DIP Switches
End Stackable DIP Switches
DX5 Series
A static load of 1 kgf is applied in the
operating direction and pulling direction
operated for a period of 15 seconds.
Stop
Strength
There shall be no sign of
damage mechanically.
7
8
1)Soldering Temperature :
PROD SERIES
TEMP
TIME
THROUGH HOLE
260ɗ 5ɗ
5 1 sec.
TYPE
1)Contact Resistance :
200m͈Max
2)As shown in item 3~6
Soldering
Heat
Resistance
SMT TYPE
SEE PAGE 4
2)Duration of Solder Immersion:
5 1 sec.
3)Frequency of Soldering Process:
2 times max.
(PCB is 1.6mm in thickness.)
Shall be vibrated in accordance with
Method 201A of MIL-STD-202F
1)Frequency: 10-55-10 Hz 1 min/cycle.
2)Direction: 3 vertical directions including the
direction of operation.
As shown in item 2~6
As shown in item 2~6
Vibration
Shock
9
3)Test Time: 2 hours each direction.
Shall be shocked in accordance with Method
213B condition A of MIL-STD-202F
1)Acceleration: 50G.
10
2)Action Time : 11 1 m sec.
3)Testing Direction: 6 sides.
4)Test cycle: 3 times in each direction
THT Soldering Temperature:245 3ɗ
Lead-Free solder烉M705E JIS Z 3282
Class A
No anti-soldering and the
coverage of dipping into
solder must more than 75%
was requested.
(Tin 96.5%炻Silver 3%炻Copper 0.5%)
SMT SEE PAGE 4
11 Solderability
Flux: 5-10 seconds.
Duration of solder Immersion:
5 1 sec.
Measurements shall be made following
the test set forth below:
1)As show in item 3,4
1)25 mA, 24V DC resistive load
)2)Rate of Operation: 15~20 cycles/ minute
3)Cycle of Operation: 2000 cycles.
Operation
2)Contact Resistance:
500m max.
12
Life
(final-after test)
