PD-04A200
Vishay Dale
Plasma Panel Displays
4 Character, 16 Segment Alphanumeric Display
with 2.00" [50.80mm] High Characters
FEATURES
• 200 foot lamberts brightness
• Designed for multiplexed operation
• Edgeboard connection (terminals available as
PD-04A200-2)
SEGMENT DESIGNATION
• End stackable
B
A
J
K
I
H
C
P
L
N M
O
G
D
F
E
STANDARD ELECTRICAL SPECIFICATIONS
CHARACTERISTIC @ + 25°C
MINIMUM
NOTES
TYPICAL MAXIMUM
Panel Voltage Drop
(at typical cathode current)
130 VDC
—
145 VDC
—
170 VDC
Initial Ionization Time
(peak cathode voltage - 180)
5 sec.
Cathode Segment Current
Note: At the specified current, a segment shall glow
uniformly over its entire surface with no glow visible on any
other part of the panel.
† Recommended D.C. keep alive circuit: Use a 1 Megohm
resistor in series with cathode and a 1 Megohm resistor in
series with anode connected to a 200 VDC source.
(see drawing for cathode designation)
Segments a, b, p, l, f and e
Segments c, d, g, h, i, j, k, m, n and o
Keep Alive †
Source Voltage *
Anode Off Voltage *
2.5 mA
5.0 mA
4.3 mA
8.6 mA
50 µA
- 200 VDC - 220 VDC
- 100 VDC
8.7 mA
17.5 mA
75 µA
25 µA
- 180 VDC
- 35 VDC
- 35 VDC
80 µsec.
20 µsec.
10 µsec.
.32 msec.
—
- 120 VDC
* Voltage referenced to anode on voltage.
Cathode Off Voltage *
Digit Period
Cathode Blanking Interval
Cathode Blanking Overlap
Display Scan Period
- 100 VDC - 120 VDC
1250 µsec. 2500 µsec.
100 µsec.
50 µsec.
5 msec.
4
—
—
Note: Operating limits do not apply simultaneously, e. g.,
operation at maximum current may require a longer blanking
interval than the minimum specified.
10 msec.
—
Number of Anodes per Scan
DIMENSIONS in inches [millimeters]
.750
[19.05]
Typ.
1.00
[25.40]
Typ.
.300 .150
[7.62 3.81]
.294
[7.468]
Max.
.550
[13.97]
Max.
Digit #1
See Detail
2.00
[50.8]
Typ.
.500
[12.70]
Max.
2.85 .040
[72.39 1.02]
1.550 .062
[39.37 1.575]
56 Spaces @ .100 [2.54]
= 5.60 [142.24]
.120 + .010
.540 .015
[13.716 .381]
- .005
[3.048 + .254
- .127]
Tolerance
.160 .015
[4.064 .381]
Non-Accumulative
3.600 .062
[91.44 1.575]
Pad #1
See Table
.06 .005
[1.52 .127] TYP.
.925 .015
[23.495 .381]
7.20 .040
[182.88 1.02]
ORDERING INFORMATION
DESCRIPTION
PART NUMBER
Display with Edgeboard Type Connection ............................................................................................................................ PD-04A200
Display with Attached Terminals (Solderable) .................................................................................................................... PD-04A200-2
