S-1.5KE Series 1500W Transient Voltage Suppressor
DESCRIPTION:
The S-1.5KE series of high current uni/bi-directional
transient suppressors are designed for A.C. line protection
and high power DC bus clamping applications. These
devices offer uni/bi-directional port protection from 6.8
volts to 600 volts. They provide a clamping voltage lower
than the avalanche voltage. Therefore, any voltage rise
due to increased current conduction is contained to a
minimum, providing the best possible protection level.
They can also be connected in series and/or parallel to
create very high capacity protection solutions.
DO-201
FEATURES:
Symbol
Low zener impedance.
Excellent clamping capability.
Repetition rate (duty cycle): 0.01%.
JEDEC DO-27/DO-201 Molded Plastic.
Color band denoted cathode except bidirectional.
High temperature soldering: 260℃/10s at terminals.
Glass passivated chip junction in DO-27/DO-201 package.
1500W Peak Pulse power capability at 10×1000μs waveform.
Fast response time: typically less than 1.0ps from 0V to VBR min.
AEC-Q101 qualified.
ABSOLUTE MAXIMUM RATINGS (TA=25ºC, RH=45%-75%, unless otherwise noted)
Parameter
Symbol
Value
Unit
Peak pulse power dissipation on 10/1000μs
waveform
PPP
1500
W
Peak pulse current of on 10/1000μs
waveform
IPP
See next table
6.5
A
Steady state power dissipation at TL=75℃
PM(AV)
TSTG, TJ
W
℃
Operating junction and Storage temperature
range
-55 to +125
Peak forward surge current, 8.3ms single
half sine-wave
IFSM
200
A
1/5
Rev : 01.08.2021
www.leiditech.com
S-1.5KE Series 1500W Transient Voltage Suppressor
ELECTRICAL CHARACTERISTICS (TA=25℃)
①
Part Number
Uni-Polar Bi-Polar
VR
IR@VR
VBR@IT
IT
VC@IPP
IPP
V
μA
150
100
50
20
10
5
min(V) max(V) mA
max(V)
10.5
11.3
A
S-1.5KE6.8A S-1.5KE6.8CA
S-1.5KE7.5A S-1.5KE7.5CA
5.8
6.4
6.45
7.13
7.14
7.88
10
10
10
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
147.1
132.8
124.0
112.0
103.5
96.2
89.8
82.5
70.8
66.7
59.6
54.2
49.1
45.2
40.0
36.3
32.9
30.1
27.9
25.3
23.2
21.4
19.5
17.7
16.4
14.6
13.3
12.0
11.0
10.0
S-1.5KE8.2A S-1.5KE8.2CA 7.02
S-1.5KE9.1A S-1.5KE9.1CA 7.78
7.79
8.61
12.1
13.4
14.5
15.6
16.7
18.2
21.2
22.5
25.2
27.7
30.6
33.2
37.5
41.4
45.7
49.9
53.9
59.3
64.8
70.1
77.0
85.0
92.0
103.0
113.0
125.0
137.0
152.0
8.65
9.55
S-1.5KE10A S-1.5KE10CA
S-1.5KE11A S-1.5KE11CA
S-1.5KE12A S-1.5KE12CA
S-1.5KE13A S-1.5KE13CA
S-1.5KE15A S-1.5KE15CA
S-1.5KE16A S-1.5KE16CA
S-1.5KE18A S-1.5KE18CA
S-1.5KE20A S-1.5KE20CA
S-1.5KE22A S-1.5KE22CA
S-1.5KE24A S-1.5KE24CA
S-1.5KE27A S-1.5KE27CA
S-1.5KE30A S-1.5KE30CA
S-1.5KE33A S-1.5KE33CA
S-1.5KE36A S-1.5KE36CA
S-1.5KE39A S-1.5KE39CA
S-1.5KE43A S-1.5KE43CA
S-1.5KE47A S-1.5KE47CA
S-1.5KE51A S-1.5KE51CA
S-1.5KE56A S-1.5KE56CA
S-1.5KE62A S-1.5KE62CA
S-1.5KE68A S-1.5KE68CA
S-1.5KE75A S-1.5KE75CA
S-1.5KE82A S-1.5KE82CA
S-1.5KE91A S-1.5KE91CA
8.55
9.4
9.50
10.50
11.60
12.60
13.70
15.80
16.80
18.90
21.00
23.10
25.20
28.40
31.50
34.70
37.80
41.00
45.20
49.40
53.60
58.80
65.10
71.40
78.80
86.10
95.50
105.0
116.0
10.50
11.40
12.40
14.30
15.20
17.10
19.00
20.90
22.80
25.70
28.50
31.40
34.20
37.10
40.90
44.70
48.50
53.20
58.90
64.60
71.30
77.90
86.50
95.00
105.0
10.2
11.1
12.8
13.6
15.3
17.1
18.8
20.5
23.1
25.6
28.2
30.8
33.3
36.8
40.2
43.6
47.8
53.0
58.1
64.1
70.1
77.8
2
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
S-1.5KE100A S-1.5KE100CA 85.5
S-1.5KE110A S-1.5KE110CA 94.0
1
1
2/5
Rev : 01.08.2021
www.leiditech.com
