption
¬ S/N ratio: 50 dB
analog: 3.3VDC 10ꢀ
¬ high sensitivity for low-light
operation
¬ external frame sync capability
(Genlock)
¬ dynamic range: 53 dB
¬ scan mode: progressive
¬ power requirements
active: 140 mW typical
(30 fps VGA, YUV)
standby: TBD
¬ master/slave compatible Serial
Camera Control Bus (SCCB)
control interface for register
programming
¬ SPI for overlay control
¬ electronic exposure: up to 521:1
(for selected fps)
¬ supports two sets of dynamic
overlay control
¬ output format
10-bit raw data
8-bit YUV/RGB
¬ pixel size: 6.0μm x 6.0μm
¬ low fixed pattern noise,
anti-blooming, zero smearing
¬ fixed pattern noise:
< 0.03ꢀ of V PEAK-TO-PEAK
¬ progressive scan
¬ max image transfer rate
VGA: 30 fps
QVGA: 60 fps
¬ image area: 4.080 mm x 3.102 mm
¬ horizontal mirroring and
vertical flipping
¬ package dimensions:
14.22 mm x 14.22 mm
¬ temperature range:
-40/+105˚C in CLCC
block diagram