S-1.5KE Series 1500W Transient Voltage Suppressor
ELECTRICAL CHARACTERISTICS (TA=25℃, continued)
①
Part Number
Uni-Polar Bi-Polar
VR
V
IR@VR
VBR@IT
IT
VC@IPP
IPP
μA
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
min(V) max(V) mA
max(V)
165.0
179.0
207.0
219.0
234.0
246.0
274.0
328.0
344.0
414.0
482.0
548.0
602.0
658.0
698.0
740.0
828.0
A
S-1.5KE120A S-1.5KE120CA 102.0
S-1.5KE130A S-1.5KE130CA 111.0
S-1.5KE150A S-1.5KE150CA 128.0
S-1.5KE160A S-1.5KE160CA 136.0
S-1.5KE170A S-1.5KE170CA 145.0
S-1.5KE180A S-1.5KE180CA 154.0
S-1.5KE200A S-1.5KE200CA 171.0
S-1.5KE220A S-1.5KE220CA 185.0
S-1.5KE250A S-1.5KE250CA 214.0
S-1.5KE300A S-1.5KE300CA 256.0
S-1.5KE350A S-1.5KE350CA 300.0
S-1.5KE400A S-1.5KE400CA 342.0
S-1.5KE440A S-1.5KE440CA 376.0
S-1.5KE480A S-1.5KE480CA 408.0
S-1.5KE510A S-1.5KE510CA 434.0
S-1.5KE550A S-1.5KE550CA 460.0
S-1.5KE600A S-1.5KE600CA 512.0
① Surge waveform: 10/1000μs
114.0
124.0
143.0
152.0
162.0
171.0
190.0
209.0
237.0
285.0
332.0
380.0
418.0
456.0
485.0
513.0
570.0
126.0
137.0
158.0
168.0
179.0
189.0
210.0
231.0
263.0
315.0
368.0
420.0
462.0
504.0
535.0
567.0
630.0
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
9.1
8.4
7.3
6.9
6.5
6.1
5.5
4.6
4.4
3.7
3.2
2.8
2.5
2.3
2.1
2.0
1.8
VR ：Stand-off Voltage -- Maximum voltage that can be applied
BR：Breakdown Voltage
V
VC：Clamping Voltage -- Peak voltage measured across the suppressor at a specified Ipp
IR：Reverse Leakage Current
3/5
Rev : 01.08.2021
www.leiditech.com
S-1.5KE Series 1500W Transient Voltage Suppressor
RATINGS AND V-I CHARACTERISTICS CURVES (TA=25ºC, unless otherwise noted)
FIG.1:V- I curve characteristics
(Uni-directional)
FIG.2:V- I curve characteristics
(Bi-directional)
IPP
IT
IR
V
V
VC
VBR
VBR VR
VR
VC
IR
IT
VF
VR VBR VC
IPP
IPP
FIG.3: Pulse waveform
FIG.4: Pulse derating curve
IPPM(%IRSM)
150
PPP derating in percentage(%)
100
tr = rise time to peak value
td = decay time to half value
tr=10μs
80
60
40
Peak value
100
Half value
50
0
20
0
td
t(ms)
2.0
TA(℃)
75 100
0
1.0
3.0
4.0
0
25
50
125
150
175
SOLDERING PARAMETERS
Pb-Free assembly
(see FIG.5)
Reflow Condition
FIG.5: Reflow condition
-Temperature Min (Ts(min)
)
+150℃
tp
Pre
T
P
-Temperature Max(Ts(max)
)
+200℃
Critical Zone
TL to TP
Ramp-up
Heat
TL
-Time (Min to Max) (ts)
60-180 secs.
tL
TS(max)
Average ramp up rate (Liquid us Temp
(TL) to peak)
3℃/sec. Max
Ramp-down
Preheat
T
S(min)
Ts(max) to TL - Ramp-up Rate
3℃/sec. Max
+217℃
t
s
-Temperature(TL)(Liquid us)
Reflow
25
time to peak temperatue
(t 25 to peak)
Time
℃
-Temperature(tL)
60-150 secs.
+260(+0/-5)℃
Peak Temp (Tp)
Time within 5℃ of actual Peak Temp (tp) 30 secs. Max
Ramp-down Rate
6℃/sec. Max
8 min. Max
+260℃
Time 25℃ to Peak Temp (TP)
Do not exceed
4/5
Rev : 01.08.2021
www.leiditech.com
S-1.5KE Series 1500W Transient Voltage Suppressor
MARKING ＆ ORDERING INFORMATION
S- 1.5KE
(1)
XX
(2)
C
(3)
A
(4)
(1)Series:1500 watts series
(2)Reverse Stand-off Voltage
(3)Bi-directional
(4)5% VBR Voltage tolerance
Cathode Band
Logo
1.5KExxCA
Product Type
PACKAGE MECHANICAL DATA
Dimensions
Inches Millimeters
Ref.
A
B
A
Max.
-
Min.
25.40
8.60
Max.
-
Min.
1.000
0.339
0.045
0.193
A
B
C
D
9.20
1.45
5.60
0.362
0.057
0.221
1.15
4.90
Part Number
Case Type
Quantity
1000
Packing Option
Box
S-1.5KEXXCA/A
DO-27/DO-201
Shanghai Leiditech Electronic Co.,Ltd
Email: sale1@leiditech.com
Tel : +86- 021 50828806
Fax : +86- 021 50477059
5/5
Rev : 01.08.2021
www.leiditech.com
